LG Fridge-Freezer Manuel utilisateur

Registration

Important Safety Instruction

Identification of Parts

Installation

Starting

Temperature Control

Quick Freeze

Vacation

Self Test

Ice Making

Defrosting

Storing Food

General Information

Lamp Replacement

Cleaning

Trouble Shooting

Precaution

How to Reverse the Doors.

Table of Contents

Introduction

Installation

Operation

Suggestion On

Food storage

Care and

Maintenance

Trouble Shooting

To Reverse the

Doors

Energy-Saving Method

Energy-Saving

Method

Introduction

The model and serial number are found on the rear of

this unit. This number is unique to this unit and not

available to others. You should record requested

information here and retain this guide as a permanent

record of your purchase. Staple your receipt here.

Date of Purchase :

Dealer Purchased From :

Dealer Address :

Dealer Phone No. :

Model No. :

Serial No. :

Important Safety Instruction

This fridge-freezer must be properly installed and

located in accordance with the Installation

Instruction before it is used.

Never unplug your fridge-freezer by pulling on the

power cord. Always grip plug firmly and pull straight out

from the outlet.

When moving your appliance away from the wall,

be careful not to roll over or damage the power

cord.

After your fridge-freezer is in operation, do not

touch the cold surfaces in the freezer compartment,

particularly when hands are damp or wet. Skin may

adhere to these extremely cold surfaces.

Registration

Introduction

Precaution

CAUTION

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not

play with the appliance.

Introduction

This appliance contains a small amount of isobutane

refrigerant (R600a), natural gas with high

environmental compatibility, but it is also

combustible. When transporting and installing the

appliance, care should be taken to ensure that no

parts of the refrigerating circuit are damaged.

Refrigerant squirting out of the pipes could ignite or

cause an eye injury. If a leak is detected, avoid any

naked flames or potential sources of ignition and air

the room in which the appliance is standing for

several minutes.

In order to avoid the creation of a flammable gas air

mixture if a leak in the refrigerating circuit occurs, the size

of the room in which the appliance may be sited depends

on the amount of refrigerant used. The room must be

1m2

in size for every 8g of R600a refrigerant inside the

appliance. The amount of refrigerant in your particular

appliance is shown on the identification plate inside the

appliance.

Never start up an appliance showing any signs of

damage. If in doubt, consult your dealer.

Important Safety Instruction

Keep ventilation openings, in the appliance enclosure

or in the built-in structure, clear of obstruction.

Do not use mechanical devices or other means to

accelerate the defrosting process, other than those

recommended by the manufacturer.

Do not damage the refrigerant circuit.

Do not use electrical appliances inside the food

storage compartments of the appliance, unless they

are of the type recommended by the manufacturer.

The refrigerant and insulation blowing gas used in the

appliance require special disposal procedures. When

disposal, please consult with service agent or a

similarly qualified person.

Introduction

Identification of Parts

Note

Parts,features,and options vary by model.

Your model may not include every option.

Rotatable

Door Basket

Utility Corner(movable)

Bottle Holder

2 Bottle

Door Basket

Leveling Screw

Egg Tray(1 or 2)

Freezer Temperature

Control

Removable

Glass Shelf(2 or 3)

Lamp

Multi-air Flow Duct

Fresh Zone

(Optional)

Fridge Temperature

Control

Vegetable Drawer

Used to keep fruits

and vegetables, etc.

fresh and crisp.

Ice Cube Tray

Storage

Drawer

Removable

Plinth

(optional)

(1 or 2)

Installation

1. Select a good location.

Place your fridge-freezer where it is easy to use.

2. Avoid placing the unit near heat sources,

direct sunlight or moisture.

3. There must be proper air circulation around your

fridge-freezer to keep it operating efficiently.

4. To avoid vibration, the unit must be leveled.

If required, adjust the leveling screws to compensate

for the uneven floor.

The front should be slightly higher than the rear to aid

in door closing.

Leveling screws can be turned easily by tipping the

cabinet slightly.

Turn the leveling screws counterclockwise( ) to

raise the unit, clockwise( ) to lower it.

5. Don’t install this appliance below 5°. It may cause the

debasement of the refrigerator.

6. Install accessories such as ice cube box, etc., in their

proper places.They are packed together to prevent

possible damage during shipment.

7. Connect the power supply cord (or plug) to the outlet.

8. To ensure proper air circulation around the fridge-freezer,

please maintain sufficient space on both the sides as well

as top and maintain at least 2 inches (5 cm) from the rear

wall.

Don't double up with other appliances on the same

outlet.

When your fridge-freezer is installed, allow it 2-3 hours to

stabilize at normal operating temperature prior to filling

it with fresh or frozen foods.

If power plug is disconnected, allow 5 minutes delay

before restarting.

Your fridge-freezer is now ready for use.

Starting

Operation

Your fridge-freezer has two controls that let you regulate

the temperature in the fridge and freezer compartments.

• Initially set the TEMP. CONTROL

at "4". Then adjust the

compartment temperature

according to your desire.

• If you want an inside temperature

slightly less cold or colder, turn the

knob towards WARM or COLD, respectively.

When the surrounding temperature is low, adjust the

TEMP. CONTROL to 'WARM'.

