LG 24MB67PY Manuel utilisateur

www.lg.com

22MB67PY

24MB67PY

IPS LED(LED LCD) MONITOR MODEL

www.lg.com

Please read this manual carefully before operating

your set and retain it for future reference.

Owner's Manual

IPS LED MONITOR

LED LCD MONITOR

(LED MONITOR*)

*LG LED Monitors are LCD Monitors with LED Backlighting.

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 ASSEMBLINGANDPREPAR-

ING

3 Unpacking

4 Partsandbuttons

5 Motionsensorlens

5 - Cautioninuse

5 - Noticeinhandlingandstorage

6 SettinguptheMonitorset

6 - AttachingtheStandBase

6 - Detachingthestandbase

7 - Detachingthestandbody

7 - Usingthecableholder

7 - Mountingonatable

8 - Adjustingtheangle

8 - Adjustingthestandheight

9 - UsingtheKensingtonlockingdevice

10 - Swivelstand

10 - UsingthePivotfunction

11 - Mountingonawall

12 USINGTHEMONITORSET

12 ConnectingtoaPC

12 - D-SUBconnection

12 - DVI-Dconnection

14 - Peripheraldeviceconnection

15 CUSTOMIZINGSETTINGS

16 CustomizingSettings

16 - MenuSettings

17 -Picture

18 -Color

19 -Display

19 -Audio

20 -MotionEnergySaver

21 -Others

22 -READERSetting

23 -SMARTENERGYSAVINGSetting

24 TROUBLESHOOTING

26 SPECIFICATIONS 

26 22MB67PY

27 24MB67PY

28 PresetModes(Resolution)

29 Indicator

30 PROPERPOSTURE

30 ProperpostureforusingtheMonitorset.

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.

 Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.

 Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.

 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.

 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

StandBase

CD(Owner'sManual)/

Card

D-SUBCable

(Thiscableisnotincludedinall

countries.)

(Dependingonthecountry) (Dependingonthecountry)

PowerCord

DVI-DCable

(Thiscableisnotincludedinall

countries.)

OneScrew CableHolder

USBCable

AudioCable

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

(PowerButton)

PowerIndicator

 LEDOn:Powerison

 LEDOff:Powerisoff

FrontSideButtons

Motionsensorlens

InputConnectors(Seep.12to14)Seep.12to14)to14)

ENG

ENGLISH

ASSEMBLING AND PREPARING

Motionsensorlens

Cautioninuse

Pleaseavoidusingthefresnellensinthefollowingconditionsbecauseitmaycausefailureor

malfunction.

(a)Insuchafluidaswater,alcoholetc.corrosivegas(SO2,Cl2,NOXetc.)orseabreeze.

(b)Inhighhumidity.

(c)Inaplaceexposeddirectlytosunlightorheadlightofautomobile.

(d)Inaplaceexposeddirectlytoblowfromair-conditionerorheater.

(e)Insuchaplacewhereinfraredrayisshaded.

(f)Inanyotherplacesimilartotheabove(a)through(e).

TheperformanceofMotionEnergySaverismaximizedtoaspecificuserdistance(1m)andangle(20

degrees).

Thesensormaynotdetectyouifyouaremotionless.

Ifyouthinkthatthemodeentrymessageappearstoofrequently,increasethetimesettingoftheMotion

EnergySaverorturnthemodeoff.

Avoidusingradioequipmentsuchasawalkie-talkieneartheproductasthismaycauseaproduct

malfunction.

Thesensormaynotdetectyou,whenthemonitorisusedinportraitmodedependingonaspecific

userangle.

Noticeinhandlingandstorage

1)Opticalfilterofsensorshouldnotbescratchedorsoiled.

2)Strongshockshouldbeavoided.

3)Hightemperature,highhumidity,fluidaswateroralcoholetc.,corrosivegas(SO2,Cl2,NOXetc.)and

seabreezeshouldbeavoided.

ENG

ENGLISH

ASSEMBLING AND PREPARING

SettinguptheMonitorset

AttachingtheStandBase

1 PlacetheMonitorsetwiththescreensidedown

onaflatandcushionedsurface.

StandBase

StandBody

StandBase

StandBody

 Toprotectthescreenfromscratches,cover

thesurfacewithasoftcloth.

3 Usingacoin,turnthescrewclockwisetosecure

thestandbase.

2 Checktheposition(atthefrontandrear)of

thestandbody,thenmountthestandbaseon

thestandbodyasshowninthefigure.

CAUTION

StandBase

 Thecomponentsappearingintheillustra-

tionsmaylookdifferentfromtheactualprod-

uct.

 Donotcarrythemonitorupside-downasthis

maycauseittofalloffitsstand,resultingin

damageorinjury.

