LG Fridge-Freezer Manuel utilisateur
FRIDGE-FREEZER
User's Guide
Please read this User's Guide carefully before
operating and keep it handy for reference at all times.
FRIGORIFERO CON
CONGELATORE
Istruzioni per l'uso
Nel ringraziarvi per avere acquistato questo
prodotto LG vi raccomandiamo di leggere
attentamente le seguenti istruzioni e di conservare
questo manuale per eventuali consultazioni future.
æY°∂π√ - KATAæYKTH™
√‰ËÁ›Â˜ ÃÚ‹Ûˆ˜
¶·Ú·Î·Ïԇ̠ӷ ‰È·‚¿ÛÂÙ ÚÔÛÂÎÙÈο ÙȘ Ô‰ËÁ›Â˜
ÚÈÓ ı¤ÛÂÙ Û ÏÂÈÙÔ˘Á›· ÙÔ „˘ÁÂ›Ô Î·È
ÊÚÔÓÙ›ÛÙ ӷ ÙȘ ¤¯ÂÙ ‰È·ı¤ÛÈ̘ ·Ó¿ ¿Û· ÛÙÈÁÌ‹.
3
Introduction
Installation
Operation
Suggestion On
Food storage
Care and
Maintenance
Trouble Shooting
Table of Contents
Registration
Important Safety Instruction
Identification of Parts
Installation
Starting
Temperature Control
Miracle Zone
Super Freezer
Vacation
Self Test
Lock
Moving Basket
Door Alarm
Ice Making
Defrosting
Water Dispenser
Folding Shelf
Wine Rack
Storing Food
General Information
Lamp Replacement
To Reverse the Doors
Cleaning
Trouble Shooting
4
4
16
17
17
18
20
21
21
22
22
22
23
23
23
24
26
26
27
29
30
30
31
33
ww•This product is exclusive use at 230V/50Hz.
•You should purchase transformer of more than 2.0KVA when you want
to use it at the 110V area.
•You can't use it anywhere except 50Hz area.
Introduction
Introduction
Registration
The model and serial number are found on the rear of
this unit. This number is unique to this unit and not
available to others. You should record requested
information here and retain this guide as a permanent
record of your purchase. Staple your receipt here.
Date of Purchase :
Dealer Purchased From :
Dealer Address :
Dealer Phone No. :
Model No. :
Serial No. :
Important Safety Instruction
To avoid any risk of personal injury, material
damage or incorrect use of the appliance, be sure to
observe the following safety precautions. (After
reading these owner’s instructions, please keep
them in a safe place for reference). Remember to
hand them over to any subsequent owner.
Indicates that
a danger of
death or
serious injury
exists
Warning
ww
4
Indicates that
a risk of
personal
injury or
material
damage exists
Caution
ww
5
Introduction
Important Safety Instruction
To reduce the risk of fire, electric shock, or injury to
persons when using your product, basic safety precautions
should be followed, including the following. Read all
instructions before using this appliance.
The dedicated outlet should be used.
• Using several devices at one outlet may cause fire.
• The electric leakage breaker may
damage food and the dispenser
may be leaked.
1. When connecting the power
ww
WARNING
Do not allow the power plug to face upward or to
be squeezed at the back of the
fridge-freezer.
Water may be flown into or the
plug may be damaged, which
causes fire or electric shock.
Do not allow the power cord
bent or pressed by the heavy
object to be damaged.
It may damage the power cord to
cause fire or electric shock.
Do not extend or modify the length
of the power plug.
It causes electric shock or fire by the
electric damage of the power cord
or others.
Unplug the power plug when cleaning, handling or
replacing the interior lamp of the fridge-freezer.
• It may cause electric shock or injury.
• When replacing the interior lamp
of the fridge-freezer, make sure
that the rubber ring for preventing
the electric spark within the
socket is not taken off.
Introduction
6
Important Safety Instruction
Do not pull out the cord or touch the power plug
with wet hands.
• It may cause electric shock or
injury.
Remove water or dust from the power plug and
insert it with the ends of the
pins securely connected.
Dust, water or unstable connection
may fire or electric shock.
Make sure of grounding.
