SIMPLE MANUAL
DVD Home
Theater
System
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
LHD625B
*MFL68882142* www.lg.com
ENGLISH PORTUGUÊS FRANÇAIS
LHD625-FB.DGHALLC_SIMPLE_ENG_2142.indd 1 2015-10-28 11:03:41
Front Panel Rear Panel
PORT. IN ··············Connect to a Portable device.
USB Port····················Connect a USB device.
R··························Disc Tray Open / Close
T·······················Starts / Pauses playback.
I·································Stops playback.
F············· Changes the input source or function.
- / +·······························Adjusts volume.
1/! ······························Power On / Off
SPEAKERS ··················· Connect to speakers.
HDMI OUT TO TV··················· Connect to TV.
AUX (L/R) INPUT······ Connect to analogue device.
VIDEO OUT ························ Connect to TV.
OPTICAL IN ·············· Connect to digital device.
ANTENNA FM ·········· Connect to radio antenna.
Speaker installation1
You can use the speaker in Stand type ( ) by adjusting
the angle or Wall type ( ) by mounting the speaker
to a wall.
Stand type
You can adjust angle of speaker.
Wall type (Mounting the speakers to a Wall)
When you want to mount the speaker to a wall, please
refer to below.
Speaker design and connection method may
be different according to models.
,
Speaker Connection2
Front
(Left)
Center
Subwoofer
Unit
Surround
(Left)
Front
(Right)
Surround
(Right)
LHD625-FB.DGHALLC_SIMPLE_ENG_2142.indd 2 2015-10-28 11:03:44
For more information, download the online owner’s manual. http://www.lg.com
LG Sound Sync
(Wireless)
TV Connection3
HDMI & Optical Connection
aConnect the Player to the TV using HDMI &
Optical cable.
bSet the input selector to HDMI on the TV.
cSet up [External Speaker (Optical)] on your TV
setting menu.
dFollow the instructions on the TV screen using
remote control.
Home menu appears on the TV screen. Enjoy various
functions on the player.
Home Menu4
TV
LHD625-FB.DGHALLC_SIMPLE_ENG_2142.indd 3 2015-10-28 11:03:44
Specication
Power
requirements Refer to main label.
Power
consumption
Refer to main label.
Networked standby : 0.4 W
(If all network ports are
activated.)
Dimensions
(W x H x D)
Approx. 360 mm x 60.5 mm x
299 mm
Net Weight Approx. 2.69 kg
Bus Power Supply
(USB) 5 V 0 500 mA
Amplier
(Total RMS output
power)
1,000 W
Design and specications are subject to change without
notice.
How to disconnect the wireless network
connection or the wireless device
Turn off the unit by pressing the power button for more
than 5 seconds.
Replacement of battery
Additional Information
LHD625-FB.DGHALLC_SIMPLE_ENG_2142.indd 4 2015-10-28 11:03:45
