Owner's Manual

IPS LED MONITOR

(LED MONITOR)

29UM65

29UB65

Please read the safety information carefully before using the

product.

IPS LED Monitor (LED Monitor) Model List

ENGLISH

ENG

ENGLISH

Contents

CONTENTS

24 CUSTOMIZING SETTINGS

24 ActivatingtheMainMenu

25 Customizingsettings

25 - MenuSettings

25 - -Easycontrol

26 - -Function

27 - -PBP

28 - -Screen

29 - -Settings

30 - -Reset

31 - ReaderSettings

32 TROUBLESHOOTING

34 SPECIFICATIONS

35 Factorysupportmode

(PresetMode,DVI-D/HDMI/PC

DisplayPort)

35 HDMITiming(Video)

35 PowerIndicator

36 PROPER POSTURE

36 ProperPostureforUsingtheMonitor

3 LICENSE

4 ASSEMBLING AND

PREPARING

4 ProductComponents

5 ComponentandButtonDescription

7 MovingandLiftingtheMonitor

8 InstallingtheMonitor

8 - Assemblingthestandbase

9 - Usingthecableholder

10 - Detachingthestandbase

12 - Installingontoatable

13 - Adjustingthestandheight

14 - Adjustingtheangle

15 - Pivotfeature

16 - UsingtheKensingtonlock

16 - Installingthewallmountplate

17 - Installingtoawall

18 USING THE MONITOR

18 ConnectingtoaPC

18 - DVIconnection

19 - DisplayPortconnection

19 - HDMIconnection

20 ConnectingtoAVDevices

20 - HDMIconnection

21 ConnectingtoExternalDevices

21 - Headphoneportconnection

22 INSTALLING LG MONITOR

SOFTWARE

ENG

ENGLISH

LICENSE

Eachmodelhasdifferentlicenses.Visitwww.lg.comformoreinformationonthelicense.

ThetermsHDMIandHDMIHigh-DefinitionMultimediaInterface,andthe

HDMIlogoaretrademarksorregisteredtrademarksofHDMILicensingLLC

intheUnitedStatesandothercountries.

VESA,VESAlogo,DisplayPortComplianceLogoandDisplayPort

ComplianceLogofordual-modesourceareallregisteredtrademarksofthe

VideoElectronicsStandardsAssociation.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Product Components

Pleasecheckwhetherallthecomponentsareincludedintheboxbeforeusingtheproduct.Ifthereare

missingcomponents,contacttheretailstorewhereyoupurchasedtheproduct.Notethattheproductand

componentsmaylookdifferentfromthoseshownhere.

 Alwaysusegenuinecomponentstoensuresafetyandproductperformance.

 Theproductwarrantywillnotcoverdamageorinjurycausedbytheuseofcounterfeitcomponents.

 Notethatthecomponentsmaylookdifferentfromthoseshownhere.

 Withoutpriornotice,allinformationandspecificationsinthismanualaresubjecttochangetoim-

provetheperformanceoftheproduct.

 Topurchaseoptionalaccessories,visitanelectronicsstoreoronlineshoppingsiteorcontactthe

retailstorewhereyoupurchasedtheproduct.

 TheDisplayPortcablemaynotbeavailableinsomeareas.

CAUTION

NOTE

Power CordUser Manual/Card AC/DC Adapter

29UM65

OPTIONAL ACCESSORIES

 TheDisplayPortcablemaynot

beavailableinsomeareas.

Display Port Cable

Stand Base

Stand Body Cable Holder Screws

(Black)

(Sliver)

HDMI Cable

29UM65

29UB65

DVI-D Dual Cable

(Thiscableisnotincludedinall

countries.)

ENG

ENGLISH

ASSEMBLING AND PREPARING

Component and Button Description

29UM65

Power Indicator

 On:powerison

 Off:powerisoff

Ports

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

29UB65

Power Indicator

 On:powerison

 Off:powerisoff

Ports

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

Moving and Lifting the Monitor

Whenmovingorliftingthemonitor,followthese

instructionstopreventthemonitorfrombeing

scratchedordamagedandtoensuresafetrans-

portationregardlessofitsshapeorsize.

