LG DLE3777 Manuel utilisateur

Guide du propri taire

S cheuse gaz et lectrique

DLE5977W / DLG5988W

DLE5977B / DLG5988B

DLE3777W / DLG3788W

DLE5977S / DLG5988S

DLE5977WM / DLG5988WM

DLE5977SM / DLG5988SM

DLE5977BM / DLG5988BM

Merci d’avoir acheté une sécheuse LG. Lire attentivement ce

guide car il fournit des instructions pour une installation

sécuritaire, et l’utilisation et l’entretien.

Noter les numéros de modèle et de série et conserver à des fins

de références.

Pour plus de détails, visiter notre site web au http://us.lge.com

Electric and Gas Dryer

Guide du propri taire

P/No.: 3828EL3003B

DLE5977W / DLG5988W

DLE5977B / DLG5988B

DLE3777W / DLG3788W

DLE5977S / DLG5988S

DLE5977WM / DLG5988WM

DLE5977SM / DLG5988SM

DLE5977BM / DLG5988BM

P/No.: 3828EL3003B

Thank you for buying a LG Dryer.

Please read your manual carefully, as it provides instructions on

safe Installation, Use and Maintenance.

Record the Model and Serial Numbers, and retain the manual

for future reference.

For more information, visit our website at http://us.lge.com

PRODUCT FEATURES

TABLE OF CONTENTS

PART1. SPECIFICATIONS ..................................................................................................................................................................................3

PART2. IMPORTANT WARRANTY AND SAFETY INSTRUCTIONS ..............................................................................................................4-6

PART3.INITIAL STEPS FOR INSTALLING YOUR DRYER ..........................................................................................................................7-12

PART4.ACCESSORIES INSTALLATION ....................................................................................................................................................13-14

PART5. ELECTRICAL REQUIREMENTS FOR ELECTRIC DRYER..................................................................................................................15

PART6. ELECTRICAL REQUIREMENTS FOR GAS DRYERS .........................................................................................................................16

PART7. GAS REQUIREMENTS AND INSTRUCTIONS.....................................................................................................................................17

PART8. EXHAUST REQUIREMENTS AND MAINTENANCE.......................................................................................................................18-19

PART9. OPERATING YOUR DRYER............................................................................................................................................................20-25

PART10. TROUBLESHOOTING GUIDE .......................................................................................................................................................26-28

LG DRYER LIMITED WARRANTY .....................................................................................................................................................................29

OUTSTANDING PERFORMANCE

Not to mention unmatched big capacity, you can benefit from good

time efficiency, quiet operation and energy saving system.

STAINLESS STEEL DRUM

Stainless steel drum doesn’t generate any rust by nature so that

rust-free drum keeps clothes away from stain all time.

ARTISTIC DESIGN

Modern front panel look and big crystal-clear glass door make your dryer look stylish.

DIGITAL FABRIC CARE

Multi-Level temperature control takes better care of your clothes

EASY OF USE

An entire selection of user-friendly functions make operating the dryer easy.

USING THE RLM (REMOTE LAUNDRY MONITOR)

The RLM monitors status of your washer and/or dryer. You can plug the display unit into any power

outlet in your home. The RLM Display Unit can be purchased separately for this dryer.

(DLE5977WM, DLG5988WM, DLE5977SM, DLG5988SM, DLE5977BM, DLG5988BM)

What are Sensor Dry and Time Dry?

Your dryer provides sensor drying and time drying programs.

Sensor Dry : Dryer senses electronically laundry humidity and it automatically determines operation time

based on the dryness of the load and the selected program. At times, you can see sudden increase or

decrease on operation time. It happens because a sensor will detect laundry humidity with a certain period.

Sudden change on operation time is not a malfunction.

Time Dry : Time Dry is that you can set operation time manually to complete drying. Or use Time Dry to have

drying performance if clothes are still damp after sensor dry cycle is finished. Time Dry is more effective for

heavyweight and bulky items such as king-size bed sheets and thick work clothes.

Part 1 SPECIFICATIONS

■Type : Electric and Gas Dryer

■Rating : Please refer to the rating label regarding detailed information.

■Size : 27 x 29.9 x 38.7(inch)

■Capacity : IEC 7.3cu.ft. (22.5 lb)

■Weight : 126 Ibs (57.2 kg)

Specifications are subject to change by manufacturer.

■ ACCESSORIES

Dryer rack (1 each)

See page 26 for how to use. See page 13 for how to use. See page 14 for how to use.

Stacking kit (1 each)

Purchased Separately Pedestal (1 each)

Purchased Separately

Remote Laundry

Monitor

Purchased Separately

(DLE5977WM, DLG5988WM,

DLE5977SM, DLG5988SM,

DLE5977BM, DLG5988BM)

❊ Design of pedestals are subject to

change wichat manafaturers notice.

