OWNER’S MANUAL

GLASSES FREE CINEMA

3D MONITOR

D2000N

Please read this manual carefully before operating

your set and retain it for future reference.

GLASSES FREE CINEMA 3D MONITOR MODEL

ENGLISH

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 ASSEMBLINGAND

PREPARING

3 Unpacking

4 Partsandbuttons

6 LiftingandmovingtheMonitorset

6 SettinguptheMonitorset

6 - AttachingtheStandBase

7 - DetachingtheStandBaseandBody

7 - Mountingonatable

9 - Mountingonawall

11 USINGTHEMONITORSET

11 ConnectingtoaPC

11 - DVI-Dconnection

11 - HDMIconnection

12 ConnectingtoaPC(3DMode)

12 - DVI-Dconnection

12 - HDMIconnection

14 CUSTOMIZINGSETTINGS

14 AccessingTheMainMenus

15 CustomizingSettings

15 - MenuSettings

16 - SUPERENERGYSAVINGSettings

17 - Thingsyouneedtocheckbeforeinstall-

ingTriDef3D

17 - 3DSettings(Supportedonlyin3Dmode

—PCinput)

18 TROUBLESHOOTING

20 TROUBLESHOOTINGWHEN

USING3DMODE

21 SPECIFICATIONS

22 PresetModes(Resolution)

22 HDMITIMING

22 Indicator

23 SAFETYPRECAUTIONS

23 - Precautionstotakewhenviewing3D

images

23 - Precautionstotakewhenviewing3D

images

24 PROPERPOSTURE

24 ProperpostureforusingtheMonitorset.

24 Precautionstotakewhenviewing3Dim-

ages

25 LICENSES

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

 Usershoulduseshieldedsignalinterfacecables(RGBcable/DVI-Dcable)withferritecoresto

maintainstandardcompliancefortheproduct.

CAUTION

NOTE

StandBase

PowerCord

CD(Owner'sManual)/

Card

TriDef3DsoftwareProgramCD/

QuickInstallationGuide

DVI-DCable USBCable

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

HDMI-IN

AC-IN

DVI-D

PowerIndicator

 LightingOn:Turnedon

 LightingOff:Turnedoff

Connectionpanel(Seep.11)

Button(Seep.14)

(PowerButton)

Face-trackingcamera

ENG

ENGLISH

ASSEMBLING AND PREPARING

Button(Seep.14)

Button Description

MENU Accessesthemainmenus.(Seep.15)

OSDLOCKED/

UNLOCKED

Thisfunctionallowsyoutolockthecurrentcontrolsettings,so

thattheycannotbeinadvertentlychanged.

PressandholdtheMENUbuttonforseveralseconds.

Themessage"OSDLOCKED"shouldappear.

YoucanunlocktheOSDcontrolsatanytimebypushing

theMENUbuttonforseveralseconds.Themessage"OSD

UNLOCKED"shouldappear.

SUPERENERGY

SAVINGButton

UsethisbuttontoenterSUPERENERGYSAVINGmenu.Formoreinformation.(Seep.16)

3D 3DMode[3D/2D].(Seep.17)

INPUT Youcanchoosetheinputsignal.



Whentwoinputsignalsareatleastareconnected,youcanselecttheinputsignal(DVI/

HDMI)youwant.



Whenonlyonesignalisconnected,itisautomaticallydetected.Thedefaultsettingis

DVI-D.

EXIT ExittheOSD(OnScreenDisplay).

(PowerButton) Turnsthepoweronoroff.

PowerIndicator Thepowerindicatorstaysblueifthedisplayisrunning

properly(OnMode).IfthedisplayisinSleepMode,thepower

indicatorblinksblue.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Setting up the Monitor set

Attaching the Stand Base

1Place the Monitor set with the screen side

down on a flat and cushioned surface.

Lay a foam mat or soft protective cloth

on the surface to protect the screen from

damage.

CAUTION

2Attach the Stand Base and then tighten the

screw to the right with a Coin.

Stand Base

Lifting and moving the

Monitor set

Please heed the following information when

moving the monitor.

Avoid touching the screen at all times, as this

may result in damage to the screen or pixels .

CAUTION

yIt is recommended to move the Monitor set in

the box or packing material that the Monitor

set originally came in.

yBefore moving or lifting the Monitor set,

disconnect the power cord and all cables.

yHold the top and bottom of the Monitor

set frame firmly. Make sure not to hold the

transparent part.

yWhen holding the Monitor set, the screen

should face away from you to prevent the

screen from scratches.

yWhen transporting the Monitor set, do not

expose the Monitor set to jolts or excessive

vibration.

yWhen transporting the Monitor set, keep the

Monitor set upright, never turn the Monitor

set on its side, or tilt towards the left or right.