 Asfaraspossible,avoidtouchingthemoni-

torscreen.Thismayresultindamagetothe

screenorsomeofthepixelsusedtocreate

images.

 Itisadvisabletoplacethemonitorinthe

originalboxorpackingmaterialbeforeat-

temptingtomoveit.

 Beforemovingorliftingthemonitor,discon-

nectthepowercordandallcables.

 Holdthetopandbottomofthemonitorframe

firmly.Donotholdthepanelitself.

 Whenholdingthemonitor,thescreenshould

faceawayfromyoutopreventitbeing

scratched.



 Whenmovingthemonitor,avoidanystrong

shockorvibrationstotheproduct.

 Whenmovingthemonitor,keepitupright,

neverturnthemonitoronitssideortiltit

sideways.

CAUTION

29UM65

29UB65

 Ifyouusethemonitorpanelwithoutthe

standbase,itsjoystickbuttonmaycause

themonitortobecomeunstableandfall,

resultingindamagetothemonitororhuman

injury.Inaddition,thismaycausethejoystick

buttontomalfunction.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Installing the Monitor

Assembling the stand base

 Toprotectthescreenfromscratches,cover

thesurfacewithasoftcloth.

CAUTION

2 First,pleaseinsertStandBodytoStandBase,

Thentightentwoscrewsintothebackofthe

standbase.

1 Placethescreenfacedown.

29UM65

Applyingexcessiveforcewhentightening

thescrewsmaycausedamagetothemoni-

tor.Damagecausedinthiswaywillnotbe

coveredbytheproductwarranty.

CAUTION

3 Checkthedirectionofthestandbody

(front,back)andthenmountthestandbody

ontothestandhinge.

4 Tightentwoscrewsintothebackofthestand

body.

Itmayhurtyourfootoffthestand,sobe

careful.

CAUTION

Stand Body

Stand Base

(Silver)

(Black)

120mm

100mm

(Black)

Stand Hinge

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Toprotectthescreenfromscratches,cover

thesurfacewithasoftcloth.

CAUTION

1 Placethescreenfacedown.

29UB65

Using the cable holder

3 Fixbyturningthescrewtotherightwithacoin.

2 Insertthestand baseintothehookofthe

stand body.

Itmayhurtyourfootoffthestand,sobe

careful.

CAUTION

29UM65

1 First,asshownintheillustration,pushthe

cableholderonthestandbody,Second,Fix

thecableholdertostandbody.

2 Putthecablesintothecableholder.

Stand Base

Stand Body

ENG

ENGLISH

ASSEMBLING AND PREPARING

Detaching the stand base

2 First,pressthethecableholderasshownin

theillustration,Second,Removethecable

holderfromthestandbody.

 Toprotectthescreenfromscratches,cover

thesurfacewithasoftcloth.

CAUTION

 Illustrationsinthisdocumentrepresenttypi-

calprocedures,sotheymaylookdifferent

fromtheactualproduct.

 Donotcarrythemonitorupsidedownbyjust

holdingthestandbase.Thismaycausethe

monitortofalloffthestandandcouldresult

inpersonalinjury.

 Whenliftingormovingthemonitor,donot

touchthemonitorscreen.Applyingforceor

pressuremaydamagethemonitorscreen.

Instead,holdthestandbodyortheplastic

frameoftheproduct.

CAUTION

1 Placethescreenfacedown.

29UM65

4 RemovethetwoscrewsfromtheStandBase.

 RemovetheStandBasefromtheStandBody.

3 Removethetwoscrewsonthebackofstand

body.

Asshownintheillustration,disconnectthe

stand body from the stand hinge.

Stand Hinge

Stand Body

Stand Base

(Black) (Black)

(Silver)
