CAUTION : The laser used in the CD-RW/DVD-ROM drive can damage your eyes.

Do not attempt to open the cover.

To reduce the risk of electric shock, do not remove cover (or back).

No user-serviceable parts inside.

Refer servicing to qualified service personnel.

Use of controls or performance of procedures other than those specified

herein may result in hazardous radiation exposure.

WARNING : To reduce the risk of fire or electric shock, do not expose this appliance to

rain or moisture

Industry Canada requirement

This class B digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulations.

Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le

matériel brouilleur du Canada.

FCC COMPLIANCE STATEMENT

Note : This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

- Consult the dealer or an Authorized Service Center for help.

• FCC WARNING

Changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

• This CD-RW/DVD-ROM Drive is for use only with UL listed personal computers that have

installation instructions detailing user-installation of card cage accessory.

English

This product is manufactured to comply with the radio interference requirements of

EEC DIRECTIVE 89/336/EEC, 93/68/EEC and 73/23/EEC.

CAUTION - INVISIBLE LASER RADIATION WHEN OPEN AVOID EXPOSURE TO BEAM.

VARNING-OSYNLIG LASERSTRÄLNING NÄR DENNA DEL ÄR ÖPPNAD STRÄLEN ÄR

FARLIG.

CLASS 1 LASER PRODUCT

KLASSE 1 LASER PRODUKT

LUOKAN 1 LASER LAITE

KLASS 1 LASER APPARAT

This unit uses CD-ROM discs with the following mark

When you use this unit as a CD player, use compact

discs with the following mark

This unit uses CD-R discs with the following mark.

This unit uses CD-RW discs with the following mark.

This unit uses High Speed CD-RW discs with the

following mark

This unit uses Ultra Speed CD-RW discs with the

following mark.

WARNING: Only CD-RW drivers bearing the logo Compact Disc ReWritable Ultra Speed can

write or erase Ultra Speed CD-RW media.

Ultra Speed CD-RW Media may be recognized by the same Compact Disc ReWritable Ultra

Speed logo on the disc label or packaging material.

Attempted writes to Ultra Speed CD-RW media using CD-RW drives NOT bearing the logo

Compact Disc ReWritable Ultra Speed may result in data loss.

Recordable

ReWritable

High Speed

ReWritable

Ultra Speed

DirectCDTM v2.5b(s)

Introduction

Installation

Operation

Appendix

Contents

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Important Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

System Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Location and Function of Controls . . . . . . . . . . . . . . . . . . . 5

Installing the Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Device Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

How to Use the Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

■Microsoft®and Windows®are trademarks registered in the United

States and other countries by the Microsoft Corporation.

■The company names and product names written in this manual are

trademarks or registered trademarks of the respective companies.

DirectCDTM v2.5b(s) Introduction

Thank you for

purchasing this

D-RW/DVD-

ROM Drive.

Package Items

Features

•Enhanced-IDE (ATAPI) interface.

•Power tray loading and ejection of disc.

(The disc can also be ejected manually.)

•Combination CD-R/RW and DVD-ROM Drive functions into one drive.

•Supports UDF for easy writing to CD-RW discs.

•Supports Region playback control Phase II.

•Supports Windows 95, 98, 2000, ME & XP/NT4.0.

•Supports Mt. Rainier.

•Automatic buffer underrun error prevention technology-SuperLink

•48X max Writing (CD-R), 24X max ReWriting (CD-RW),

16X max Reading (DVD-ROM), and 48X max Reading (CD-ROM)*.

* Writing speed depends on capabilities of discs.

As a result, for ultra speed write/rewrite, you should use media

labelled Ultra Speed Write/ReWritable discs

Item Quantity

- Internal CD-RW/DVD-ROM Drive 1

- CD Recording Software 1

- MPEG-2 Software(Power DVD) 1

- E-IDE (ATAPI) cable 1

- Audio Cable 1

- Mounting Screws 4

- Manual for CD-RW/DVD-ROM Drive 1

- Quick Manual for CD Recording Software 1

DirectCDTM v2.5b(s) Introduction

Precautions

Installation

Operation

Important Precautions

Follow these precautions when handling the drive or discs.

