LG 32LF510B Guide de démarrage rapide

www.lg.com

P/NO : MFL68587845 (1507-REV00)

32LF510B

32LF510D

43LF510T

LED TV

43LF5100

49LF510T

49LF5100

X 4

(M4 x L14)

Depending upon model / Según el modelo

ENGLISH Easy Setup Guide

Please read this manual carefully before operating your set and retain it for future reference.

ESPAÑOL Guía Rápida de Conguración

Lea atentamente este manual antes de poner en marcha el equipo y consérvelo para futuras consultas.

ENGLISH

ESPAÑOL

Image shown may differ from your TV.

La imagen puede ser diferente a la de su televisor.

DC-IN

(19V )

DC-IN

(19V )

DC-IN

(19V )

DC-IN

(19V )

Depending upon model / Según el modelo

ENGLISH

MODELS

32LF510B

(32LF510B-DB)

43LF510T

(43LF510T-DA)

49LF510T

(49LF510T-DA)

32LF510D

(32LF510D-DB)

43LF5100

(43LF5100-DA)

49LF5100

(49LF5100-DA)

32LF510B

(32LF510B-SB) 43LF5100

(43LF5100-SA)

49LF5100

(49LF5100-SA)

32LF510B

(32LF510B-SD)

Dimensions (W x H x D) With stand (mm) 734 x 474 x 172 976 x 621 x 208.7 1,108 x 696 x 208.7

Without stand (mm) 734 x 438 x 71 976 x 583 x 81.5 1,108 x 657 x 81.5

Weight With stand (kg) 4.7 8.5 10.9

Without stand (kg) 4.5 8.2 10.6

Power Requirement 19 V 1.6 A 19 V 2.5 A 19 V 3.2 A

Power Consumption 35 W 50 W 65 W

AC/DC Adapter

Manufacturer : Honor

ADS-45EI-19 19040GPI

ADS-45FSN-19 19040GPG

ADS-45FSN-19 19040GPCU

ADS-40LSI-19-2 19040G

ADS-45SN-19-2 19040G

Manufacturer : Lien Chang

Model : LCAP40

Manufacturer : APD

WA-40D19FI

Manufacturer : APD

Model : DA-65F19

Manufacturer : Lien Chang

LCAP16B-E

LCAP16B-A

LCAP25B

In : AC 100 - 240 V ~ 50 / 60 Hz

Out : 19 V 2.1 A Out : 19 V 3.42 A

ESPAÑOL

MODELOS

32LF510B

(32LF510B-DB)

43LF510T

(43LF510T-DA)

49LF510T

(49LF510T-DA)

32LF510D

(32LF510D-DB)

43LF5100

(43LF5100-DA)

49LF5100

(49LF5100-DA)

32LF510B

(32LF510B-SB) 43LF5100

(43LF5100-SA)

49LF5100

(49LF5100-SA)

32LF510B

(32LF510B-SD)

Dimensiones

(Ancho x altura x profundidad)

Con base (mm) 734 x 474 x 172 976 x 621 x 208,7 1 108 x 696 x 208,7

Sin base (mm) 734 x 438 x 71 976 x 583 x 81,5 1 108 x 657 x 81,5

Peso Con base (kg) 4,7 8,5 10,9

Sin base (kg) 4,5 8,2 10,6

Potencia requerida 19 V 1,6 A 19 V 2,5 A 19 V 3,2 A

Consumo de la potencia 35 W 50 W 65 W

Adaptador de CA/CC

Fabricante : Honor

ADS-45EI-19 19040GPI

ADS-45FSN-19 19040GPG

ADS-45FSN-19 19040GPCU

ADS-40LSI-19-2 19040G

ADS-45SN-19-2 19040G

Fabricante : Lien Chang

Modelo : LCAP40

Fabricante : APD

WA-40D19FI

Fabricante : APD

Modelo : DA-65F19

Fabricante : Lien Chang

LCAP16B-E

LCAP16B-A

LCAP25B

Entrada : AC 100 - 240 V ~ 50 / 60 Hz

Salida : 19 V 2,1 A Salida : 19 V 3,42 A

*MFL68587845*

Drawn Approved

Signature A. R. Kim J. O. Kim

MMM/DD/YYYY Dec/16/2014 Dec/16/2014

49LF5400-S* LG MFL68663713

W* not WM/WD/WZ 49LF5400 (1507-REV04)

:LGEAK :LGEKR :LGERS

:LGEAZ :LGEMA :LGESY

:LGEEG :LGEMX :LGETH

:LGEIL :LGEND

:LGEIN :LGERA

:LGEAS :LGEWR

J. A. Park

Dec/16/2014

1. Model Description

:Model name

:Brand name

:Part number

:Suffix

:Product name

(Revision number)

Printing specification

Checked

: • Inside

1 Color (Black)

3. Stock (Paper)

: • Cover

Uncoated, wood-free paper 60 g/㎡

2. Printing Specification

:1. Trim size (Format)

148 mm x 210 mm (A5)

2. Printing colors

: • Cover

1 Color (Black)

:6. Number of pages

“This part contains Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level,

Details should be followed Eco-SCM management standard[LG(56)-A-2524].

Especially, Part should be followed and controlled the following specification.

(1) Eco-hazardous substances test report should be submitted when Part certification test and First Mass Production.

(2) Especially, Don’t use or contain lead(Pb) and cadmium(Cd) in ink.

: • Inside

Uncoated, wood-free paper 60 g/㎡

:4. Bindery

Saddle stitching

:5. Language

ENG/SPA_LATIN (2)

Printed in Egypt

Printed in Mexico

Printed in Thailand

Printed in India

Printed in China

Printed in Vietnam

3. Origin Notification

Printed in Kazakhstan

Printed in Korea

Printed in Mexico

Printed in Brazil

Printed in Poland

Printed in China

:LGEVN

Printed in Indonesia

Printed in Russia

Made by LG Electronics (Only TW Suffix)

4. Changes

Printed in Algeria

Printed in Poland

Jul/01/2015

A. R. Kim

EKLF700056

To add the series of LF51 on manual

Jun/03/2015

A. R. Kim

EKLF600048

To add the sentences about mounting on a wall

Feb/12/2015

A. R. Kim

EKLF201170

To add the models of Game TV (LF541*) for manual

Feb/03/2015

A. R. Kim

EKLE600143

To add the model for wall mount mini bracket for LF54

Rev. Number

MMM/DD/YYYY

Signature

ECO Number

Change Contents

Front Back

(Eng)

P/No. 2 … … … 18 Blank

Front Back

(Spa)

2… … … 18 Blank
