LG M2362D-PM Manuel utilisateur

www.lg.com

OWNER’S MANUAL

MONITOR TV

MONITOR TV MODELS

Please read this manual carefully before operating

your set and retain it for future reference.

ENGLISH

M2362D

PREPARATION

FRONT PANEL CONTROLS

■

This is a simp ified representation of the front pane . The image shown may be somewhat different from your

set.

INPUT

Button

INPUT

VOL

Button

OK(ENTER)

Button

VOLUME

Buttons

PROGRAMME

(CHANNEL)

Buttons

Power

Button

Headphone

Jack

IR receiver

(Remote contro er

receiver)

LLiigghhtt SSeennssoorr

This is ens for ight sensor

se ect outside uminance,

when setting AUTO

BRIGHT ON.

PPoowweerr IInnddiiccaattoorr

i uminates b ue when the

set is switched on.

Note:You can adjust

Power indicator in the

OPTION menu.

PREPARATION

BACK PANEL INFORMATION

■

This is a simp ified representation of the back pane . The image shown may be somewhat different from your

set.

AV 1 AV 2

AC IN

VIDEO

COMPONENT

AV-IN

VIDEO

S-VIDEO

AUDIO

RS-232C IN

(CONTROL & SERVICE)

SERVICE

ONLY

RGB IN (PC)

DVI-D IN (PC)

HDMI IN

OPTICAL

DIGITAL

AUDIO OUT

AC IN

AUDIO IN

(RGB/DVI)

ANTENNA/

CABLE IN

AUDIO

(MONO)

910 11

87 12

3 4

PPoowweerr CCoorrdd SSoocckkeett

This set operates on AC power. The vo tage is indicated

on the Specifications page. Never attempt to operate

the set on DC power.

HHDDMMII IInnppuutt

High definition inputs. These two inputs accept TV

Video, not PC Video. They a so accept TV Video from a

DVI connection when using an adapter. The HDMI

inputs support video and audio. When using an adapter

for DVI, they on y accept video.

DDVVII--DD IInnppuutt

Digita PC input.

RRSS--223322CC IINN ((CCOONNTTRROOLL && SSEERRVVIICCEE)) PPOORRTT

Seria port used for externa contro or service.

RRGGBB IINNPPUUTT ((PPCC))

Ana og PC input. A so known as VGA.

SS--VViiddeeoo IInnppuutt

Standard definition (480i), but better qua ity than

standard A/V input.

SSEERRVVIICCEE OONNLLYY PPOORRTT

RRGGBB//DDVVII AAuuddiioo IInnppuutt

This is the audio input for the RGB and DVI-D video

inputs.

OOppttiiccaa DDiiggiittaa AAuuddiioo OOuutt

Use this to export audio to an externa amp ifer.

CCoommppoonneenntt IInnppuutt

High definition ana og input.

AAuuddiioo//VViiddeeoo IInnppuutt

Standard definition input.

AAnntteennnnaa IInnppuutt

Connect over-the-air or cab e signa s to this jack.

PREPARATION

STAND INSTALLATION

■

The image shown may be somewhat different from your set.

Carefu y p ace the product screen side down on a

cushioned surface that wi protect product and

screen from damage.

Insert the SSttaanndd BBaasseeinto the product.

Turn the SSttaanndd BBaassee LLoocckkthrough 90°to fix the stand base to the stand body.

SSttaanndd BBaassee LLoocckk

<<LLoocckkeedd>>

4 5

SSttaanndd BBaassee

PREPARATION

DETACHING STAND

■

The image shown may be somewhat different from your monitor.

P ace the set screen side down on a cushion or

soft c oth.

Detach the monitor to the SSttaanndd BBaasseeby

turning the screw to the eft.

Turn the SSttaanndd BBaassee LLoocckkthrough 90°to separate the stand base from the stand body.

Pushing LLaattcchhinside, Take the stand base from stand body.