Electric and Gas Dryer

Guide du propri taire

P/No.: 3828EL3003B

DLE5977W / DLG5988W

DLE5977B / DLG5988B

DLE 777W / DLG 788W

DLE5977S / DLG5988S

DLE5977WM / DLG5988WM

DLE5977SM / DLG5988SM

DLE5977BM / DLG5988BM

DLE5977SM / DLG5988SM

DLE5977BM / DLG5988BM

P/No.: 3828EL3003B

Thank you for buying a LG Dryer.

Please read your manual carefully, as it provides instructions on

safe Installation, Use and Maintenance.

Record the Model and Serial Numbers, and retain the manual

for future reference.

For more information, visit our website at http://us.lge.com

Part 2

IMPORTANT WARRANTY AND SAFETY INSTRUCTIONS

SEEKING WARRANTY ASSISTANCE

WARNING!

For your safety, the recommendations in this manual must be followed. To reduce the risk

of fire or explosion, electric shock, or to prevent property damage, personal injury, or

death when using your appliance, follow basic precautions, including the following.

The Warranty for your Dryer is located at the end of this manual. Warranty Service is

available by contacting your nearest G Service Center. If this product is installed and

operated per this manual, G will repair or replace any parts defective in material or

workmanship throughout the Warranty period, beginning the Date of Purchase.

Warranty Restriction: If the dryer is subjected to other than private family use, all warranty

coverage is effective for only 90 days.

You will need the complete Model and Serial Number when requesting Warranty Service. Proof of

purchase date is required.

Use the space below to record the model number and serial number of your new LG dryer.

Model No.

Serial No.

Date of Purchase

❈ Staple your receipt HERE.

Part 2 IMPORTANT WARRANTY AND SAFETY INSTRUCTIONS

1) Read all instructions before using the appliance.

2) Do not dry articles that have come into contact with

gasoline, dry-cleaning solvents, or other flammable

or explosive substances, as they give off vapors that

could ignite or explode.

3) Do not allow children to play on or in the appliance.

Close supervision of children is necessary when

using the appliance.

4) Before the appliance is removed from service or

discarded, remove the door to the drying

compartment.

5) Do not reach into the appliance if the drum is

moving.

6) Do not install or store this appliance where it will be

exposed to the weather.

7) Do not tamper with controls.

8) Do not repair or replace any part of the appliance or

attempt any servicing unless specifically

recommended in the user-maintenance instructions.

9) Do not use heat to dry articles containing foam

rubber or similarly textured rubber-like materials.

10) Clean lint screen before or after each load.

11) Keep area around the exhaust opening and adjacent

surrounding areas free from the accumulation of

lint, dust, and dirt.

12) The interior of the appliance and exhaust duct

should be cleaned periodically by qualified service

personnel.

13) Do not place items exposed to cooking oils in your

dryer. Items contaminated with cooking oils may

contribute to a chemical reaction that could cause a

load to catch fire.

14) Do not use fabric softners or products to eliminate

static unless recommended by the manufacturer of

the fabric softner or product.

GROUNDING INSTRUCTIONS

This appliance must be grounded. In the event of

malfunction or breakdown, grounding will reduce the

risk of electric shock by providing a path of least

resistance for electric current. This appliance is

equipped with a cord having an equipment-grounding

conductor and a grounding plug. The plug must be

plugged into an appropriate outlet that is properly

installed and grounded in accordance with all local

codes and ordinances.

WARNING - Improper connection of the equipment-

grounding conductor can result in a risk of electric

shock. Check with a qualified electrician or service

person if you are in doubt as to whether the appliance is

properly grounded.

Do not modify the plug provided with the appliance: if

it will not fit the outlet, have a proper outlet installed by

a qualified electrician.

This appliance must be connected to a grounded metal,

permanent wiring system or an equipment-grounding

conductor must be run with the circuit conductors and

connected to the equipment-grounding terminal or lead

on the appliance.

WARNING!

To help reduce any risk of electric shock, fire, or other personal or property injury

when using your dryer, please exercise care and follow basic safety precautions,

including the following:

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

Part 2

IMPORTANT WARRANTY AND SAFETY INSTRUCTIONS

• Do not try to light a match or cigarette, or turn

on any gas or electrical appliance.

• Do not touch any electrical switches. Do not

use any phone in your building.

• Clear the room, building or area of all

occupants.

• Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s

instructions carefully.

• If you cannot reach your gas supplier, call the

fire department.

To reduce the risk of fire or explosion, electric

shock, property damage, personal injury or death

when using this appliance, please follow all

instructions and information, including those in

this manual and instructions and information

provided by your gas supplier, including the

following:

• Do not store or use any gasoline, dry-cleaning

solvents any other flammable vapors or

liquids in the area surrounding this appliance.

• Do not dry anything that has ever had anything

flammable on it, even after washing.

• No washer can completely remove oil. Do not

dry any articles that have ever had any kind of

oil on them, including cooking oil.

• Articles containing foam, rubber, rubber-like

materials, plastic or similar materials should be

dried on a clothesline or by using an air cycle.

• Failure to follow these instructions can result in

fire, death or serious injury.

