LG MS4440SRW Manuel utilisateur

MS4440SRW

www.lg.com

OWNER’S MANUAL

MICROWAVE OVEN

PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE OPERATING.

MFL67120503

You cannot operate your oven with the door open due to the safety interlocks

built into the door mechanism. These safety interlocks automatically switch off

any cooking activity when the door is opened; which in the case of a

microwave oven could result in harmful exposure to microwave energy.

It is important not to tamper with the safety interlocks.

Do not place any object between the oven front face and the door or allow

food or cleaner residue to accumulate on sealing surfaces.

Do not operate your oven if it is damaged. It is particularly important that the

oven door closes properly and that there is no damage to the: (1) door(bent),

(2) hinges and latches (broken or loosened), (3) door seals and sealing

surfaces.

Your oven should not be adjusted or repaired by anyone except qualified

service personnel.

Warning

Precautions to avoid possible exposure to excessive microwave energy.

Precautions

When heating liquids, e.g. soups, sauces and beverages in your microwave

oven, overheating the liquid beyond boiling point can occur without

evidence of bubbling. This could result in a sudden boil over of the hot

liquid. To prevent this possibility the following steps should be taken:

1 Avoid using straight sided containers with narrow necks.

2 Do not overheat.

3 Stir the liquid before placing the container in the oven and again halfway

through the heating time.

4 After heating, allow to stand in the oven for a short time, stir or shake

them again carefully and check the temperature of them before

consumption to avoid burns (especially, contents of feeding bottles and

baby food jars).

Be careful when handling the container.

Warning

Always allow food to stand after being cooked by

microwaves and check the temperature of them

before consumption. Especially contents of feeding

bottles and baby food jars.

Please ensure cooking times are correctly set as

over cooking may result in the FOOD catching fire

and subsequent damage to your oven.

How the Microwave Oven Works

Microwaves are a form of energy similar to radio and television waves and

ordinary daylight. Normally, microwaves spread outwards as they travel

through the atmosphere and disappear without effect. Microwave ovens,

however, have a magnetron which is designed to make use of the energy in

microwaves. Electricity, supplied to the magnetron tube, is used to created

microwave energy.

These microwaves enter the cooking area through openings inside the oven. A

turntable or tray is located at the bottom of the oven. Microwaves cannot pass

through metal walls of the oven, but they can penetrate such materials as

glass, porcelain and paper, the materials out of which microwave-safe

cooking dishes are constructed.

Microwaves do not heat cookware, though cooking vessels will eventually get

hot from the heat generated by the food.

A very safe appliance

Contents

Your microwave oven is one of the safest of all home

appliances. When the door is opened, the oven

automatically stops producing microwaves. Microwave

energy is converted completely to heat when it enters

food, leaving no “left over” energy to harm you when

you eat your food.

Precautions

4 ~ 5

12 ~ 14

15 ~ 16

17 ~ 18

19 ~ 20

23 24

26 27

28 ~

Contents

Unpacking & Installing

Setting the Clock

Child Lock

Micro Power Cooking

Micro Power Level

Two Stage Cooking

Quick Start

Auto Cook

Auto Reheat

Auto Defrost

Quick Defrost

Timer

More or Less Cooking

Important safety instructions

Microwave - safe Utensils

Food characteristics & Microwave cooking

Questions & Answers

Plug Wiring Information/Technical Specifications

Place the oven in the level location of your choice with

more than 85cm height but make sure there is at least

30cm of space on the top and 10cm at the rear for proper

ventilation. The front of the oven should be at least 8cm from the

edge of the surface to prevent tipping.

An exhaust outlet is located on top or side of the oven. Blocking

the outlet can damage the oven.

Unpacking &

Installing

Unpack your oven and place it on a flat level

surface.

By following the basic steps on these two pages you will be able to quickly check that your oven is operating

correctly. Please pay particular attention to the guidance on where to install your oven. When unpacking your

oven make sure you remove all accessories and packing. Check to make sure that your oven has not been

damaged during delivery.

THIS OVEN SHOULD NOT BE USED FOR COMMERCIAL

CATERING PURPOSES

GLASS TRAY

ROLLER REST

The DISPLAY will count down from 30 seconds.

When it reaches 0 it will sound BEEPS. Open

the oven door and test the temperature of the water. If

your oven is operating the water should be warm. Be

careful when removing the container it may be hot.

YOUR OVEN IS NOW INSTALLED

Press the

START button

once to set

30 seconds of

cooking time.

