LG 9LS3500-ZA Manuel utilisateur

www.lg.com

OWNER’S MANUAL

LED LCD TV / LCD TV

Please read this manual carefully before operating

your set and retain it for future reference.

LS35**

LS34**

CS46**

P/NO : MFL67409508(1208-REV07)

Printed in Korea

A-2 TABLE OF CONTENTS

LANGUAGE

COMMON

TABLE OF CONTENTS

A-3 SETTING UP THE TV

A-3 Attaching the stand

A-6 Tidying cables

A-7 Not using the Desk-Type Stand

LANGUAGE LIST

English

Русский

Қазақша

Українська

B-1 MAKING CONNECTIONS

B-1 Antenna connection

B-2 Satellite dish connection

B-3 Adapter connection

B-4 HDMI connection

B-6 Component connection

B-7 Composite connection

B-8 USB connection

B-8 CI module connection

B-9 Euro Scart connection

B-13 SPECIFICATIONS

A-3

SETTING UP THE TV

19/22/26LS35**

Model 19/22LS35** 26LS35**

Standard screw P4 x 16 M4 x 14

Number of screw 2EA 2EA

32LS35**

Screw(Stand+Head)

M4 x 14

Screw(Stand+Head)

M4 x 14

4EA

Stand Body

Stand Base

Stand Body

Stand Base

Screw(Stand+Head)

M4 x 14

Screw(Stand+Head)

M4 x 14

P4 x 16

4EA

SETTING UP THE TV

Attaching the stand

Image shown may differ from your TV.

A-4 SETTING UP THE TV

26CS46** 32/42CS46**, 32/42LS340*

Stand Body

Stand Base

M4 x 20

4EA

M4 x 20

4EA

Stand Body

Stand Base

M4 x 20

4EA

M4 x 20

4EA

A-5

SETTING UP THE TV

P4 x 16

2EA

M4 x 20

4EA

P4 x 16

4EA

M4 x 14

4EA

32LS345* 42LS345*

Stand Body

Stand Base

Stand Body

Stand Base

A-6 SETTING UP THE TV

Tidying cables

Gather and bind the cables with the cable holder.

(Only 19LS35**)

Cable Holder

(Only 22/26LS35**)

Cable Holder

(Only 32LS35**, 32/42LS345*)

Cable Holder

CAUTION

yDo not move the TV by holding the cable

holder, as the cable holders may break, and

injuries and damage to the TV may occur.

CAUTION

yWhen attaching the stand to the TV

set, place the screen facing down on a

cushioned table or flat surface to protect the

screen from scratches.

yMake sure that the screws are inserted

correctly and fastened securely. (If they are

not fastened securely enough, the TV may

tilt forward after being installed.)

Do not use too much force and over tighten

the screws; otherwise screw may be

damaged and not tighten correctly.

NOTE

yRemove the stand before installing the TV

on a wall mount by performing the stand

attachment in reverse.

A-7

SETTING UP THE TV

(Only 26/32/42CS46**, 32/42LS340*)

1 Gather and bind the cables with the cable

management.

2 Fix the cable management rmly to the TV.

Cable Management

CAUTION

yDo not move the TV by holding the cable

management, as the cable management may

break, and injuries and damage to the TV may

occur.

Not using the Desk-Type

Stand

(Only 26/32/42CS46**, 32/42LS340*, 32LS345*)

• When installing the wall mounting bracket,

use the Protection cover. This will protect the

opening from accumulating dust and dirt.

Push the supplied protection cover into the

opening at the bottom of the TV until it locks in

place.

Protection cover

NOTE

(Only 32LS345*)

yWhen removing Protection Cover from

bottom of TV insert your fingers into hole of

cover hold firmly and pull upwards towards

you to remove.

Protection cover

Please read this manual carefully before operating

your set and retain it for future reference.

www.lg.com

OWNER’S MANUAL

LED LCD TV / LCD TV

ENG

ENGLISH

TABLE OF CONTENTS

WARNING

yIf you ignore the warning message, you

may be seriously injured or there is a

possibility of accident or death.

CAUTION

yIf you ignore the caution message, you may

be slightly injured or the product may be

damaged.

NOTE

yThe note helps you understand and use

the product safely. Please read the note

carefully before using the product.

TABLE OF CONTENTS

3 LICENSES

3 OPEN SOURCE SOFTWARE NOTICE

4 SAFETY INSTRUCTIONS

10 INSTALLATION PROCEDURE

10 ASSEMBLING AND PREPARING

10 Unpacking

15 Parts and buttons

16 Lifting and moving the TV

17 Mounting on a table

19 Mounting on a wall

20 REMOTE CONTROL

21 ENTERTAINMENT

21 Wired Network Connection

21 Network setting

22 USING THE USER GUIDE

23 MAINTENANCE

23 Cleaning your TV

23 - Screen, frame, cabinet and stand

23 - Power cord

23 TROUBLESHOOTING