• A qualified service person or company must

perform installation and service of this

appliance.

California Safe Drinking Water

and Toxic Enforcement Act

This act requires the governor of California to

publish a list of substances known to the state to

cause cancer, birth defects or other reproductive

harm and requires businesses to warn customers

of potential exposure to such substances.

Gas appliances can cause minor exposure to four

of these substances, namely benzene, carbon

monoxide, formaldehyde and soot, caused

primarily by the incomplete combustion of

natural gas or LP fuels.

Properly adjusted dryers will minimize

combustion. Exposure to these substances can be

minimized further by properly venting the dryer

to the outdoors.

WHAT TO DO IF YOU SMELL

GAS:

WARNING!

• Keep flammable materials and vapors, such

as gasoline, away from dryer.

• Place dryer at least 18 inches above the floor

for a garage installation.

• Failure to do so can result in death,

explosion or fire.

WARNING

Part 3 INITIAL STEPS FOR INSTALLING YOUR DRYER

The following instructions will help guide you through the initial steps of setting up your dryer for use.

Please note that every section of this manual provides important information regarding the preparation and

use of your dryer, and it is important that you review this entire manual before proceeding with any

installation or use. More detailed instructions concerning electrical connections, gas connections, and

exhaust requirements are provided at other parts of this manual.

Choose a location with a solid floor for your dryer.

Place the dryer at least eighteen inches above the

floor for a garage installation. After placing the

dryer in the desired location, please make sure that

it has the required clearances shown below, and

sections on Exhaust and Maintenance requirements.

If you are installing your dryer in a manufactured or

mobile home, please refer to STEP 9 below for

additional instructions.

Certain minimum clearances are required

above, behind, and to the sides of the unit, as

shown below.Those required minimum clearances

are set forth in the picture below. Please also keep the

following instructions in mind when installing in a

closet or recessed area:

• Consider allowing additional clearance for

installation and servicing.

• Wall, door and floor molding may force additional

clearances.

• An additional inch of clearance is recommended to

minimize noise transfer .

• Consider space needed for companion appliances.

• For closet installations, the picture below shows the

minimum required ventilation openings for the door.

A louvered door with comparable ventilation openings

is also acceptable.

* Most installations require a minimum 5 1/2 in.

(14 cm) clearance behind the dryer for the exhaust

vent with elbow.

<Closet-Side view><Closet door>

ventilation

hole

ventilation

hole

<Closet-Front view>

38.7”

(98.3 cm)

27”

(68.6 cm)

29.96”

(76.1 cm)

49.8”

(126.4 cm)

STEP 1 Positioning the Dryer.

Leveling legs should be secured.

All four legs are stably placed on the solid and

even floor.

If dryer is not level, laundry may not tumble

properly and sensor will not detect the accurate

humidity information.

When adjusting leveling, please be cautious not to

have serious injuries on your fingers and toes.

Note

Part 3 INITIAL STEPS FOR INSTALLING YOUR DRYER

Once in position, adjust the leveling legs of the dryer

until it is level from left to right and from front to

back. The leveling legs must remain firmly on the

floor and the dryer should not rock. The maximum

slope of the dryer from left to right or from front to

back should not exceed 2.5 cm (1 inch). If the dryer

is not level, and if the slope exceeds 2.5 cm (1 inch),

a load may not tumble properly and internal sensors

may malfunction. Note: Other sections of this

manual also provide important information

concerning the placement of and clearances for your

dryer. Please review this entire manual before

proceeding with any installation.

The door on your dryer can be installed to open

either to the left or the right. Follow these

procedures to reverse the direction in which your

door opens:

STEP 2:

STEP 2 Procedure for Reversing

the Door

Door and latch should be aligned at the center

when closed. Otherwise, door is improperly closed

and opened.

Note

Autres manuels pour DLE3777

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels LG Séchoir

LG RH10V9 V Series Manuel utilisateur

LG DLEX3885W Manuel utilisateur

LG DLEX4270W Manuel utilisateur

LG DLE2140 Series Manuel utilisateur

LG DLGX2551R Manuel utilisateur

LG Tromm DLE5955W Mode d’emploi

LG DL X670 Seies Manuel utilisateur

LG DLE2350W Manuel utilisateur

LG Tromm DLEX7177RM Mode d’emploi

LG DLEY1201 Manuel utilisateur

LG DLE0442W Manuel utilisateur

LG SteamDryer DLGX2802 Manuel utilisateur

LG TD-V10150G Manuel utilisateur

LG DLGX3071 Series Manuel utilisateur

LG TDD15515S Manuel utilisateur

LG DLE2511W Manuel utilisateur

LG DLEX3250 Series Manuel utilisateur

LG DLGX3471 Series Manuel utilisateur

LG TDN12240G Manuel utilisateur

LG DLG7401 E Series Manuel utilisateur

LG DVH10-10B Manuel utilisateur

LG DLEV833 Manuel utilisateur

LG DLG3461 Series Manuel utilisateur

LG RC8055*H Series Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
