Color Video Camera

User Manual

Models: LV821

LV822

LV823

Before installing, operating or adjusting

this product, please read this instruction

booklet carefully and completely.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This lightning flash with arrowhead symbol

within an equilateral triangle is intended to

alert the user to the presence of uninsulated

dangerous voltage within the product’s enclo-

sure that may be of sufficient magnitude to

constitute a risk of electric shock to persons.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and mainte-

nance (servicing) instructions in the literature

accompanying the product.

FCC WARNING: This equipment may generate or use radio

frequency energy. Changes or modifications to this equip-

ment may cause harmful interference unless the modifica-

tions are expressly approved in the instruction manual. The

user could lose the authority to operate this equipment if

an unauthorized change or modification is made.

REGULATORY INFORMATION: FCC Part 15

This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide rea-

sonable protection against harmful interference when the

equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio fre-

quency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interfer-

ence to radio communications.

Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be

required to correct the interference at his own expense.

A suitable conduit entries, knock-outs or glands shall

be provided in the cable entries of this product in the

end user.

•

Caution: Danger of explosion if battery is incorrectly

replaced. Replaced only with the same or equivalent

type recommended by the manufacturer. Dispose

of used batteries according to the manufacturer’s

instructions.

Holes in metal, through which insulated wires pass,

shall have smooth well rounded surfaces or shall be

provided with brushings.

This Class A digital apparatus complies with Canadian

ICES-003.

Cet appareil numérique de la classe A est conforme à la

norme NMB-003 du Canada.

Warning: Do not install this equipment in a confined space

such as a bookcase or similar unit.

Warning: Wiring methods shall be in accordance with the

National Electric Code, ANSI/NFPA 70.

Warning: This is a class A product. In a domestic environ-

ment this product may cause radio interference in which

case the user may be required to take adequate measures.

Warning: To reduce a risk of fire or electric shock, do not

expose this product to rain or moisture.

•

Caution: This installation should be made by a qualified

service person and should conform to all local codes.

Caution: To avoid electrical shock, do not open the cabi-

net. Refer servicing to qualified personnel only.

Caution: The apparatus shall not be exposed to water

(dripping or splashing) and no objects filled with liquids,

such as vases, shall be placed on the apparatus.

To disconnect power from mains, pull out the mains

cord plug. When installing the product, ensure that the

plug is easily accessible.

Disposal of your old appliance

1. When this crossed-out wheeled bin

symbol is attached to a product it means

the product is covered by the European

Directive 2002/96/EC.

2. All electrical and electronic products

should be disposed of separately from

the municipal waste stream via desig-

nated collection facilities appointed by

the government or the local authorities.

3. The correct disposal of your old appli-

ance will help prevent potential negative

consequences for the environment and

human health.

4. For more detailed information about

disposal of your old appliance, please

contact your city office, waste disposal

service or the shop where you pur-

chased the product.

This product is manufactured to comply

with EMC Directive 2004/108/EC and Low

Voltage Directive 2006/95/EC.

European representative :

LG Electronics Service Europe B.V.

Veluwezoom 15, 1327 AE Almere,

The Netherlands (Tel : +31-036-547-8940)

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accor-

dance with the manufacturer's instructions.

8. Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug

has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If

the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or

pinched particularly at plugs, convenience receptacles,

and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the

manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table

specified by the manufacturer, or sold with the appa-

ratus. When a cart is used, use caution when moving

the cart/apparatus combination to avoid injury from

tip-over.

13. Unplug this apparatus during lightning storms or

when unused for long periods of time.

14. Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or

plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate nor-

mally, or has been dropped.

Important Safety Instructions

Power Supply

This camera must always be operated a AC 24 V or DC 12 V

Certified/Listed, class 2 power supply only.

Note:

Be careful of AC frequency when the camera is operated

with Line lock mode.

Handling of the unit

Be careful not to spill water or other liquids on the unit. Be

cautions not to get combustible or metallic material inside

the body. If used with foreign matter inside, the camera is

liable to fail or to get cause of fire or electric shock.

Remove dust or dirt on the surface of the lens with a

blower.

Use a dry soft cloth to clean the body. If it is very dirty,

use a cloth dampened with a small quantity of neutral

detergent then wipe dry.

Avoid the use of volatile solvents such as thinners,

alcohol, benzene and insecticides.

They may damage the surface finish and/or impair the

operation of the camera.

•

Operating and storage location

Avoid viewing a very bright object (such as light fittings)

during an extended period. Avoid operating or storing the

unit in the following locations.