You will hear

a BEEP when

you press the button.

Seconds

Open your oven door by pushing the Door Open

button. Place the ROLLER REST inside the oven and

place the GLASS TRAY on top.

Plug your oven into a standard household socket.

Make sure your oven is the only appliance

connected to the socket. If your oven does not operate

properly, unplug it from the electrical socket and then plug it

back in.

Fill a microwave safe container with

300 ml (1/2 pint) of water. Place on

the GLASS TRAY and close the oven door. If you

have any doubts about what type of container to

use please refer to page .

Setting the

Clock You can set either 12 hour clock or 24 hour clock.

In the following example I will show you how to set the time for 14:35 when using the 24 clock.

Make sure that you have removed all packaging from your oven.

When your oven is plugged in for the

first time or when power resumes after a

power cut, a ‘0’ will be shown in the

display; you will have to reset the clock.

If the clock (or display) shows any

strange looking symbols, unplug your

oven from the electrical socket and plug

it back in and reset the clock.

Make sure that you have correctly installed your oven as described earlier

in this book.

Press STOP/CLEAR.

Press SET CLOCK once.

(If you want to use different option, Press SET CLOCK once more.

If you want to change different option after setting clock,

you have to unplug and plug it back in.)

Press 10 MIN fifteen times.

Press 1 MIN three times.

Press 10 SEC five times.

Press SET CLOCK to set the time.

The clock starts counting.

Child

Lock

Press and hold STOP/CLEAR until “L” appears on the display and BEEP

sounds.

The CHILD LOCK is now set.

The time will disappear on the display but will reappear on the display a

few seconds later.

If any button is pressed, “L” will appear on the display.

To cancel CHILD LOCK press and hold STOP/CLEAR until “L” disappears.

You will hear BEEP when it’s released.

Your oven has a safety feature that

prevents accidental running of the oven.

Once the child lock is set, you will be

unable to use any functions and no

cooking can take place.

However your child can still open the

oven door!

Press STOP/CLEAR.

Micro Power

Cooking

Make sure that you have correctly installed your oven as described earlier

in this book.

Press STOP/CLEAR.

Press MICRO

“800”

MICRO

twice to select 800W power.

appears on the display.

Press 1 MIN five times.

Press 10 SEC three times.

Press START.

Your oven has five microwave Power

settings. High power is automatically

selected but repeated presses of the

key will select a different power

level.

In the following example I will show you how to cook some food on 800W (80%) power for 5 minutes and 30

seconds.

POWER

HIGH

MAX

MEDIUM

HIGH

MEDIUM

DEFROST

MEDIUM LOW

LOW

Press

100%

80%

60%

40%

20%

time

times

Micro Power

Level

Your microwave oven is equipped with 5 power levels to give you maximum flexibility and control over cooking.

The table below shows the examples of food and their recommended cooking power levels for use with this

microwave oven.

POWER LEVEL

POWER LEVEL (%)

HIGH

MAX

* Boil Water

* Brown minced beef

* Cook poultry pieces, fish, vegetables

* Cook tender cuts of meat

MEDIUM HIGH * All reheating

* Roast meat and poultry

* Cook mushrooms and shellfish

* Cook foods containing cheese and eggs

MEDIUM * Bake cakes and scones

* Prepare eggs

* Cook custard

* Prepare rice, soup

DEFROST/ * All thawing

MEDIUM LOW * Melt butter and chocolate

* Cook less tender cuts of meat

LOW * Soften butter & cheese

* Soften ice cream

* Raise yeast dough

USE POWER OUTPUT

100%

80%

60%

40%

20%

1000W

800W

600W

400W( )

200W

Press START.

Two stage

Cooking

Press STOP/CLEAR.

Set the power and the cooking time for stage1.

Press once to select HIGH power.

Press 10 MIN once.

Press 1 MIN once.

Set the power and the cooking time for stage2.

Press four times to select 400W power.

Press 10 MIN three times.

Press 1 MIN five times.

During two stage cooking the oven door

can be opened and food checked. Close

the oven door and press START and the

cooking stage will continue.

At the end of stage1, BEEP sounds and

stage 2 commences.

Should you wish to clear the programme

press STOP/CLEAR twice.

In the following example I will show you how to cook some food in two stages. The first stages will cook your

food for 11 minutes on HIGH; the second will cook for 35 minutes on 400W(40%) power.

MICRO
