OWNER’S MANUAL
LED LCD TV
M1931D
M2631D
Please read this manual carefully before operating the your TV and
retain it for future reference.
LED LCD TV MODEL
ENGLISH
2
ENGLISH
TABLE OF CONTENTS
TABLE OF CONTENTS
3LICENSES
4INSTALLATION PROCEDURE
5ASSEMBLING AND PREPARING
5 Unpacking
7 Parts and buttons
8 Lifting and moving the TV
9 Setting up the TV
9 - Attaching the Stand
12 - Mounting on a table
13 - Tidying cables
14 - Detaching the Stand
16 - Mounting on a wall
18 WATCHING TV
18 Turning the TV on for the first time
20 MAKING CONNECTIONS
20 Connecting an antenna
21 Connecting to a HD receiver, DVD, VCR
player or Gaming device
21 - HDMI connection
22 - HDMI to DVI connection
23 - Component connection
24 - Composite connection
25 - Euro Scart connection
26 Connecting to a USB
26 Connecting to a CI Module
27 Connecting to a PC
28 - HDMI connection
29 - HDMI to DVI connection
30 - RGB connection
31 REMOTE CONTROL
33 CUSTOMIZING SETTINGS
33 Accessing main menus
34 USING THE USER GUIDE
34 Accessing User Guide menu.
34 - Using the TV menu
34 - Using the Remote Control
35 MAINTENANCE
35 Cleaning Your TV
35 Screen and frame
35 Cabinet and stand
35 Power cord
36 Preventing “Image burn” or “Burn-in” on
your TV screen
37 TROUBLESHOOTING
37 General
38 SPECIFICATIONS
ENGLISH
3
LICENSES
LICENSES
Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories. “Dolby “and the
double-D symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a
subsidiary of Rovi Corporation. This is an official DivX Certified® device that
plays DivX video. Visit divx.com for more information and software tools to
convert your files into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be
registered in order to play purchased DivX Video-on-Demand (VOD) movies.
To obtain your registration code, locate the DivX VOD section in your device
setup menu. Go to vod.divx.com for more information on how to complete
your registration.
DivX Certified® to play DivX® video up to HD 1080p, including premium
content.
DivX®, DivX Certified® and associated logos are trademarks of Rovi
Corporation or its subsidiaries and are used under license.
Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668;
7,515,710; 7,519,274
ENGLISH
4INSTALLATION PROCEDURE
INSTALLATION PROCEDURE
1Open the package and make sure all the accessories are included.
2Attach the stand to the TV.
3Connect an external device to the TV.
yImage shown may differ from your TV.
yYour TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.
yThe available menus and options may differ from the input source or product model that you are
using.
yNew features may be added to this TV in the future.
NOTE
ENGLISH
5
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and accessories.
yThe accessories supplied with your product may vary depending on the model.
yProduct specifications or contents in this manual may be changed without prior notice due to
upgrade of product functions.
NOTE
yDo not use any pirated items to ensure the safety and product life span.
yAny damages or injuries by using pirated items are not covered by the warranty.
CAUTION
yThe items supplied with your product may vary depending on the model.
yProduct specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
yFor an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm thick
and 18 mm width. Use an extension cable that supports USB 2.0 if the USB cable or USB memory
stick does not fit into your TV’s USB port.
NOTE
*A 10 mm
*B 18 mm
A
B
A
B
ENGLISH
6ASSEMBLING AND PREPARING
Remote control.
Batteries (AAA).
Power Cord.
Stand Base.
CD (Owner's Manual).
Cards.
Stand Body.
(Only M1931D)
Cable Tie.
(See p.31, See p.32)
(See p.12)
(See p.9, See p. 14)
(See p. 10, See p. 15)
(See p.9, See p. 14) (See p. 10, See p. 15)
(See p.13)
M2631D
M1931D
Screws for Assembly.
2 EA
(Only M2631D)
(See p. 10, See p. 15)
Stand Body.
(Only M2631D)
AC-DC Adapter.
or
(See p.12)
AC-DC Adapter.
( Depending on the country )
(See p.12)
( Depending on the country )
ENGLISH
7
ASSEMBLING AND PREPARING
Parts and buttons
All of the buttons are touch sensitive and can be operated through simple touch with your finger.
NOTE
Touch button Description
Scrolls through the saved programmes.
Adjusts the volume level.
OK Selects the highlighted menu option or confirms an input.
SETTINGS Accesses the main menus, or saves your input and exits the menus.
INPUT Changes the input source.
/ITurns the power on or off.
Remote Control Sensor
Standby Light
yLighting On: Turned off
yLighting Off: Turned on
Connection panel (See p.20)
Touch Buttons
ENGLISH
8ASSEMBLING AND PREPARING
yWhen holding the TV, the screen should face
away from you to prevent the screen from
scratches.
yWhen transporting the TV, do not expose the
TV to jolts or excessive vibration.
yWhen transporting the TV, keep the TV
upright, never turn the TV on its side, or tilt
towards the left or right.
Lifting and moving the TV
When moving or lifting the TV, read the following
to prevent the TV from being scratched or
damaged and for save transportation regardless of
its type and size.
Avoid touching the screen at all times, as
this may result in damage to the screen or
some of the pixels used to create images.
CAUTION
yIt is recommended to move the TV in the
box or packing material that the TV originally
came in.
yBefore moving or lifting the TV, disconnect
the power cord and all cables.
yHold the top and bottom of the TV frame
firmly. Make sure not to hold the transparent
part, speaker, or speaker grill area.
ENGLISH
9
ASSEMBLING AND PREPARING
3Attach the Stand Base from the Stand Body by
turning the screw to the right with a Coin.
Setting up the TV
Attaching the Stand
If you are not mounting the TV to a wall, use the
following instructions to attach the stand.
1Place the TV with the screen side down on a
flat and cushioned surface.
2Attach the Stand Body from the TV.
yLay a foam mat or soft protective cloth
on the surface to protect the screen from
damage.
yWhen attaching the stand to the TV,
place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
CAUTION
Tighten the screws firmly to prevent the TV
from tilting forward. Do not over tighten.
CAUTION
M1931D
ENGLISH
10 ASSEMBLING AND PREPARING
4Attach the Stand Base from the Stand Body by
turning the screw to the right with a Coin.
If you are not mounting the TV to a wall, use the
following instructions to attach the stand.
1Place the TV with the screen side down on a
flat and cushioned surface.
2Attach the Stand Body from the TV.
Insert the two Lockers of the Stand Body right
into the groove of the TV head and secure
them by pressing the left and right bottom
sides.
3Secure the TV and the Stand Body with the
2 screws.
Locker
Tighten the screws firmly to prevent the TV
from tilting forward. Do not over tighten.
CAUTION
If you don`t fasten the screw tightly, TV will
fall down and get damaged.
WARNING
M2631D
