FRIDGE

User's Guide

Please read this User's Guide carefully before

operating and keep it handy for reference at all times.

Introduction

Operation

Suggestion On

Food storage

Care and

Maintenance

Trouble Shooting

Table of Contents

Registration

Important Safety Instruction

Identification of Parts

Temperature Control

Display Panel For Temperature Control

Power / 11

How to adjust the temperature

in the re rigerator compartment / 11

Super Cooling / 12

Sel Test / 12

Door Alarm / 12

Low-temperature catalyst deodorization system

(removing the odor)

How to store food properly

Storing Food

General Information

How to disassemble each component

Cleaning

Trouble Shooting

* Refer to Installation Insturction for details.

Introduction

Registration

The model and serial number are found on the rear of

this unit. This number is unique to this unit and not

available to others. You should record requested

information here and retain this guide as a permanent

record of your purchase. Staple your receipt here.

Date of Purchase :

Dealer Purchased From :

Dealer Address :

Dealer Phone No. :

Model No. :

Serial No. :

Important Safety Instruction

To avoid any risk of personal injury, material

damage or incorrect use of the appliance, be sure to

observe the following safety precautions. (After

reading these owner’s instructions, please keep

them in a safe place for reference). Remember to

hand them over to any subsequent owner.

Indicates that a

danger of death

or serious injury

exists

Warning

Indicates that a

risk of personal

injury or

material

damage exists

Caution

Introduction

Important Safety Instruction

ww Warning

Precaution •This fridge-freezer must be properly installed and

located in accordance with the Installation Instruction

before it is used.

•Before you install this fridge-freezer reference to

installation manual.

•Never unplug your fridge-freezer by pulling on the

power cord. Always grip plug firmly and pull straight

out from the outlet.

•When moving your appliance away from the wall, be

careful not to roll over or damage the power cord.

•After your fridge-freezer is in operation, do not touch

the cold surfaces in the freezer compartment,

particularly when hands are damp or wet. Skin may

adhere to these extremely cold surfaces.

•Pull out the power plug prior to cleaning the fridge-

freezer.

Never damage, serverely bend, pull out, or twist the

power cord because power cord damage may cause a

fire or electronic shock.

Never place glass products in the freezer because they

may be broken when their inner contents are frozen.

•Do not directly spray water inside or outside the

fridge/freezer.

There is a risk of explosion or fire.

•Do not insert the power plug with wet hands.

You may receive an electric shock.

•Do not install the fridge/freezer in a damp place, where

it could be splashed with water.

Incorrect insulation of the electrical parts may cause an

electric shock or fire.

Introduction

Important Safety Instruction

•Do not disassemble, repair or alter the appliance. It

may cause fire or abnormal operations, which may lead

to injury.

•Pull the power plug out of the socket before replacing

the interior light in the refrigerator.

Otherwise, there is a risk of electric shock.

•

If possible, connect the fridge-freezer to its own

individual electrical outlet to prevent it and other

appliances or household lights from causing an overload.

The supply plug of the refrigerator-freezer should be

placed in easy accessible position for quick disconnection

in emergency.

Accessibility of

Supply Plug

It will cause electric shock or fire.

Do not modify or

extend the Power

Cord length

If the supply cord is damaged, it must be replaced by the

manufacturer or its service agent or a similarly qualified

person in order to avoid a hazard.

Don't store or use gasoline or other flammable vapors

and liquids in the vicinity of this or any other appliance.

In the event of an electric short circuit, grounding

(earthing) reduces the risk of electric shock by providing

an escape wire for the electric current. In order to

prevent possible electric shock, this appliance must be

grounded. Improper use of the grounding plug can result

in an electric shock. Consult a qualified electrician or

service person if the grounding instructions are not

completely understood, or if you have doubts on

whether the appliance is properly grounded.

Risk of child entrapment.

Before you throw away your old refrigerator or freezer:

Take off the doors.

Leave the shelves in place so that children may not

easily climb inside.