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Thisillustrationdepictsthegeneralmodelof

connection.Yourmonitormaydifferfromthe

itemsshowninthepicture.

 Donotcarrytheproductupsidedownholding

onlythestandbase.Theproductmayfall

andgetdamagedorinjureyourfoot.

CAUTION

DetachingtheStandBaseandBody

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

2 PullouttheStandBaseandStandBodyfrom

theMonitorset.

3 TurnthescrewtotheleftwithaCoin,andthen

pullouttheStandBasefromtheStandBody.

Mountingonatable

1 LiftandtilttheMonitorsetintoitsupright

positiononatable.

Leavea10cm(minimum)spacefromthewall

forproperventilation.

2 ConnectthePowerCordtoawalloutlet.

3 Press (Power)buttononthefrontswitch

paneltoturnthepoweron.

10 cm

Unplugthepowercordbeforemovingthe

Monitortoanotherlocation.Otherwiseelectric

shockmayoccur.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

Whenyouadjusttheangle,donotholdthe

bottomoftheMonitorsetframeasshownon

thefollowingillustration,asmayinjureyour

fingers.

Donottouchorpressthescreenwhen

adjustingtheangleofthemonitor.

WARNING

Tiltfrom+15to-5degreesupordowntoadjust

theangleoftheMonitorsettosuityourview.

NOTE

Front Rear

15- 5

UsingtheKensingtonsecuritysystem

TheKensingtonsecuritysystemconnectoris

locatedatthebackoftheMonitorset.Formore

informationofinstallationandusing,refertothe

manualsuppliedwiththeKensingtonsecurity

systemorvisit

http://www.kensington.com

ConnecttheKensingtonsecuritysystemcable

betweentheMonitorsetandatable.

TheKensingtonsecuritysystemisoptional.

Youcanobtainitfrommostelectronicsstores.

NOTE

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonawall

Forproperventilation,allowaclearanceof10cm

oneachsideandfromthewall.Detailed

instructionsareavailablefromyourdealer,seethe

optionalTiltWallMountingBracketInstallationand

SetupGuide.

IfyouintendtomounttheMonitorsettoawall,

attachtheWallmountinginterface(optionalparts)

tothebackoftheset.

WhenyouinstalltheMonitorsetusingthewall

mountinginterface(optionalparts),attachit

carefullysoitwillnotdrop.

1 Please,Usethescrewandwallmount

interfaceinaccordancewithVESAStandards.

2 Ifyouusescrewlongerthanstandard,the

monitormightbedamagedinternally.

3 Ifyouuseimproperscrew,theproductmightbe

damagedanddropfrommountedposition.In

thiscase,LGElectronicsisnotresponsiblefor

damage.

4 VESAcompatibleonlywithrespecttoscrew

mountinginterfacedimensionsandmounting

screwspecifications.

10 cm

5 PleaseuseVESAstandardasbelow.

 784.8mm(30.9inch)andunder

*WallMountPadThickness:2.6mm

*Screw:Φ4.0mmxPitch0.7mmx

Length10mm

 787.4mm(31.0inch)andabove

*PleaseuseVESAstandardwallmountpad

andscrews.

Model D2000N

VESA(AxB) 75x75

Standardscrew M4

Numberofscrews 4

Wallmountbracket

(optional)

RW120

 VESA(AxB)

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Disconnectthepowercordfirst,andthen

moveorinstalltheMonitorset.Otherwise

electricshockmayoccur.

 IfyouinstalltheMonitorsetonaceilingor

slantedwall,itmayfallandresultinsevere

injury.

 UseonlyanauthorizedLGwallmount

andcontactthelocaldealerorqualified

personnel.

 Donotovertightenthescrewsasthismay

causedamagetotheMonitorsetandvoid

yourwarranty.

 Useonlyscrewsandwallmountsthat

meettheVESAstandard.Anydamages

orinjuriesbymisuseorusinganimproper

accessoryarenotcoveredbythewarranty.

 UsethescrewsthatarelistedontheVESA

standardscrewspecifications.

 Thewallmountkitwillincludeaninstallation

manualandnecessaryparts.

 Thewallmountbracketisoptional.Youcan

obtainadditionalaccessoriesfromyourlocal

dealer.

 Thelengthofscrewsmaydifferdepending

onthewallmount.Besuretousetheproper

length.

 Formoreinformation,refertothe

instructionssuppliedwiththewallmount.

CAUTION

NOTE
