LG 32MR50C-B Manuel utilisateur

* LG LED Monitor applies LCD screen with LED backlights.

Please read this manual carefully before operating your set and retain it for future reference.

www.lg.com

Owner’s Manual

LED LCD MONITOR

(LED Monitor*)

32MR50C

32MR50CS

32MR51CA

32MR51CS

32BR50C

Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per LG 32MR50C-B o

cerca il tuo prodotto tra le migliori offerte di Monitor

ENGLISH

TABLE OF CONTENTS

USING THE MONITOR....................................................................... 11

-Connecting to a PC ...........................................................................................................12

D-SUB Connection............................................................................................................12

HDMI Connection .............................................................................................................12

-Connecting AV Devices .....................................................................................................13

HDMI Connection .............................................................................................................13

-Connecting Peripherals ....................................................................................................13

Headphones Connection ..................................................................................................13

ASSEMBLING AND PREPARING ......................................................... 4

-Installing............................................................................................................................5

Moving and Lifting the Monitor .........................................................................................5

Installing on a Table ...........................................................................................................6

Using the Kensington Lock .................................................................................................6

Installing on the Wall .........................................................................................................7

-Product Description............................................................................................................9

How to Use the Joystick Button........................................................................................10

Adjusting the Angle .........................................................................................................10

-Supported Software.........................................................................................................11

ENGLISH

USER SETTINGS ............................................................................... 14

-Activating the Main Menu................................................................................................14

Main Menu Features.........................................................................................................14

Menu Settings..................................................................................................................15

[Quick Settings]................................................................................................................15

[Input]..............................................................................................................................16

[Picture]...........................................................................................................................16

[General]..........................................................................................................................19

PRODUCT SPECIFICATION................................................................ 20

-Support Mode..................................................................................................................22

(Preset Mode, D-SUB/ HDMI)............................................................................................22

HDMI Timing (Video)........................................................................................................23

TROUBLESHOOTING ........................................................................ 24

LICENSE ........................................................................................... 26

BEEP GUIDE ..................................................................................... 27

ENGLISH

ASSEMBLING AND PREPARING

CAUTION

•Always use genuine LG components to ensure safety and product performance.

•The product warranty will not cover damage or injury caused by the use of unauthorized components.

•It is recommended that use the supplied components.

•If you use generic cables not certified by LG, the screen may not display or there may be image noises.

•The product figures and screen displays used in this manual are examples to help consumers use the product

and may differ from the actual product.

•Do not apply foreign substances (oils, lubricants, etc.) to the screw parts when assembling the product.

(Doing so may damage the product.)

•Applying excessive force when tightening screws may cause damage to the monitor. Damage caused in this

way will not be covered by the product warranty.

•Do not carry the monitor upside down by just holding the base. This may cause the monitor to fall off the

stand and could result in personal injury.

•When lifting or moving the monitor, do not touch the monitor screen.The force applied to the monitor screen

may cause damage to it.

NOTE

•The components may look different from those illustrated here.

•Without prior notice, all product information and specifications contained in this manual are subject to

change to improve the performance of the product.

•To purchase optional accessories, visit an electronics store or an online shopping site, or contact the retailer

from which you purchased the product.

•The power cord provided may differ depending upon the region.

ENGLISH

Installing

Moving and Lifting the Monitor

When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or

damaged and to ensure safe transportation, regardless of its shape or size.

•Place the monitor in the original box or packing material before attempting to move it.

•Before moving or lifting the monitor, disconnect the power cord and all other cables.

•Hold the bottom and side of the monitor frame firmly. Do not hold the panel itself.

•When holding the monitor, the screen should face away from you to prevent it from being scratched.

•When transporting the monitor, do not expose the monitor to shock or excessive vibration.

•When moving the monitor, keep it upright and never turn the monitor on its side or tilt it sideways.

CAUTION

•Avoid touching the monitor screen as much as possible.

-This may result in damage to the screen or some of the pixels used to create images.

ENGLISH

Installing on a Table

•Lift the monitor and place it on the table in an upright position. Place the monitor at least 100mm

(3.9inches) away from the wall to ensure sufficient ventilation.

: 100mm (3.9inches)

CAUTION

•Unplug the power cord before moving or installing the monitor. There is risk of electric shock.

•Make sure to use the power cord that is provided in the product package and connect it to a grounded power

outlet.

•If you need another power cord, please contact your local dealer or the nearest retail store.

Using the Kensington Lock

For more information on installation and usage, refer to the Kensington lock owner’s manual or visit the website

at http://www.kensington.com.

Connect the monitor to a table using the Kensington security system cable.

NOTE

•The Kensington security system is optional. You can obtain optional accessories from most electronics stores.

ENGLISH

Installing on the Wall

This monitor meets the specifications for the wall mount plate or other compatible devices.

Install the monitor at least 100mm (3.9inches) away from the wall and leave about 100mm (3.9inches)

of space at each side of the monitor to ensure sufficient ventilation. Detailed installation instructions can be

obtained from your local retail store. Alternatively, please refer to the manual for how to install and set up a

tilting wall mounting bracket.

: 100mm (3.9inches)

Installing the Wall Mount Plate

To install the monitor to a wall, attach a wall mounting bracket (optional) to the back of the monitor.

Make sure that the wall mounting bracket is securely fixed to the monitor and to the wall.

Wall Mount (mm) 100 x 100 (3.9x3.9inches)

Standard screw M4 x L10

Number of screws 4

Wall Mount Plate (Optional) LSW149

ENGLISH

NOTE

•Use the screws specified byVESA standards.

•The wall mount kit includes the installation guide and all necessary parts.

•The wall mounting bracket is optional.You can obtain optional accessories from your local dealer.

•The length of the screw may differ for each wall mounting bracket. If you use screws longer than the standard

length, it may damage the inside of the product.

•For more information, please refer to the user manual for the wall mounting bracket.

•Be careful not to apply too much force while mounting the wall mount plate as it may cause damage to the

screen.

•Remove the stand before installing the monitor on a wall mount by performing the stand attachment in

reverse.

CAUTION

•Unplug the power cord before moving or installing the monitor to avoid electric shock.

•Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could

lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel.

•To prevent injury, this apparatus must be securely attached to the wall in accordance with the installation

instructions.

•Applying excessive force when tightening screws may cause damage to the monitor. Damage caused in this

way will not be covered by the product warranty.

•Use the wall mounting bracket and screws that conform toVESA standards. Damage caused by the use or

misuse of inappropriate components will not be covered by the product warranty.

•When measured from the back of the monitor, the length of each installed screw must be 8mm (0.3inches)

or less.

ENGLISH

: Wall Mount Plate

: Back of the Monitor

: Standard screw

: Max. 8mm (0.3inches)

Product Description

A: Joystick Button

ENGLISH

How to Use the Joystick Button

You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/

down with your finger.

Basic Functions

(Power on): Press the joystick button once with your finger to turn on the monitor.

(Power off): Press and hold the joystick button once more than 5 seconds with your finger to turn off the

monitor.

(Volume control): You can control the volume by moving the joystick button left/right.

Enters the [Accessibility] menu.

Adjusting the Angle

1 Place the monitor mounted on the stand base in an upright position.

2 Adjust the angle of the screen.

The angle of the screen can be adjusted forward or backward from -5° to 20° for a comfortable viewing

experience.

WARNING

•To avoid injury to the fingers when adjusting the screen, do not hold the lower part of the monitor’s frame as

illustrated below.

•Be careful not to touch or press the screen area when adjusting the angle of the monitor.
