LG 37LS575S Manuel utilisateur

담 당 관리자

Model Description

MODEL

BRAND

User’s Guide Specification

JO KIM

12.02.06

47LM760S

HJ SHIN

12.02.06

YJ JEON

12.02.07

MODEL

BRAND

Printing Specification

1. Trim Size (Format) : 182mm x 257 mm

2Piti Cl

Part No.

SUFFIX

47LM760S

MFL67441704

(1203-REV01)

Product Name 47LM760S

BEUWLJG

ors

Cover : 1 COLOR (BLACK)

Inside : 1 COLOR (BLACK)

3. Stock (Paper)

Cover : Coated paper , S/W 150 g/㎡

Inside : Uncoated paper , 백상지 60 g/㎡

4. Printing Method : Off-set

5. Bindery : Perfect bind

ENG/GER/FRE/ITA/SPA/POR/DUT/GRE(8)

anguage :

ENG/GER/FRE/ITA/SPA/POR/DUT/GRE(8)

7. Number of pages : 276

“This part contain Eco-hazardous substances (Pb, Cd, Hg, Cr6+, PBB, PBDE, etc.) within LG standard level,

Details should be followed Eco-SCM management standard[LG(56)-A-2524].

Especially, Part should be followed and controlled the following specification.

(1)Eco-hazardous substances test report should be submitted

Special Instructions

when Part certification test and First Mass Production.

(2) Especially, Don’t use or contain lead(Pb) and cadmium(Cd) in ink.

(1) Origin Notification

* LGEIN : Printed in Indonesia * LGEWA : Printed in U.K.

* LGESP : Printed in Brazil * LGEMX : Printed in Mexico

*G C *G

Changes

END : Printed in

hina

EIL : Printed in India

* LGEMA : Printed in Poland

REV.

NO. MM/DD/YY SIGNATURE CHANGE NO. CHANGE CONTENTS

03/28/12 Jeon Yoo Jeong EKLC301979 Added the model

Pagination sheet P/NO. MFL67441704

Total pages : 276 pages

Set u

Guide

(EN)

P/NO. ………A-2

Front

Cover

(EN)

…A-8

Blank

………

Blank

Front

Cover

(GE)

………227 Blank

Front

Cover

(FR)

………227 Blank

Front

Cover

(ITA)

………2…34

Front

Cover

(SP)

………227 Blank

Front

Cover

(PO)

………227 Blank

Front

Cover

(DU)

………227 Blank

Front

Cover

(GR)

………227 Blank

……

Back

Cover

(EN)

……

B-1 B-36 Blank

OWNER’S MANUAL

LED LCD TV

Please read this manual carefully before operating

your set and retain it for future reference.

LM62**

LM64**

LM66**

LM67**

LM76**

LS57**

P/NO : MFL67441704 (1203-REV01)

Printed in Korea

www.lg.com

A-2 TABLE OF CONTENTS

COMMON

LANGUAGE

TABLE OF CONTENTS

A-3 SETTING UP THE TV

A-3 Attaching the stand

A-7 Tidying cables

LANGUAGE LIST

English

Deutsch

Français

Italiano

Español

Português

Nederlands

Ελληνικά

B-1 MAKING CONNECTIONS

B-1 Antenna connection

B-2 Satellite dish connection

B-3 HDMI connection

B-6 DVI to HDMI connection

B-8 RGB-PC connection

B-9 Component connection

B-11 Composite connection

B-12 Audio connection

B-12 - Digital optical audio connection

B-14 USB connection

B-17 CI module connection

B-18 Headphone Connection

B-21 Euro Scart connection

B-29 SPECIFICATIONS

A-3

SETTING UP THE TV

Image shown may differ from your TV.

Attaching the stand

42/47LM669*

Protection pad

M4 x 20

4EA

Wrapping bag

M4 x 20

4EA

Front

Stand Base

Stand Body

Top View

A-4 SETTING UP THE TV

42/47/55LM660*, 42/47/55LM67**,

42/47/55LM760*, 42/47/55LM761*

Protection pad

M4 x 20

4EA

Wrapping bag

M4 x 20

4EA

Front

Top View

Stand Base

Stand Body

A-5

SETTING UP THE TV

42/47/55LM765*

Stand rear cover

Wrapping bag

Front

Top View

Stand base

Stand body

M4 x 20

4EA

Protection pad

M4 x 20

4EA

A-6 SETTING UP THE TV

32/37/42LS57**, 65LM62**, 32LM669*

M4 x 20

4EA

Front

Stand Base

Stand Body

Top View

M4 x 20

4EA

32/37/42/47/55LM62**, 32/42/47/55/60LM64**,

32LM660*

M4 x 20

4EA

M4 x 20

4EA

Front

Top View

Stand Base

Stand Body

A-7

SETTING UP THE TV

CAUTION

yWhen attaching the stand to the TV

set, place the screen facing down on a

cushioned table or flat surface to protect the

screen from scratches.

yMake sure that the screws are fastened

completely. (If they are not fastened securely

enough, the TV may tilt forward after being

installed.)

Do not fasten the screws with too much

force; otherwise they may be worn out and

get loosened.

NOTE

Remove the stand before installing the TV

on a wall mount by performing the stand

attachment in reverse.

Tidying cables

Only 32/37/42LS57**, 65LM62**, 32/42/47LM669*

1 Gather and bind the cables with the Cable

Holder.

Cable Holder

Only 32/37/42/47/55LM62**,

32/42/47/55/60LM64**, 32/42/47/55LM660*,

42/47/55LM67**, 42/47/55LM760*,

42/47/55LM761*

1 Gather and bind the cables with the Cable

Management.

2 Fix the Cable Management rmly to the TV.

Cable Holder

Cable Management

A-8 SETTING UP THE TV

42/47/55LM765*

1 Gather the cables with the stand rear cover.

Stand rear cover

2 Install the Cable Holder as shown.

Cable Holder

3 Gather and bind the cables with the Cable

Holder.

CAUTION

Do not move the TV by holding the cable

holders, as the cable holders may break, and

injuries and damage to the TV may occur.