•Freezer temperature control is on the top of the fridge-

freezer. Initially set the Freeze Temp at mid-point. By

pressing the Freezer Temp button, you can adjust the

temperature of the Freezer as indicated by the numbers

of lamps lit.(the setting is composed of five steps,

5 lamps lit indicates coldest.)

•When you starting the Fridge-Freezer or connecting the

power plug to the outlet, temperature setting is

automatically set to the mid-point.

• This function is used when

you want to freeze the foods

quickly. Press the 'QUICK

FREEZE' button once, and

then the quick freeze

operation starts with the

lamp lit.

The quick freeze operation

takes about 3 hours.

When its operation ends,

it automatically returns to the normal state.

If you want to stop the quick freeze operation, press

the 'QUICK FREEZE' button once more, the lamp goes

out, and the quick freeze operation stops and the

refrigerator returns to the normal state.

Temperature Control

Fridge

Freezer

Quick Freeze

TEMP. CONTROL

COLD

WARM

FREEZE TEMP

VACATION QUICK FREEZE

QUICK FREEZE

Operation

This function makes the fridge-freezer

work in a power saving mode which is

useful for when you are away on

holiday, by reducing energey

consumption as much as possible.

Pressing 'VACATION' starts operation

with lamp ON and pressing it again

stops the operation.

For better functioning, you should set

the TEMP. CONTROL to "WARM".

This function allows you to check for operational

problems. If you think you have a problem with your

fridge-freezer, then press the temperature control button:

- If the indicate lights move up or down, then there is no

problem with your fridge-freezer.

- If the indicate lights do not move up or down, then

please leave the power connected and call your nearest

service agent.

• To make ice cubes, fill the

ice tray to the water level

and place it in the freezer.

• If ice cubes are required

fast, press the 'QUICK

FREEZE' button.

• To remove ice cubes,

hold the tray at its ends and twist gently.

Defrosting takes place automatically.

The defrosting water flows down to the evaporating tray

and is evaporated automatically.

Vacation

Self Test

Ice Making

Defrosting

VACATION

To remove ice cubes easily, run water on the tray

before twisting.

Tip

SUGGESTIONS ON FOOD STORAGE

• Do not store food which goes bad easily at low

temperature, such as banana, and melon.

• Allow hot food to cool prior to storing. Placing hot food

in the fridge-freezer could spoil other food, and lead to

higher electric bills.

• When storing the food, use a container with a lid. This

prevents moisture from evaporating, and helps food to

keep its taste and nutrients.

• Do not block air vents with food. Smooth circulation of

cold air keeps fridge-freezer temperature even.

• Do not open the door frequently. Opening the door lets

warm air enter the fridge-freezer, and cause

temperature to rise.

• To adjust the temperature control easily, do not store

food near the temperature control dial.

• Never keep too many foods in door rack, as this may

stop the door from fully closing.

• Do not store bottles in the freezer compartment - they

may break when frozen.

• Do not refreeze food that has been thawed. This causes

loss of taste and nutrition.

Storing Food

Note

If you keep the fridge-freezer in a hot, and humid place,

frequently open its door or put a lot of vegetables in it,

dew may form in it, which has no effect on its

performance.

Remove the dew with dust cloth free from care.

Energy-Saving Method

•Install the fridge in a shady,cool and well-ventilated

place.

•Do not open and close the door frequently if not

necessary.

•Please do not keep the door open for a long time,

close door in the shortest time.

•Allow hot food to cool prior to storing.

•Too much food are not advised to be put in. Enough

space should be kept for cool air circulating freely.

•Do not set the temperature of refrigerator lower than

needed.Do not put the food near the temperature

sensor.

•Food need’t store is not advised to be put in.

•Place the deep-frozen food for thawing intorefrigerator;

they can be used for cooling the refrigerator.

(Applicabe to some models only)

•Clean up the back cover and anti-condensation pipe

termly (once a year) to make sure heat exchange in gear.

(Applicabe to some models only)

•Do not block air vents with food.

( Applicabe to some models only)

Autres manuels pour Fridge-Freezer

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels LG Réfrigérateur

LG LRSPC2301BS Manuel utilisateur

LG GC-B569PMCZ Manuel utilisateur

LG 3828JD8984K Manuel utilisateur

LG LMX21984 Series Mode d’emploi

LG MFL67653437-11 Manuel utilisateur

LG LFC23760ST - Bottom Freezer Refrigerator Manuel utilisateur

LG LSC27914SB Manuel utilisateur

LG GF24BG Manuel utilisateur

LG LFC20760ST - 19.7 cu. ft. Refrigerator Manuel utilisateur

LG LFC22740 Series Instructions de montage

LG LT12CBB Series Manuel utilisateur

LG GB-455BLE Manuel utilisateur

LG SXS Series Manuel utilisateur

LG GL-402 Manuel utilisateur

LG GSL545NSQV Manuel utilisateur

LG LRSC26910 Instructions de montage

LG GT-M5097PZ Manuel utilisateur

LG LMX25964SS.ASTCNB0 Manuel utilisateur

LG LFC21760ST Manuel utilisateur

LG LSC27935SB Mode d’emploi

LG REFRIGERATOR Manuel utilisateur

LG GTF925PZPM Manuel utilisateur

LG LFD22860 Series Manuel

LG 50144815 - LFX23961ST 22.6 cu. ft.... Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
