LG 29LN549M Manuel utilisateur
2
ENGLISH
TABLE OF CONTENTS
TABLE OF CONTENTS
3 LICENSES
4 INSTALLATION PROCEDURE
5 ASSEMBLING AND PREPARING
5 Unpacking
8 Parts and buttons
12 Lifting and moving the TV
13 Setting up the TV
13 - Attaching the Stand Base
13 - Detaching the Stand Base
15 - Attaching the Stand Base
16 - Detaching the Stand Base
18 - Mounting on a table
20 - Tidying cables
22 - Mounting on a wall
24 WATCHING TV
24 Turning the TV on for the first time
26 MAKING CONNECTIONS
26 Connecting an antenna
26 - Connecting an antenna or basic cable
27 - Connecting with a cable box
28 Connecting to a HD receiver, DVD Player,
VCR or Gaming device
28 - HDMI Connection
29 - HDMI to DVI Connection
30 - Component Connection
31 - Composite Connection
32 Connecting a USB Device
33 Connecting to a PC
34 - HDMI connection
35 - HDMI to DVI connection
36 - RGB connection
37 REMOTE CONTROL
39 CUSTOMIZING SETTINGS
39 Accessing the Main Menus
40 USING THE USER GUIDE
40 Accessing the On-Screen User Guide
40 - Using the TV menu
40 - Using the Remote Control
41 MAINTENANCE
41 Cleaning Your TV
41 Screen and frame
41 Cabinet and stand
41 Power cord
42 Preventing “Image burn” or “Burn-in” on
your TV screen
43 TROUBLESHOOTING
43 General
44 SPECIFICATIONS
48 KEY CODES
49 EXTERNAL CONTROL DEVICE
SETUP
49 USB to Serial converter with USB Cable
50 RS-232C with RS-232C Cable (Legacy)
50 - Customer Computer
50 - RS-232C configurations
51 Communication Parameters
51 Command reference list
52 Transmission / Receiving Protocol
ENGLISH
3
LICENSES
LICENSES
Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories. Dolby and the
double-D symbol are trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC
in the United States and other countries.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a
subsidiary of Rovi Corporation. This is an official DivX Certified® device that
plays DivX video. Visit divx.com for more information and software tools to
convert your files into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be
registered in order to play purchased DivX Video-on-Demand (VOD) movies.
To obtain your registration code, locate the DivX VOD section in your device
setup menu. Go to vod.divx.com for more information on how to complete
your registration.
DivX Certified® to play DivX® video up to HD 1080p, including premium
content.
DivX®, DivX Certified® and associated logos are trademarks of Rovi
Corporation or its subsidiaries and are used under license.
Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668;
7,515,710; 7,519,274
ENGLISH
4INSTALLATION PROCEDURE
INSTALLATION PROCEDURE
1 Open the package and make sure all the accessories are included.
2 Attach the stand to the TV.
3 Connect an external device to the TV.
Image shown may differ from your TV.
Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.
The available menus and options may differ from the input source or product model that you are
using.
New features may be added to this TV in the future.
NOTE
ENGLISH
5
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and accessories.
The accessories supplied with your product may vary depending on the model.
Product specifications or contents in this manual may be changed without prior notice due to
upgrade of product functions.
NOTE
Do not use any pirated items to ensure the safety and product life span.
Any damages or injuries by using unapproved or counterfeit parts or accessories are not covered
by the warranty.
CAUTION
The items supplied with your product may vary depending on the model.
Product specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm thick
and 18 mm width. Use an extension cable that supports USB 2.0 if the USB cable or USB memory
stick does not fit into your TV’s USB port.
NOTE
*A 10 mm
*B 18 mm
A
B
A
B
ENGLISH
7
ASSEMBLING AND PREPARING
Remote Control
Batteries (AAA)
Owner's Manual/ Cards
AC-DC Adapter.
Cable Tie.
(See p.37, See p.38)
(See p.19)(See p.19) (See p.19)
(See p.20)
Power Cord. AC-DC Adapter.
or
( Depending on the country ) (Depending on the country)
Stand Base
(See p.15, See p.16)
29LN549M
(See p.15, See p.16)
Screws for Assembly
2 EA
(See p.15, See p.16)
Stand Body
ENGLISH
8ASSEMBLING AND PREPARING
Parts and buttons
28LN549M
INPUT
OK
SETTINGS
All of the buttons are touch sensitive and can be operated through simple touch with your finger.
NOTE
Touch buttons Description
Scrolls through the saved channels.
Adjusts the volume level.
OK Selects the highlighted menu option or confirms an input.
SETTINGS Accesses the main menus, or saves your input and exits the menus.
INPUT Changes the input source.
/ ITurns the power on or off.
Remote Control Sensor
Standby Light
Lighting On:
When Power is turned off
Lighting Off:
When Power is turned on
Touch Buttons
Front
ENGLISH
9
ASSEMBLING AND PREPARING
All of the buttons are touch sensitive and can be operated through simple touch with your finger.
NOTE
Touch button Description
Scrolls through the saved channels.
Adjusts the volume level.
OK Selects the highlighted menu option or confirms an input.
SETTINGS Accesses the main menus, or saves your input and exits the menus.
INPUT Changes the input source.
/ ITurns the power on or off.
Remote Control Sensor
Standby Light
Lighting On:
When Power is turned off
Lighting Off:
When Power is turned on
Touch Buttons
29LN549M
