FCC CONCERNS

RF Exposure Statement:

The antenna(s) used for this device must not be co-located or operating in conjunction

with any other antenna or transmitter.

Do not

Any changes or modifications to the equipment not expressly approved by

the party responsible for compliance could void user’s authority to operate

the equipment.

The LG Bluetooth® headset HBM-560 is a light weight wireless Headset

utilizing Bluetooth® technology.

This product can be used as an audio accessory for devices supporting

either the Headset or Handsfree Bluetooth® Profiles.

■Included in package

■Change direction

■Charging

- Remove the cover on the charging port and connect the charger.

- When the charger is connected, with power on or off, the headset will

turn off. While charging, the LED indicator will show a solid blue light.

- The buttons will not function while the device is charging.

- It takes 2 hours to fully charge the headset.

- When charging is complete, the LED indicator will turn off.

■Low battery

- The LED indicator will blink blue when the battery power is low.

- When the battery is not charged, the LED indicator will blink blue and

then turn off.

■Power on

- Press and hold the PWR/END button for 2 seconds.

●The headset will turn on and a booting tone will play.

■Power off

- Press and hold the PWR/END button for at least 2 seconds.

● A shutdown tone will play, the Bluetooth® link will disconnect, and the

headset will turn off.

■Pairing

- Prior to using the Headset for the first time, you must pair it with a

Bluetooth-enabled handset.

- Enter the pairing mode with pressing and holding the CALL button for 5

seconds.

● You will hear two short beeps and the LED indicator will show a solid

blue light, when the device enters Pairing Mode.

▶Using your Handset, find the Bluetooth® Menu and "search for" or

"add” new devices.

▶Select ”LG HBM-560” from the list of devices and pair it with your

handset.

▶When asked for the Pass/PIN code during the pairing procedure,

please enter “0000” (4Zeros).

● Once pairing has completed successfully, you will hear a beep.

▶After pairing successfully, be sure to “Connect” to the HBM-560.

● If you want to pair with other devices in the future, the headset must be

placed in Pairing Mode.

● If the HBM-560 is in "Pairing Mode" for 3 minutes, without being paired

to a device, the Headset will automatically turn off.

■Auto Reconnect

When the HBM-560 turns off accidentally or intentionally during connected

condition, the headset and handset will disconnect.

The Headset and handset will automatically reconnect without pairing

when the HBM-560 turns on. HBM-560 will enter the pairing mode if

there’s no device to connect (Easy Pairing)

[ Out of range ]

- When the HBM-560 and your handset are separated by a distance of 33

feet (10meters) or more, the headset and handset will disconnect. When

the handset and HBM-560 are brought back within the required distance,

the HBM-560 will automatically reconnect with the handset.

- If the headset and handset do not automatically reconnect when they are

back within the required range, briefly press the CALL button to reconnect

manually.

■Volume control

- Briefly press the VOLUME UP or VOLUME DOWN button to adjust the

speaker volume.

- There are eight levels of speaker volume.

■Answering a call

- When there is an incoming call, the Headset will ring.

- Briefly press the CALL button to answer an incoming call.

Making a call

- If you make a call from the Handset, the call will (subject to phone

settings) transfer automatically to the Headset. If not automatically

transferred, you can transfer the call manually by briefly pressing the

CALL button on the HBM-560 (headset and handset must be paired).

Voice dialing*

- Briefly press the CALL button. (You will get the best results if you record

the voice dialing tag through your Headset.)

NOTE : If the Handset does not support the Voice Dial, the Headset will

activate the last number redialing.

Last number redial*

- Press and hold the CALL button for 1second to activate "Last Number

Redial". The headset will beep, and call the last number dialed.

Ending a call

- Briefly press the CALL button.

Transferring a call*

- While on a call on your handset, briefly press the CALL button on the

HBM-560 to transfer the audio to the headset.(headset and handset must

be paired).

- And to transfer a call from the Headset to Handset, press and hold

VOLUME UP button for 5 seconds.

Call waiting*

- Answer a second call without hanging up the first call by pressing the

CALL button for 1seconds. Press the CALL button for 1seconds to return

to the original call.

- Briefly press the CALL button to terminate the active call.

Call reject*

Activate call reject by pressing the CALL button for 1 second when

receiving a call.

* It is possible to use these functions only when your Handset supports

them.

For further information about using these features please consult your

Handset's user manual.

Function HBM-560 Status Action

Power on Power off Press the PWR/END button for at

least 2 seconds

Power off Power on Press the PWR/END button for at

lea

Volume Up Talking Briefly press the Volume Up

button

Volume Down Talking Briefly press the Volume Down

button

Transferring a call Talking

- Handset to Headset

Briefly press the CALL button

- Headset to Handset

Press and hold the VOLUME

UP button for 5 seconds

Answering a call Ringing Briefly press the CALL button

Ending a call Talking Briefly press the CALL button

Call waiting Talking Press the CALL button for 1

second

Last number

redialing Idle Press the CALL button for 1

second

Voice dialing

(Handset must support) Idle Briefly press the CALL button

Call Reject Ringing Press the CALL button for 1

second

Pairing mode Power Off or Idle Press the CALL button for 5

seconds