The incorrect grounding may cause
breakdown and electric shock.
Ground
Wire
Copper
Flat
More than
30 inches
When the power cord or the power plug is
damaged or the holes of the outlet are loosed, do
not use them.
It may cause electric shock or short
circuit to make fire.
Do not place the heavy object or the dangerous
object (container with liquid) on
the fridge-freezer.
It may be dropped to cause injury,
fire or electric shock when opening
or closing the door.
2. When using the fridge-freezer
Do not cling to the door or the shelves of the door
or the home bar of the freezer or
the cool chamber.
It may make the fridge-freezer fallen
down or damage the hands.
Especially, do not allow the children
to do the above.
7
Introduction
Important Safety Instruction
Do not install the fridge-freezer in the wet place or
the place which water or rain
splashes.
Deterioration of insulation of
electric parts may cause electric
leakage.
Do not use or store inflammable materials ether,
benzene, alcohol, medicine, LP
gas, spray or cosmetics near or
in the fridge-freezer.
It may cause explosion or fire.
Benzene
Ether
Thinner
Do not place the lit candle within the fridge-freezer
to deodorize.
It may cause explosion or fire.
Do not store the medicine or the academic
materials at the fridge-freezer.
When the material with the strict
temperature control is stored, it may
be deteriorated or it may make an
unexpected reaction to cause any
risk.
The Academic
Medicine
The Medicine
Do not use the combustible spray near the fridge-
freezer.
It may cause fire.
Introduction
8
Important Safety Instruction
Avoid the heating devices.
It may cause fire.
Do not place flower vase, cup,
cosmetics, medicine or any
container with water on the
fridge-freezer.
It may cause fire, electric shock or
injury by dropping down.
Use the submerged fridge-freezer after checking it.
It may cause electric shock or fire.
When gas is leaked, do not touch the fridge-freezer
or the outlet and ventilate the room immediately.
• The explosion by spark may cause fire or burn.
• Because this fridge-freezer uses natural gas (isobutene,
R600a) as the environment-
friendly refrigerant, even a small
amount (80~90g) is combustible.
When the gas is leaked by the
severe damage during delivering,
installing or using the fridge-
freezer, any spark may cause fire
or burn.
Do not spray water at the
outside or the inside of the
fridge-freezer or do not clean it
with benzene or thinner.
Deterioration of insulation of
electric parts may cause electric
shock or fire.
ThinnerThinner
9
Introduction
Important Safety Instruction
When any strange smell or smoke is detected from
the fridge-freezer, disconnect the power plug
immediately and contact to the
service center.
It may cause fire.
Service
center
Do not allow any person except the qualified
engineer to disassemble, repair
or alter the fridge-freezer.
It may cause injury, electric shock or
fire.
Do not use the fridge-freezer for non-domestic
purpose (storing medicine or testing material,
using at the ship, etc.).
It may cause an unexpected risk
such as fire, electric shock,
deterioration of stored material or
chemical reaction.
When disposing the fridge-freezer, remove the
packing materials from the door.
It may cause to lock out the child.
Install the fridge-freezer on the solid and level
floor.
Installing it on the unstable place
may cause death by falling down
the fridge-freezer when opening or
closing the door.
Introduction
10
Important Safety Instruction
Do not insert the hands or the
metal stick into the exit of cool
air, the cover, the bottom of the
fridge-freezer, the heatproof grill
(exhaust hole) at the backside.
It may cause electric shock or injury.
When you want to dispose the fridge-freezer,
contact to the down-block office.
When you want to dispose the large
living waste such as electric home
appliance and furniture, you’d
better contact the local down-block
office.
Down-block
office
Do not touch food or containers
at the freezer with wet hands.
It may cause frostbite.
Wait for 5 minutes or longer
when reconnecting the plug.
It may cause the operation of the
freezer to fail.
After
5minutes
Do not put bottle in the freezer.
It may freeze the contents to break
the bottle to cause injury.
Pull out the power plug not by
grasping the cord but the plug
of its end.
It may cause electric shock or short
circuit to fire.
Violating this direction may cause injury or damage
house or furniture. Always be careful, please.
ww CAUTION
