Please read this manual carefully before operating your set and retain it for future reference.
OWNER’S MANUAL
HD Compact Network Camera
MODEL
LW130W
1202 (V1.2)
2
Safety Instructions
The following instructions and guidance are for your safe and proper use of the products to prevent damages on
properties and injuries.
Handling of the Product
• Make sure any water or other fluid does not enter the device, as well as metallic objects or any other conductive substances.
- Fire or electric shock is feared if any fluids or metallic objects enter the device.
• When cleaning the dusts or other foreign objects off the device, use dry clothes to wipe out the surface gently. When the
contamination is heavy, use clothes soaked in neutral detergents. Do not use thinner, alcohol, benzene, insecticide or other
volatile substances on the surface.
- The surface of the product or the operation of the device may negatively be affected.
• When cleaning the surface of the device, always use dry clothes. Do not use water, chemicals, or cleansing detergents as
electric shocks or damages on the devices may occur.
• Do not attempt to disassemble, repair, or adjust the device. Any disassembly attempts not by a qualified technicians from LG
Electronics may cause fire, electric shocks, or injuries.
• Do not place heavy objects on top of the device.
3
Safety Instructions
Installation and Storage
• Please read and follow the instructions below carefully as you prepare for the installation of the device.
• Shut down the power of the main device
• Reserve enough space for the wiring of the device when installing the product.
• Do not install in a place with high moisture, dusts, or soot.
• Do not install under direct sunlight or close to a heater.
• Do not install in a place where there is danger of electric shocks or close to magnetic objects.
• Install the device in a place with appropriate temperature and moisture. ( the recommended temperature range of operation
is between 0 °C and 40 °C.)
• Make sure the device is installed in a well-ventilated place. Do not place the device where the ventilation is bad, under
excessive vibration, or close to a strong electro-magnetic wave source.
• Check for any source of danger (moisture, possible damages on the wires, or instability of the place where the device is
located). When you find one, please contact the closet customer service center.
4
Safety Instructions
EU Conformity Notice
LG Electronics hereby declares that this/these product(s) is/are in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC, 2004/108/EC, 2006/95/EC and 2009/125/EC
Please contact to the following address for obtaining a copy of the DoC (Declaration of Conformity).
European Standards Centre:
Krijgsman 1, 1186 DM Amstelveen The Netherlands
Indoor use only.
RF Radiation Exposure Statement
This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body.
5
Safety Instructions
France Notice
Pour la France métropolitaine
2.400 - 2.4835 GHz (Canaux 1à 13) autorisé en usage intérieur
2.400 -2.454 GHz (canaux 1 à 7) autorisé en usage extérieur
Pour la Guyane et la Réunion
2.400 - 2.4835 GHz (Canaux 1à 13) autorisé en usage intérieur
2.420 - 2.4835 GHz (canaux 5 à 13) autorisé en usage extérieur
Italy Notice
A general authorization is requested for outdoor use in Italy.
The use of these equipments is regulated by:
1. D.L.gs 1.8.2003, n. 259, article 104 (activity subject to general authorization)
for outdoor use and article 105 (free use) for indoor use, in both cases for private use.
2. D.M. 28.5.03, for supply to public of RLAN access to networks and telecom services.
L’uso degli apparati è regolamentato da:
1. D.L.gs 1.8.2003, n. 259, articoli 104 (attività soggette ad autorizzazione generale) se utilizzati al di fuori del proprio fondo e
105 (libero uso) se utilizzati entro il proprio fondo, in entrambi i casi per uso private.
2. D.M. 28.5.03, per la fornitura al pubblico dell’accesso R-LAN alle reti e ai servizi di telecomunicazioni.
6
Safety Instructions
FCC Compliance Statement
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
7
Safety Instructions
CAUTION : Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate this equipment.
FCC RF Radiation Exposure Statement : This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator
and your body. End users must follow the specific operating instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
CAUTION: Regulations of the FCC and FAA prohibit airborne operation of radio-frequency wireless devices because their signals
could interfere with critical aircraft instruments.
Responsible Party:
LG Electronics USA, Inc.
1000 Sylvan Avenue
Englewood Cliffs, NJ 07632
TEL. : +1-800-243-0000
8
Contents
Product Characteristics ................................................... 9
Device Overview & Features.......................................... 10
Connecting the Device....................................................13
Cautions.....................................................................13
Connection Scheme .............................................13
Network Connections ........................................... 14
Power Supply........................................................... 15
Connecting Alarming Devices .......................... 16
Inserting a micro SD Card.................................. 18
Installing the Camera .......................................... 20
Initial Configuration and Operation..............................22
Before Using the System ................................... 22
Recommended PC Requirements................. 23
Connecting LG IP Device................................... 23
Overview of LG Smart Web Viewer ................ 25
Configuration of LG Network Camera........... 28
Things to Check before Reporting a Malfunction.......59
Open Source Software Disclaimer................................62
Product Specification ....................................................63
9
LG Network Camera is a more convenient, easy-to-use
network-based surveillance system. As you establish a network
based surveillance environment using LG’s Network Cameras,
you can easily perform various surveillance tasks such as
the video monitoring, recording, configurations and event
management.
With this manual, you can learn how to install and operate LG
Network Camera in a networked environment in details. Any
prior knowledge or familiarity with the network environment
will be of assistance as you try to understand this manual.
If you need further technical assistance, contact our customer
service centers.
• Multi Codec Streaming (H.264, MJPEG)
• Audio supported (G.711/G.726 Full Duplex)
• Ethernet 100Mbps
• Wireless Lan802.11b/g/n
• Digital Input/Output: Input 1port, Output 1port
• Exntended memory using a micro SD card (up to 32GB)
• Pre/Post Alarming feature and recording
• Human Motion Detection
• Night Flash LED (5meter radious)
• AW, AE, Sharpness
Note:
A PIR sensor can detect human motions within 5m radius.
Product Characteristics
10
Device Overview & Features
