LG 27MP35VQ-B Manuel utilisateur

www.lg.com

OWNER’S MANUAL

IPS LED MONITOR

27MP35VQ

Please read this manual carefully before operating

your set and retain it for future reference.

IPS LED MONITOR MODEL

ENGLISH

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 LICENSE

4 ASSEMBLINGANDPREPAR-

ING

4 Unpacking

5 Partsandbuttons

6 MovingandLiftingtheMonitor

7 SettinguptheMonitorset

7 - AttachingtheStandBase

8 - DetachingtheStandBase

9 - Mountingonatable

9 - Usingthecableholder

11 - Mountingonawall

12 USINGTHEMONITORSET

12 ConnectingtoaPC

12 - D-SUBconnection

12 - DVI-Dconnection

12 - HDMIconnection

13 ConnectingtoAVDevices

13 - HDMIconnection

13 ConnectingtoExternalDevices

13 - Peripheraldeviceconnection

15 CUSTOMIZINGSETTINGS

16 CustomizingSettings

16 - MenuSettings

17 -Picture

18 -Color

19 -Display

19 -Audio

20 -Others

21 READERSetting

22 FUNC.Setting

22 -SUPERENERGYSAVING

23 -PictureMode

24 -SUPERRESOLUTION+

25 -DUALDISPLAY

25 -DUALWEB

26 TROUBLESHOOTING

28 SPECIFICATIONS

28 27MP35VQ

29 PresetModes(Resolution)

29 Indicator

30 PROPERPOSTURE

30 ProperpostureforusingtheMonitorset.

LICENSE

ENGLISH

LICENSE

Eachmodelhasdifferentlicenses.Visitwww.lg.comformoreinformationonthelicense.

ThetermsHDMIandHDMIHigh-DefinitionMultimediaInterface,andthe

HDMIlogoaretrademarksorregisteredtrademarksofHDMILicensingLLC

intheUnitedStatesandothercountries.

ThefollowingcontentisonlyappliedtothemonitorwhichissoldinEuropemarketandwhichneedsto

meettheErPDirective:

*Thismonitorissettobeturnedoffautomaticallyin4hoursafteryouturnedondisplayifthereisnoadjust-

menttodisplay.

*Tomakethissettingbedisabled,changetheoptionto‘Off’inOSDmenuof“AutomaticStandby”.

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

StandBody StandBase

CD(Owner'sManual)/

Card

(Dependingonthecountry) (Dependingonthecountry)

PowerCord AC-DCAdapter AC-DCAdapter

or

TwoScrews HDMICable

(Thiscableisnotincluded

inallcountries.)

D-SUBCable

(Thiscableisnotincluded

inallcountries.)

DVI-DCable

(Thiscableisnotincluded

inallcountries.)

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

PowerIndicator

 LightingOn:Turnedon

 LightingOff:Turnedoff

Connectionpanel(Seep.12)

Button(Seep.15)

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

MovingandLiftingtheMonitor

Whenmovingorliftingthemonitor,followthese

instructionstopreventthemonitorfrombeing

scratchedordamagedandtoensuresafetrans-

portationregardlessofitsshapeorsize.

 Asfaraspossible,avoidtouchingthemoni-

torscreen.Thismayresultindamagetothe

screenorsomeofthepixelsusedtocreate

images.

 Itisadvisabletoplacethemonitorinthe

originalboxorpackingmaterialbeforeat-

temptingtomoveit.

 Beforemovingorliftingthemonitor,discon-

nectthepowercordandallcables.

 Holdthetopandbottomofthemonitorframe

firmly.Donotholdthepanelitself.

 Whenholdingthemonitor,thescreenshould

faceawayfromyoutopreventitbeing

scratched.



 Whenmovingthemonitor,avoidanystrong

shockorvibrationstotheproduct.

 Whenmovingthemonitor,keepitupright,

neverturnthemonitoronitssideortiltit

sideways.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

AttachtheStandBodytothemonitorset.

UsetwoscrewstofixtheStandBodyand

monitorset.

AttachtheStandBase.

Tightenthescrewtotheright.

SettinguptheMonitorset

AttachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

Layafoammatorsoftprotectivecloth

onthesurfacetoprotectthescreenfrom

damage.

CAUTION

StandBody

2

ENG

ENGLISH

ASSEMBLING AND PREPARING

 Thisillustrationdepictsthegeneralmodelof

connection.Yourmonitormaydifferfromthe

itemsshowninthepicture.

 Donotcarrytheproductupsidedownholding

onlythestandbase.Theproductmayfall

andgetdamagedorinjureyourfoot.

CAUTION

DetachingtheStandBase

1 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

StandBody

Turnthescrewtotheleft.

PullouttheStandBasefromtheStand

Body.

RemovetwoscrewsandpullouttheStand

Bodyfromthemonitorset.

2

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonatable

1 LiftandtilttheMonitorsetintoitsupright

positiononatable.

Leavea10cm(minimum)spacefromthewall

forproperventilation.

Usingthecableholder

2 ConnecttheAC-DCAdapterandPowerCord

toawalloutlet.

3 Press (Power)buttononthebottomswitch

paneltoturnthepoweron.

10 cm

Unplugthepowercordbeforemovingthe

Monitortoanotherlocation.Otherwiseelectric

shockmayoccur.

CAUTION

Cableholder

or

ENG

ENGLISH

ASSEMBLING AND PREPARING

UsingtheKensingtonsecuritysystem

TheKensingtonsecuritysystemconnectoris

locatedatthebackoftheMonitorset.Formore

informationofinstallationandusing,refertothe

manualsuppliedwiththeKensingtonsecurity

systemorvisit

http://www.kensington.com

ConnecttheKensingtonsecuritysystemcable

betweentheMonitorsetandatable.

TheKensingtonsecuritysystemisoptional.

Youcanobtainitfrommostelectronicsstores.

NOTE

Whenyouadjusttheangle,donotholdthe

bottomoftheMonitorsetframeasshownon

thefollowingillustration,asmayinjureyour

fingers.

Donottouchorpressthescreenwhen

adjustingtheangleofthemonitor.

Donotholdthissetlikebelowpicture.Monitor

screencandetachfromstandbaseandinjure

yourbody.

WARNING

Tiltfrom+20to-5degreesupordowntoadjust

theangleoftheMonitorsettosuityourview.

NOTE

Front Rear
