Owner's Manual

IPS LED MONITOR

(LED MONITOR)

25UM55

25UB55

29UM55

29UB55

Please read the safety information carefully before using the

product.

IPS LED Monitor (LED Monitor) Model List

ENGLISH

ENG

ENGLISH

Contents

CONTENTS

32 CUSTOMIZING SETTINGS

32 ActivatingtheMainMenu

33 Customizingsettings

33 - MenuSettings

33 - -Easycontrol

34 - -Function

35 - -PBP

36 - -Screen

37 - -Settings

38 - -Reset

39 - ReaderSettings

40 TROUBLESHOOTING

42 SPECIFICATIONS

42 25UM55

43 25UB55

44 29UM55

45 29UB55

46 Factorysupportmode

(PresetMode,DVI-D/HDMI/PC

DisplayPort)

46 HDMITiming(Video)

46 PowerIndicator

47 PROPER POSTURE

47 ProperPostureforUsingtheMonitor

3 LICENSE

4 ASSEMBLING AND

PREPARING

4 ProductComponents

5 ComponentandButtonDescription

9 MovingandLiftingtheMonitor

10 InstallingtheMonitor

10 - Assemblingthestandbase

13 - Usingthecableholder

14 - Detachingthestandbase

17 - Detachingthestandbody

18 - Installingontoatable

19 - Adjustingthestandheight

20 - Adjustingtheangle

22 - Pivotfeature

23 - UsingtheKensingtonlock

23 - Installingthewallmountplate

24 - Installingtoawall

25 USING THE MONITOR

25 ConnectingtoaPC

25 - DVIconnection

26 - DisplayPortconnection

27 - HDMIconnection

28 ConnectingtoAVDevices

28 - HDMIconnection

29 ConnectingtoExternalDevices

29 - Headphoneportconnection

30 INSTALLING LG MONITOR

SOFTWARE

ENG

ENGLISH

LICENSE

Eachmodelhasdifferentlicenses.Visitwww.lg.comformoreinformationonthelicense.

ThetermsHDMIandHDMIHigh-DefinitionMultimediaInterface,andthe

HDMIlogoaretrademarksorregisteredtrademarksofHDMILicensingLLC

intheUnitedStatesandothercountries.

VESA,VESAlogo,DisplayPortComplianceLogoandDisplayPort

ComplianceLogofordual-modesourceareallregisteredtrademarksofthe

VideoElectronicsStandardsAssociation.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Product Components

Pleasecheckwhetherallthecomponentsareincludedintheboxbeforeusingtheproduct.Ifthereare

missingcomponents,contacttheretailstorewhereyoupurchasedtheproduct.Notethattheproductand

componentsmaylookdifferentfromthoseshownhere.

 Alwaysusegenuinecomponentstoensuresafetyandproductperformance.

 Theproductwarrantywillnotcoverdamageorinjurycausedbytheuseofcounterfeitcomponents.

 Notethatthecomponentsmaylookdifferentfromthoseshownhere.

 Withoutpriornotice,allinformationandspecificationsinthismanualaresubjecttochangetoim-

provetheperformanceoftheproduct.

 Topurchaseoptionalaccessories,visitanelectronicsstoreoronlineshoppingsiteorcontactthe

retailstorewhereyoupurchasedtheproduct.

 TheDisplayPortcablemaynotbeavailableinsomeareas.

CAUTION

NOTE

User Manual/Card

OPTIONAL ACCESSORIES

 TheDisplayPortcablemaynot

beavailableinsomeareas.

Display Port Cable

Stand Base

Stand Body Screw Cover Screws

HDMI Cable

One Screw Cable Holder

29UB5525UB55

Stand Base Stand Body Screw Cover Screws

(Dependingonthecountry) (Dependingon

thecountry)

Power Cord AC-DC Adapter AC-DC Adapter

ENG

ENGLISH

ASSEMBLING AND PREPARING

Component and Button Description

Power Indicator

 On:powerison

 Off:powerisoff

Ports

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

29UM55

Power Indicator

 On:powerison

 Off:powerisoff

Ports

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

5 5

Power Indicator

 On:powerison

 Off:powerisoff

Ports

(PowerButton)

Ports

ENG

ENGLISH

ASSEMBLING AND PREPARING

29UB55

Power Indicator

 On:powerison

 Off:powerisoff

Ports

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

Moving and Lifting the Monitor

Whenmovingorliftingthemonitor,followthese

instructionstopreventthemonitorfrombeing

scratchedordamagedandtoensuresafetrans-

portationregardlessofitsshapeorsize.

 Asfaraspossible,avoidtouchingthemoni-

torscreen.Thismayresultindamagetothe

screenorsomeofthepixelsusedtocreate

images.

 Itisadvisabletoplacethemonitorinthe

originalboxorpackingmaterialbeforeat-

temptingtomoveit.

 Beforemovingorliftingthemonitor,discon-

nectthepowercordandallcables.

 Holdthetopandbottomofthemonitorframe

firmly.Donotholdthepanelitself.

 Whenholdingthemonitor,thescreenshould

faceawayfromyoutopreventitbeing

scratched.



 Whenmovingthemonitor,avoidanystrong

shockorvibrationstotheproduct.

 Whenmovingthemonitor,keepitupright,

neverturnthemonitoronitssideortiltit

sideways.

CAUTION

29UM5525UM55

25UB55 29UB55

 Ifyouusethemonitorpanelwithoutthe

standbase,itsjoystickbuttonmaycause

themonitortobecomeunstableandfall,

resultingindamagetothemonitororhuman

injury.Inaddition,thismaycausethejoystick

buttontomalfunction.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Installing the Monitor

Assembling the stand base

 Toprotectthescreenfromscratches,cover

thesurfacewithasoftcloth.

CAUTION

2 Checkthedirectionofthestandbody

(front,back)andthenmountthestandbody

ontothestandhinge.

Tightentwoscrewsintothebackofthestand

body.

1 Placethescreenfacedown.

25UM55

3

4 Attachthescrewcover.

Stand Body

Stand Base

Stand Hinge

AttachtheStand BasetoStand Body.

Tightenthescrewtotheright.

Screws

Screw Cover
