LG 55EA980V Manuel utilisateur

User Guide

This is a 「User Guide」 installed on the TV.

The contents of this guide are subject to change without prior notice for quality

improvement.

GP4

eng

 

Displays information on current programme and / or current time, etc.

1 Move the pointer of the Magic remote control to the top of the TV screen.

2 Click the activated channel banner area.

3 The programme details will be displayed at the bottom of the TV screen.

✎ Image shown may differ from your TV.

Programme name Detail information on programme

(for digital broadcast)

Current time

DOWN

Prev./Next Pr. Change Watch

 



GP4

eng

 

    

1 MovetothedesiredprogrammeandpressWheel(OK)button.Programmeis

selected.

2 PressSetasFavourite.

3 SelectthedesiredFavouritePr.Group.

4 SelectOK.Favouriteisset.

 

 

Programmelistwillappear.Selectsthedesiredpresetfavouriteprogramme

fromFavouriteListAtoD.

GP4

eng

SMART ➾ TV Guide

[In Digital Mode Only]

Obtains information about programmes and airing times. Obtains programme

information and schedules viewing / recording.

Press Wheel (OK) button after moving to a

programme of your choice to view or view /

record.

Makes schedule reservation by selecting date / time /

programme. Makes repeat schedule reservation.

[Image shown may differ from your TV.]

After viewing the schedule list, makes

revisions or deletions.

Today OO OO. OOOO AM 9:00

TV Guide

Select schedule by date Schedule List P-24H +24H

GP2

eng

 

 

Automatically tunes the programmes.

1 Select Country where the TV is used. Programme settings change depending

on the country you choose.

2 Initiate Auto Tuning.

3 Select Input Source of your choice.

4 Set Auto Tuning following screen instructions.

✎ If Input Source is not connected properly, programme registration may not

work.

✎ Auto Tuning only finds programmes that are currently broadcasting.

✎ If Lock System is turned on, a pop-up window will appear asking for

password.

GP2

eng

 

When searching for programmes using FULL setting it can take a long time.

The following values are needed in order to search all available programmes

quickly and correctly. The commonly used values are provided as “default”.

Frequency Enter a user-defined frequency.

Symbol rate Speed at which a device such as modem sends symbols to

a programme.

Modulation Loading of audio or video signals onto carrier.

Network ID Unique identifier allocated for each user.

Start Frequency Enter a user-defined start frequency range.

End Frequency Enter a user-defined end frequency range.

GP2

eng

 

Satellite Select your desired Satellite.

LNB Frequency

[Depending on country]

Select one value from 9750/10600, 9750/10750, 9750,

10600,10750, 5150, MDU1, MDU2, MDU3, MDU4, MDU5.

If you select 9750/10600, 9750/10750(MHz), 22KHz

Tone is disabled. If you cannot find the LNB frequency

value from the list, select User and manually enter the

frequency.

Transponder Select the transponder you want to tune.

22KHz Tone When using 22KHz Tone switch, select A or B. If you use

22KHz Tone, Unicable and Motor Type are disabled.

GP2

eng

LNB Power To enable the power supply for the LNB, select On. If you

select Off, Motor Type is disabled.

DiSEqC When using DiSEqC, select one option from A~D/ToneA~B.

If you use DiSEqC, Unicable and Motor Type are disabled.

Unicable Settings

Select On to use Unicable and set the Unicable in the

Unicable Setting menu. When Unicable is enabled, 22KHz

Tone, DiSEqC, Motor Type are disabled.

Motor Type

Select Motor Type to use Motor and set the Motor in the

Motor Setting menu. When Motor is enabled, 22KHz Tone,

DiSEqC, Unicable are disabled.

GP2

eng

✎ If you set satellite to others, you must add a transponder using Manual

Tuning.

✎ When selecting 22KHz Tone and DiSEqC, you must connect them in the

same position as displayed on the OSD.

✎ If you delete a Satellite, all programmes stored in the Satellite are deleted.

GP2

eng

 

• DiSEqC 1.2 : Control motor to change satellite dish position.

Drive Direction Select the direction in which you want to move the motor.

Drive Mode

Two modes are available : Step and Continuous.

• Step : The motor moves based on the value you enter

(from 1 to 128).

• Continuous : The motor moves continuously until you

press the Stop.

Test TP Select the test TP you want to tune.
