LG 32MA68HY Manuel utilisateur

www.lg.com

LED MONITOR MODEL

32MA68HY

Please read this manual carefully before operating

your set and retain it for future reference.

Owner's Manual

LED MONITOR

(LED MONITOR*)

*LG LED Monitors are LCD Monitors with LED Backlighting.

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 LICENSE

4 ASSEMBLINGANDPREPAR-

ING

4 Unpacking

5 SupportedDriversandSoftware

6 Partsandbuttons

6 - HowtoUsetheJoystickButton

7 - InputConnector

8 MovingandLiftingtheMonitor

9 SettinguptheMonitorset

9 - AttachingtheStandBase

10 - DetachingtheStandBase

11 - Mountingonatable

12 - Usingthecableholder

13 - Installingthewallmount

14 - Mountingonawall

15 USINGTHEMONITORSET

15 ConnectingtoaPC

15 - D-SUBconnection

15 - HDMIconnection

16 - DisplayPortconnection

16 ConnectingtoAVDevices

16 - HDMIconnection

17 ConnectingPeripherals

17 - USBCableconnection-PC

17 ConnectingtoExternalDevices

17 - Peripheraldeviceconnection

18 CUSTOMIZINGSETTINGS

19 Customizingsettings

19 - MenuSettings

19 - -QuickSettings

20 - -Picture

23 - -General

24 - -AutoConfiguration

25 - -Reset

26 - -Picturemode

27 TROUBLESHOOTING

29 SPECIFICATIONS

30 PresetModes(Resolution)

30 Indicator

ENG

ENGLISH

LICENSE

Eachmodelhasdifferentlicenses.Visitwww.lg.comformoreinformationonthelicense.

ThetermsHDMIandHDMIHigh-DefinitionMultimediaInterface,andthe

HDMIlogoaretrademarksorregisteredtrademarksofHDMILicensingLLC

intheUnitedStatesandothercountries.

ThefollowingcontentisonlyappliedtothemonitorwhichissoldinEuropemarketandwhichneedsto

meettheErPDirective:

*Thismonitorissettobeturnedoffautomaticallyin4hoursafteryouturnedondisplayifthereisno

adjustmenttodisplay.

*Tomakethissettingbedisabled,changetheoptionto‘Off’inOSDmenuof“AutomaticStandby”.

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

CD(Owner'sManual)/

Card (Dependingonthecountry) (Dependingonthecountry)

PowerCord AC-DCAdapter AC-DCAdapter

or

D-SUBCable

(Thiscableisnotincluded

inallcountries.)

USBCable

(Thiscableisnotincluded

inallcountries.)

StandBody StandBase

HDMICable

(Thiscableisnotincludedin

allcountries.)

CableHolder

OPTIONALACCESSORIES

DisplayPortCable

(Thiscableisnotincludedinallcountries.)

ENG

ENGLISH

ASSEMBLING AND PREPARING

SupportedDriversandSoftware

CheckthedriversandsoftwaresupportedbyyourproductandrefertothemanualsontheCDenclosedin

theproductpackage.

 RequiredandRecommended:YoucandownloadandinstallthelatestversionfromtheenclosedCD

orfromtheLGEwebsite

(www.lg.com)

DriversandSoftware InstallationPriority 32MA68HY

MonitorDriver Recommended O

OnScreenControl Recommended O

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

JoystickButton/

PowerIndicator

 On:powerison

 Off:powerisoff

 Thejoystickbuttonislocatedatthebottomofthemonitor.

NOTE

HowtoUsetheJoystickButton

Youcaneasilycontrolthefunctionsofthemonitorbypressingthejoystickbuttonormovingitleft/rightwith

yourfinger.

BasicFunctions

Poweron Pressthejoystickbuttononcewithyourfingertoturnonthe

monitor.

Poweroff Pressandholdthejoystickbuttononcewithyourfingertoturnoff

themonitor.

◄/►Volume

Control Youcancontrolthevolumebymovingthejoystickbuttonleft/right.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

InputConnector

ENG

ENGLISH

ASSEMBLING AND PREPARING

MovingandLiftingtheMonitor

Whenmovingorliftingthemonitor,followthese

instructionstopreventthemonitorfrombeing

scratchedordamagedandtoensuresafetrans-

portationregardlessofitsshapeorsize.

 Asfaraspossible,avoidtouchingthemoni-

torscreen.Thismayresultindamagetothe

screenorsomeofthepixelsusedtocreate

images.

 Itisadvisabletoplacethemonitorinthe

originalboxorpackingmaterialbeforeat-

temptingtomoveit.

 Beforemovingorliftingthemonitor,discon-

nectthepowercordandallcables.

 Holdthetopandbottomofthemonitorframe

firmly.Donotholdthepanelitself.

 Whenholdingthemonitor,thescreenshould

faceawayfromyoutopreventitbeing

scratched.



 Whenmovingthemonitor,avoidanystrong

shockorvibrationstotheproduct.

 Whenmovingthemonitor,keepitupright,

neverturnthemonitoronitssideortiltit

sideways.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

SettinguptheMonitorset

AttachingtheStandBase

1Pleaseputasoftclothonalowtableorbox

toprotectthescreenofthemonitor.

Pleaseputthemonitoronthesoftclothwith

thescreenfacingdown.

2PleasegrabtheStandbodyinonehand,and

pushitinthedirectionofthearrowtohinge

body.Afterassembling,youmustcheckifthe

Standbodylatchedinornot.

3PleasepushtheStandBaseinthedirection

ofthearrowasshownbelowandassemble

together.

Pleaseuseadriver(-)orcointoinsertthumb

screwandturnrightarrowdirectionlock.

 *Itisnecessarytothoroughlytightenitwith

ThumbScrew,orthemonitorwillshake.

4 PleasesettheMonitorupright,andinstallthe

necessarycable.

*Mustuseonetypeinputcable.Don'tuse

morethantwotypescabletogether.

Standbody

StandBase

ENG

ENGLISH

ASSEMBLING AND PREPARING

1Pleaseremovethecableinstalledtothemonitor.

2Pleaseputasoftclothonalowtableorboxto

protectthescreenofthemonitor.

Pleaseputthemonitoronthesoftclothwith

thescreenfacingdown.

3Pleaseusethedriver(-)orcoininsertthumb

screwandturnleftarrowdirectionunlock.

PleasepulltheStandBaseinthedirectionof

thearrowasshownbelowanddisassemble

asshownbelow.

4Afterfixingthemonitorinonehand,removethe

Standbodybypullingitstronglyinthedirection

ofthearrowasshownbelow.

*Ifitisdifficulttoremove,youcanpushthe

Latchwithasmallflat-headscrewdriverora

flat-headedtoolanddisassembleasshown

below.

DetachingtheStandBase