•Please take notice that the manufacturer of this equipment does not

offer any warranty against data loss due to inappropriate installation

or handling, or direct or indirect damages.

•Please take notice that the manufacturer will bear no responsibility

for direct or indirect damages caused by the use of this product or its

malfunction.

•Please take notice that the manufacturer will bear no responsibility for

damage to data caused by this product.

•Please backup (copy) all important data as protection against data

loss.

•Avoid placing the drive in a location subject to:

- high humidity

- high temperature

- excessive dust

- mechanical vibration

- direct sunlight

We recommend using the drive in a horizontal or vertical position.

Do not use it in tilted position.

•Don’t move the drive suddenly from a cold place to a warm one or

raise the room temperature suddenly. Condensation may occur,

causing abnormal operation.

•Make sure to remove the disc before moving the drive. The disc may

be damaged, causing data loss.

•Be careful to prevent foreign objects, such as liquids or metal, from

entering the drive. In case a foreign object enters the drive, please

consult the dealer where the drive was purchased.

•Don’t interrupt the electric power while the drive is operating.

•When connecting two IDE devices to the Primary or Secondary

connectors, make sure that the two devices are not configured as

both Master, or both Slave. If they are both set the same, Windows

may fail to run or recognize the drives.

•The total length of the IDE cable should be no more than 18 inches

(about 45 cm).

DirectCDTM v2.5b(s) Introduction

omputer

Software

❏ Occasionally the CD-R and CD-RW discs written by the CD-R/RW drive cannot be

read by other CD drives*.These unreadable discs may need to be read using the

CD-R/RW drive on which they were written.

* The disc written using the CD-R/RW drive might not be readable by CD-ROMs

other than Multi-read compatible (UDF compatible) CD-ROMs.

Multiread compatible (UDF compatible) CD-ROMs are:

1. CD-ROMs that can read low reflectance.

2. CD-ROMs that support Packet Write.

❏ Please note: Certain software (i.e. particularly those including Video playback)

may require a considerably increased specification PC to give acceptable

results. While this CD-RW/DVD-ROM drive can read DVD-video discs, decoding

them to display on your pc’s monitor requires separate MPEG decoding that is

done by separate hardware (either an MPEG decoder card or MPEG decoding

done by your video card), or separate software that you install to do MPEG

decoding. For further details, refer to the documentation that comes with MPEG

software.

Install the supplied CD Recording Software before using this unit.

System Environment

This unit can be operated in the system environment explained here.

350MHz (or faster) Pentium (for high speed,

500MHz or faster recommended)

75MB or more free space.

(The free space needed for writing depends on the

quantity of data.)

Enhanced-IDE interface (as Primary Slave,

Secondary Master or Slave)

5.25-inch half-height bay required

+5V/+12V power socket required

Windows 95/98/2000/ME/XP, Windows NT

Workstation Ver.4.0 or later*

CD-R : LG, Ricoh, Mitsubishi Chemical, Verbatim,

Taiyo Yuden, Mitsui Toatsu, TDK, Kodak, or

SKC discs are recommended.

CD-RW : Ricoh, Mitsubishi chemical, Verbatim,

Imation, Sony discs are recommended.

System

requirements

Hard disk

Interface

Drive bay

Power

Software Required OS

CD-R, CD-RW discs

CPU

Memory Windows 95/98 : 64MB or greater.

Windows NT Workstation Ver. 4.0: 64MB or greater

(128MB or over recommended)

Windows 2000:64MB or greater(128MB or over

recommended)

DirectCDTM v2.5b(s) Introduction

Front Panel

Rear Panel

Location and Function of Controls

DIGITAL

AUDIO

ANALOG

AUDIO INTERFACEPOWER

401+5GND+12

CSM

SLA

R G L

1 2 3 4 5

1. Digital Audio Output Connector

2. Analog Audio Output Connector

3. Jumper Connector

This jumper determines whether the drive is configured as a master or slave.

Changing the master-slave configuration takes effect after power-on reset.

4. IDE Interface Connector

Connect to the IDE (Integrated Device Electronics) Interface using a 40-pin

flat IDE cable.

NOTE : Do not connect or disconnect the cable when the power is on, as this

could cause a short circuit and damage the system. Always turn the power

OFF when connecting or disconnecting the cable.