Supply Cord

Replacement

Danger

Don't store

Grounding

(Earthing)

Introduction

Important Safety Instruction

ww Warning ww Keep ventilation openings, in the appliance

enclosure or in the built-in structure, clear of

obstruction.

ww Do not use mechanical devices or other means to

accelerate the defrosting process, other than those

recommended by the manufacturer.

ww Do not damage the refrigerant circuit.

ww Do not use electrical appliances inside the food

storage compartments of the appliance, unless they

are of the type recommended by the manufacturer.

ww The refrigerant and insulation blowing gas used in

the appliance require special disposal procedures.

When disposal, please consult with a service agent

or similarly qualified person.

This appliance contains a small amount of isobutane

refrigerant (R600a), natural gas with high

environmental compatibility, but it is also

combustible. When transporting and installing the

appliance, care should be taken to ensure that no

parts of the refrigerating circuit are damaged.

Refrigerant squirting out of the pipes could ignite

or cause an eye injury. If a leak is detected, avoid

any naked flames or potential sources of ignition

and air the room in which the appliance is standing

for several minutes.

In order to avoid the creation of a flammable gas air

mixture if a leak in the refrigerating circuit occurs, the

size of the room in which the appliance may be sited

depends on the amount of refrigerant used. The room

must be 1m2in size for every 8g of R600a refrigerant

inside the appliance. The amount of refrigerant in your

particular appliance is shown on the identification plate

inside the appliance.

Never start up an appliance showing any signs of

damage. If in doubt, consult your dealer.

Introduction

Important Safety Instruction

ww Caution •If the wall socket is loose, do not insert the power

plug.

It may cause electric shock or fire.

•Never unplug your refrigerator by pulling on the

power cord. Always grip plug firmly and pull it

straight out from the outlet.

You may disconnect a wire and cause a short circuit.

•Do not use a wet or damp cloth when cleaning the

plug. Remove any foreign matter from the power

plug pins.

Otherwise, there is a risk of fire.

•Do not put your hands into the bottom area of

the appliance.

Any Sharp edges may cause personal injury..

•After unplugging the appliance, wait for at least

five minutes before plugging it again to the wall

socket.

Abnormal operation of the freezer may cause material

damage.

•If the appliance is not to be used for a long time,

pull out the power plug.

Any deterioration in the insulation may cause fire.

•Do not let children touch or play with the control

panel on the front of the appliance.

•The refrigerant used in fridge/freezer and the

gases in the insulation material require special

disposal procedures. Ensure that none of the pipes

on the back of the appliances are damaged prior

to disposal.

Introduction

Identification of Parts

Lamp

Dairy Corner

Egg Tray

Door Basket

Bottle Guide

2ℓℓBottle

Door Basket

Removable

Glass Shelf

Bottle Shelf

Leveling Screw

Vegetable Drawer

Used to keep ruits and

vegetables crisp.

Snack Corner

Multi-Air Flow Duct

Temperature Control

Display Panel For

Temperature Control

Your fridge has controls that let you regulate the

temperature in the fridge compartments.

Adjusting the

temperatures and

functions

Operation

POWER

3SECS

REF.TEMP.SUPERCOOL

Display Panel

Super Cooling Power

Temperature Adjustment Button

or Re rigerator Compartment

Operation

How to adjust the

temperature in the

refrigerator

compartment

• The initial Temperature of the Refrigerator

Compartment is 0°C and 6°C respectively.

You can now adjust the temperature of the

compartments as you want.

Power • If you push button more than 3 seconds

you can switch on or off the Refrigerator.

• When you press the temperature

control button, the temperature

of the Refrigerator part is change

by 1 degree.

Note

The actual inner temperature varies depending on the

food status, as the indicated setting temperature is a

target temperature, not actual temperature within

refrigerator.

Refrigeration function is weak in the initial time. Please

adjust temperature as above after using refrigerator for

minimum 2~3 days.

POWER

3SECS

REF.TEMP.