LLaattcchh

SSttaanndd BBaassee

PREPARATION

DETACHING STAND BODY

1. Remove the screw 2 point.

2. Pu the stand body.

■

The image shown may be somewhat different from your set.

■

Remove the Stand Body in the same way as the fo owing when using it as a Wa Hook.

PREPARATION

DESKTOP PEDESTAL INSTALLATION

For proper ventilation, allow a clearance of 10 cm on eac side and from t e wall.

WALL MOUNT: HORIZONTAL INSTALLATION

For proper ventilation, allow a clearance of 10 cm on eac side and from t e wall. Follow t e instructions includ-

ed wit t e wall mount.

1100 ccmm

1100 ccmm1100 ccmm

1100 ccmm

PREPARATION

POSITIONING YOUR DISPLAY

■

T e image s own may be somew at different from your set.

Adjust t e position of t e panel in various ways for maximum comfort.

•• TTiilltt rraannggee

LOCATION

Position your set so t at no brig t lig t or sunlig t falls directly onto t e screen. Care s ould be taken not to expose

t e set to any unnecessary vibration, moisture, dust or eat. Also, ensure t at t e set is placed in a position to allow a

free flow of air. Do not cover t e ventilation openings on t e back cover.

If you intend to mount t e set to a wall, attac t e wall mounting interface (optional parts) to t e back of t e set.

W en you install t e set using t e wall mounting interface (optional parts), attac it carefully so it will not drop.

- Be sure to use screws and a wall mount t at meet VESA standards.

- Using screws longer t an t ose recommended mig t damage t e product.

- Using screws t at do not meet VESA standards mig t eit er damage t e product or result in it coming away from t e

wall. We will not be eld responsible for any damage resulting from failure to follow t ese instructions.

< Screw Mounting Interface Dimension >

••

100 mm x 100 mm ole spacing

- Wall mount interface(LG) : RW120

WWaarrnniinngg::

W en adjusting t e angle of t e screen, do not put

your finger(s)in between t e ead of t e monitor

and t e stand body. You can urt your finger(s).

RW120

-5

PREPARATION

KENSINGTON SECURITY SYSTEM

- The product is equipped with a Kensington Security System connector on the back pane . Connect the

Kensington Security System cab e as shown be ow.

- For detai ed insta ation and use of the Kensington Security System, refer to the user’s guide provided with the

Kensington Security System.

For further information, contact hhttttpp::////wwwwww..kkeennssiinnggttoonn..ccoomm, the internet homepage of the Kensington

company. Kensington se s security systems for expensive e ectronic equipment such as notebook PCs and LCD

projectors.

NOTE

- The Kensington Security System is an optiona accessory avai ab e at most e ectronics stores.

NOTES

a. If the product fee s co d to the touch, there may be a sma “f icker” when it is turned on.

This is norma , there is nothing wrong with product.

b. Some minute dot defects may be visib e on the screen, appearing as tiny red, green, or b ue spots. However, they

have no adverse effect on the monitor's performance.

c. Avoid touching the LCD screen or ho ding your finger(s) against it for ong periods of time.

AV 1 AV 2

AC IN

ANTENNA/

CABLE IN

AV 1 AV 2

AC IN

ANTENNA/

CABLE IN

EXTERNAL EQUIPMENT SETUP

■For optimum picture qua ity, adjust antenna direction.

■An antenna cab e and converter are not supp ied.

■To prevent equipment damage, never p ug in any power cords unti you have finished connecting a equipment.

Mu ti-fami y Dwe ings/Apartments

(Connect to wa antenna socket)

Sing e-fami y Dwe ings /Houses

(Connect to wa jack for outdoor antenna)

Outdoor

Antenna

(VHF, UHF)

Antenna

Socket

RF Coaxia Wire (75 )

ANTENNA CONNECTION

Antenna

UHF

VHF

■In poor signa areas, to get better picture qua ity, insta a signa amp ifier to the antenna as shown above.

■If signa needs to be sp it for two TVs, use an antenna signa sp itter for connection.

Signa

Amp ifier