5. Power Connector

1. Headphone Jack

2. Volume Control

3. Emergency Eject Hole

4. Stop/Eject Button

5. Disc Tray

6. Drive activity indicator (Read/Write)

12 43

DirectCDTM v2.5b(s) Installation

Before

Installation

Removing the

omputer

over

Mounting the

Drive

Installing the Drive

Before installing the drive, please note the following points.

■You will need the following:

•A screw driver of a suitable size to fit the securing screws

for the drive unit.

•The manual for the computer, so you can find the mounting

positions for the IDE controller cable.

■Turn off all peripheral appliances of the computer and the computer

itself, and disconnect their power cords from the wall sockets.

■

Discharge any static electricity on your person by touching the

computer covers, etc.

Make sure all peripheral devices of the computer and the computer itself

are turned off, and then remove the cover. Refer to the manual for the

computer for details about removing the cover.

NOTE : There may be sharp edges inside the computer so take care to

avoid injury.

1. Remove the 51/4″ drive bay panel from the computer. Refer to the

manual for the computer for details.

2. Insert the drive unit into the bay. Do not apply excessive pressure to

the cables inside the computer.

3. Secure the drive with the screws provided. If there is not enough

space behind the drive, connect the IDE and other cables before

securing the drive.

NOTE : This is a general installation guide. If your PC hardware appears

different, please consult your hardware manual for installing peripheral

devices.

READ

WRITE

READ

WRITE

DirectCDTM v2.5b(s) Installation

Jumper Setup

Before installation, set the jumper connector on the rear panel.

The drive can be connected as the Master or Slave on an EIDE (ATAPI)

interface. When several (up to four) EIDE devices are connected, each

must be set in a unique way. Specific knowledge of hardware and

software is necessary to install the drive.

NOTE : If two peripheral devices with the same settings are both con-

nected to the Primary or to the Secondary EIDE bus, the host computer

may fail to run or may malfunction. Careful attention is necessary.

DIGITAL

AUDIO

ANALOG

AUDIOINTERFACEPOWER

401+5GND+12

CSM

SLA

RGL

R G L C S M

S L A 39

ANALOG

AUDIO

CS: Cable Select (CSEL)

SL: Slave

MA: Master

NOTE : Only one jumper should be installed on the jumper connector.

If more than one jumper is installed, the drive may malfunction or be

damaged.

Master/Slave setting is determined by jumper installation on the Jumper

Connector. The following table shows the possible jumper settings.

If you use CSEL setting, the MASTER/SLAVE setting will be made

automatically, depending on the hardware configuration.

For details refer to the manual of your computer.

Name Function

Drive set as Master

Drive set as Slave

Drive mode set by CSEL on the

host IDE interface

(Master)

(Slave)

(Cable Select)

Autres manuels pour GCC-4480B

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels LG Lecteur CD/CDR

Manuels Lecteur CD/CDR populaires d'autres marques

Philips

Philips CDD3610 Manuel utilisateur

QPS

QPS Que!Fire Manuel utilisateur

Plextor

Plextor 12X-3 Mode d’emploi

Samsung

Samsung SN-324B Manuel utilisateur

Teac

Teac CD-211E Manuel utilisateur

SmartDisk

SmartDisk Firewire CD-R/W Manuel utilisateur

Axis

Axis CD-ROM SERVER Manuel utilisateur

Memorex

Memorex 32023234 - 52x32x52x External USB2.0 CD... Instructions d'installation

Yamaha

Yamaha CD Recordable/Rewritable Drive CRW3200 Manuel utilisateur

Sony

Sony CRX230AE Manuel utilisateur

Sony

Sony CRX - 160E Manuel utilisateur

Panasonic

Panasonic KX-LD742 Manuel utilisateur

Pioneer

Pioneer BDR-S13U-X Manuel utilisateur

Panasonic

Panasonic LK-MC606BP Manuel utilisateur

Panasonic

Panasonic CF-VCW Series Manuel utilisateur

Conner

Conner CFP2107 Series Manuel utilisateur

Sony

Sony CRX-1611 Manuel utilisateur

Plextor

Plextor 12-20C Mode d’emploi
