ENGLISH

SIMPLE MANUAL

DVD Home

Theater

System

To view the instructions of advanced features,

visit http://www.lg.com and then download Owner’s Manual.

Some of the content in this manual may differ from your unit.

MODEL

LHD655

*MFL69400849* www.lg.com

LHD655-FB.DEGYLLC_SIMPLE_ENG_0849.indd 1 2015-09-17  9:25:44

Front Panel Rear Panel

PORT. IN ··············Connect to a Portable device.

USB Port····················Connect a USB device.

R··························Disc Tray Open / Close

T·······················Starts / Pauses playback.

I·································Stops playback.

F············· Changes the input source or function.

- / +·······························Adjusts volume.

1/! ······························Power On / Off

SPEAKERS ··················· Connect to speakers.

HDMI OUT TO TV··················· Connect to TV.

AUX (L/R) INPUT······ Connect to analogue device.

VIDEO OUT ························ Connect to TV.

OPTICAL IN ·············· Connect to digital device.

ANTENNA FM ·········· Connect to radio antenna.

Speaker design and connection method may

be different according to models.

,

Speaker Connection2Speaker Assembling1

Front

(Right)

Front

(Left)

Center

Subwoofer

Unit

Surround

(Left) Surround

(Right)

LHD655-FB.DEGYLLC_SIMPLE_ENG_0849.indd 2 2015-09-17  9:25:46

TV

Home menu appears on the TV screen. Enjoy various

functions on the player.

TV Connection3 Home Menu4

HDMI & Optical Connection

aConnect the Player to the TV using HDMI &

Optical cable.

bSet the input selector to HDMI on the TV.

cSet up [External Speaker (Optical)] on your

TV setting menu.

dFollow the instructions on the TV screen

using remote control.

For more information, download the online owner’s manual. http://www.lg.com

LG Sound Sync

(Wireless)

LHD655-FB.DEGYLLC_SIMPLE_ENG_0849.indd 3 2015-09-17  9:25:47

Specication

Power

requirements Refer to main label.

Power

consumption

Refer to main label.

Networked standby : 0.4 W

(If all network ports are

activated.)

Dimensions

(W x H x D)

Approx. 360 mm x 60.5 mm x

299 mm

Net Weight Approx. 2.69 kg

Bus Power Supply

(USB) 5 V 0 500 mA

Amplier

(Total RMS output

power)

1,000 W

Design and specications are subject to change without

notice.

How to disconnect the wireless network

connection or the wireless device

Turn off the unit by pressing the power button for more

than 5 seconds.

Replacement of battery

Additional Information