Extremely hot or cold places (operating temperature

-10 °C to 50 °C, however, we recommend that the unit

be used within a temperature range of 0 °C to 45 °C)

Damp or dust place

Places exposed to rain

Places subject to strong vibration

Close to generators of powerful electromagnetic radia-

tion such as radio or TV transmitters.

•

Cautions for Safe Operation

Features............................................................................. 8

Features Chart............................................................................ 8

Part Names and Functions............................................... 9

Connections .................................................................... 11

Basic connection.....................................................................11

Installation ...................................................................... 12

Mounting the Camera without bracket..........................12

Mounting the Camera with bracket.................................14

Image Adjustment .................................................................16

Menu Operation.............................................................. 19

OSD Menu Overview.............................................................20

General Operation..................................................................22

Camera Identication Settings..........................................22

Exposure Settings...................................................................23

WDR/BLC setting...........................................................23

Brightness setting.........................................................24

AGC (Automatic Gain Control) setting..................25

SHUTTER (Shutter Speed) setting...........................25

SENS-UP setting ............................................................26

White Balance settings .........................................................26

Day/Night Setting ..................................................................27

Motion Detection Setting....................................................28

3D-DNR Setting.......................................................................29

Privacy Setting.........................................................................30

Special Menu Settings ..........................................................31

Setting the D-ZOOM (Digital Zoom ) level .........31

Setting the D-EFFECT (Digital eect) ....................32

Setting the SHARPNESS eect .................................32

Stabilizer setting ...........................................................33

Setting the COLOR eect ..........................................33

Setting the SYNC (Synchronization) ......................34

Setting the USER TITLE................................................34

Language Setting .........................................................35

Reset Settings ..........................................................................36

Specication ................................................................... 37

Contents

Features

This Color Video Camera is designed for installation in an

indoor video surveillance system.

This manual contains instructions on how to install and

manage the Color Video Camera in your video surveillance

system.

Should you require any technical assistance, please contact

authorized service center.

High resolution and high sensitivity with a 6 mm CCD.

Day & Night function.

BLC covers various light conditions

Excellent signal-to-noise ratio of 52 dB

Internal / Line Lock (External)

Power Supply : Automatically switch between

DC 12 V and AC 24 V

Line Lock when using AC 24 V.

Dome Cover : Vandal -Proof

•

Features Chart

This table shows the differences between the models.

Use LV823P-DB is used for the description, operation and

details provided in this operating guide.

Models WDR Sens-up Day & Night

LV823N/P-DB Yes Yes Filter change

LV822N/P-DB Yes No Filter change

LV821N/P-DB No Yes Filter change

LV821N/P-D2 No Yes Digital

aDome Cover

bLens Cover

cVideo output connector (BNC type)

dPower input connector

Supplies AC 24 V or DC 12 V from an external power

source.

eFocus lock lever

Fixes the focus position after adjusting.

fSetup menu control buttons

gVideo Out connector

Use this jack for checking the picture with portable

monitor when install the camera.

Part Names and Functions

hAzimuth adjuster

Adjusts the azimuth angle to obtain a level image.

iAzimuth lock screw

Fixes the azimuth angle after adjusting.

jZoom lock lever

Fixes the zoom position after adjusting.

kPan lock screw

Fixes the panning position after adjusting.

lCamera mounting bracket

This bracket is supplied for ceiling installation.

Ce manuel convient aux modèles suivants

Table des matières

Manuels caméscope populaires d'autres marques

Toshiba

Toshiba CAMILEO Z100 Manuel utilisateur

Panasonic

Panasonic NV-VS40B Manuel utilisateur

Canon

Canon RC 260 Manuel utilisateur

Sony

Sony Handycam DCR-DVD7E Manuel utilisateur

Brinno

Brinno TimeLapse TLC200 Manuel utilisateur

JVC

JVC GR-SXM68AC Guide de démarrage rapide

Panasonic

Panasonic AG-HMC152EN Manuel utilisateur

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Manuel utilisateur

MYDLINK

MYDLINK DCS-6100LH Manuel utilisateur

Sony

Sony video Hi8 Handycam CCD-TR555 Manuel utilisateur

SECURECOM

SECURECOM V-5014B Manuel utilisateur

Panasonic

Panasonic HDC-SD100 Manuel utilisateur

Sharper Image

Sharper Image U-VIDEO Manuel utilisateur

JVC

JVC AA-V15EG Manuel utilisateur

Canon

Canon LEGRIA HV40 Manuel utilisateur

Sony

Sony Handycam DCR-VX2000 Manuel utilisateur

RCA

RCA CC616 Manuel utilisateur

Panasonic

Panasonic NVM40 Manuel utilisateur