 Toavoiddamagingthescreenwhenlifting

ormovingthemonitor,onlyholdthestandor

theplasticcover.Thisavoidsputtingunnec-

essarypressureonthescreen.

 Onlyremovethetapeandthelockingpin

whenthemonitorismountedonthestand

baseandisinanuprightposition.Otherwise,

thestandbodymayprotrude,whichmay

leadtoinjury.

Detachingthestandbase

1 Placethemonitor'sscreenfacedown.

Toprotectthescreenfromscratches,coverthe

surfacewithasoftcloth.

2 Usingacoin,turnthescrewinthestandbase

counterclockwise.Detachthestandbasefrom

thestandbody.

CAUTION

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonatable

1 Liftthemonitorandplaceitonthetableinan

uprightposition.

Installatleast10cmawayfromthewallto

ensuresufficientventilation.

10 cm

Detachingthestandbody

1 Placethemonitor'sscreenfacedown.To

protectthescreenfromscratches,coverthe

surfacewithasoftcloth.

2 Usingascrewdriver,removethefourscrews

anddetachthestandfromthemonitor.

Usingthecableholder

FixtheKnob(Cableholder)tothe

Hole(Hingebody).

UseonescrewtofixtheCableHolderand

monitorset.

ClosetheCableholder.

3 Pressthe (Power)buttononthefrontofthe

monitortoturnonthemonitor.

 Unplugthepowercordpriortomovingor

installingthemonitor.Thereisriskofelectric

shock.

CAUTION

ConnectthePowercordtothemonitor,then

plugthepowercordintothewalloutlet.

(Beforeconnectpleasecheckthe“ON/OFF”

knobin“O”state).

Pressthe“ON/OFF”knobin“”state

(Openthepower).



 Theholesareusedforwallmountbracket.

 Variesdependinguponyourcountryor

model.

NOTE

ENG

ENGLISH

ASSEMBLING AND PREPARING

Adjustingtheangle

1 Placethemonitormountedonthestandbase

inanuprightposition.

2 Adjusttheangleofthescreen.Theangleofthe

screencanbeadjustedupto5°forwardsand

20°backwardsforacomfortableviewingexpe-

rience.

 Toavoidinjurytothefingerswhenadjusting

thescreen,donotholdthelowerpartofthe

monitor'sframeasillustratedbelow.

 Becarefulnottotouchorpressthescreen

areawhenadjustingtheangleofthemonitor.

WARNING

FrontSideRearSide

22MB67PY

2 Adjusttheangleofthescreen.Theangleofthe

screencanbeadjustedupto5°forwardsand

35°backwardsforacomfortableviewingexpe-

rience.

FrontSideRearSide

24MB67PY

Adjustingthestandheight

1 Placethemonitormountedonthestandbase

inanuprightposition.

2 Removethetapeattachedatthebottomrearof

thestandbody,thenpulloutthelockingpin.

Tape

LockingPin

StandBody



ENG

ENGLISH

ASSEMBLING AND PREPARING

Using the Kensington locking

device

TheconnectorfortheKensingtonlockislocated

ontherearofthemonitor.

Formoreinformationoninstallationandusage,

refertotheKensingtonlockusermanualorvisit

thewebsiteathttp://www.kensington.com.

ConnectthemonitortothetablewiththeKensing-

tonlockcable.

 UsingtheKensingtonlockisoptional.The

accessoriescanbepurchasedatyourlocal

electronicsstore.

NOTE

 Oncethepinisremoved,itisnotnecessary

tore-insertittoadjusttheheight.

3 Theheightcanbeadjustedupto120mm.

 Donotputyourfingerbe-

tweenthescreenandthe

base(chassis)whenadjust-

ingthescreen'sheight.

CAUTION

WARNING

120.0mm

22MB67PY

3 Theheightcanbeadjustedupto130mm.

130.0mm

24MB67PY

ENG

ENGLISH

ASSEMBLING AND PREPARING

Swivelstand

 ImageshownmaydifferfromyourMonitor

set.

1 Swivel355degreesandadjusttheangleofthe

Monitorsettosuityourview.

1 Liftthemonitortoitshighestheighttoutilizethe

Pivotfunction.

UsingthePivotfunction

Thepivotfunctionallowsyoutorotatethescreen

90degreesclockwise.

2 Landscape&Portrait:Youcanrotatethepanel

90°clockwise.Pleasebecautiousandavoid

contactbetweenthemonitorheadandthe

StandBasewhenrotatingthescreentoaccess

thePivotfunction.Ifthemonitorheadtouches

theStandBase,thentheStandBasecould

crack.

Head

section

Stand

section

3 Becarefulwiththecableswhenrotatingthe

screen.
