Models: PHNFP14A0 / PSNFP14A0
TYPE: PI485 Gateway(C, R)
Please read this installation manual completely before installing the product.
Installation work must be performed in accordance with the national wiring
standards by authorized personnel only.
Please retain this installation manual for future reference after reading it
thoroughly.
INSTALLATION MANUAL
AIR
CONDITIONER
P/NO : MFL57868523
2485 Gateway(C, R)
PI 485 INSTALLATION MANUAL
TABLE OF CONTENTS
nSafety Precautions....................................................3~4
nPart Description .......................................................5~6
nInstallation Guide ....................................................7~12
nInstallation Steps .................................................................................7
nDIP Switch Configuration.................................................................8~9
nAdvanced Lock Control Type ...........................................................10
nCentral Controller Connection Diagram.............................................11
nExamples For Product Installation.....................................................12
nAccessory Parts .........................................................13
Safety Precautions
Installation Manual 3
Don't touch with the
hands while the power is
on
•
There is risk of fire or electric
shock.
Use standard
parts(connector).
•
Do not disassemble or repair
the product. There is risk of fire
or electric shock.
For electrical work, contact
the dealer, seller, a qualified
electrician, or an Authorized
Service Center.
•
Do not disassemble or repair
the product. There is risk of fire
or electric shock.
nInstallation
Safety Precautions
To prevent injury to the user or other people and property damage, the following instructions
must be followed.
nIncorrect operation due to ignoring instruction will cause harm or damage. The seriousness is
classified by the following indications.
nMeanings of symbols used in this manual are as shown below.
WARNING
CAUTION
This symbol indicates the possibility of death or serious injury.
This symbol indicates the possibility of injury or damage.
Be sure not to do.
Be sure to follow the instruction.
WARNING
Safety Precautions
4485 Gateway(C, R)
When the product is soaked (flooded or
submerged), contact an Authorized Service
Center.
• There is risk of fire or electric shock.
Be cautious that water could not enter the
product.
• There is risk of fire, electric shock, or product
damage.
nOperation
Use the correctly rated
breaker or fuse.
• There is risk of fire or electric
shock.
Do not install, remove, or re-
install the unit by yourself
(customer).
• There is risk of fire, electric
shock, explosion, or injury.
For installation, always
contact the dealer or an
Authorized Service Center.
• There is risk of fire, electric
shock, explosion, or injury.
Part Description
Installation Manual 5
Part Description
PHNFP14A0
PI485 GATEWAY(C)
BUS_B: RS-485 (-) Terminal
BUS_A: RS-485 (+) Terminal
Reset Switch: PI485(C) Reset
LED01G,02G,03G: Communication Status LED
LED1: RS-485 Communication Status LED
CN_OUT: Indoor Unit Connector
DIP Switch: Product Selection (Refer Page 8~10)
1
2
4
5
6
7
3
L1 2 3 4
1
2
3
4
5
6
7
6485 Gateway(C, R)
Part Description
PSNFP14A0
PI485 GATEWAY(R)
BUS_B: RS-485 (-) Terminal
BUS_A: RS-485 (+) Terminal
Reset Switch: PI485(R) Reset
LED01G,02G,03G: Communication Status LED
LED1: RS-485 Communication Status LED
CN_OUT: Indoor Unit Connector
DIP Switch: Product Selection (Refer Page 8~10)
6
7
2
5
3
1
4
L1 2 3 4
1
2
3
4
5
6
7
Installation Manual 7
Installation Guide
Installation Steps (PHNFP14A0/PSNFP14A0)
1. Select DIP Switch Configuration(Refer page 8 ~ 10)
2. Connect RS-485 BUS_A(+), BUS_(B)(-) with other network products (ex.
Simple Central Controller , ACP.....)
3. Connect CN_OUT with Indoor Unit by the cable (provided)
4. Check the Communication Status LED
- LED1G(Red)
• OK operation : LED blinks for 5 times and then gets OFF
This process is repeated after every 3 minutes
• NG operation : Check the Indoor Unit’s address & wiring connections
- LED2G(Yellow), LED3G(Orange)
• NG operation : Check the DIP Switch setting & wiring connections
5. Check RS-485
nOK operation :
(1) LED blinks when PI485 receives data from central controller.
nNG operation : Check the wiring connections
6. Finally if all of the above steps are OK then tie the cables by tie wraps & clamp
Installation Guide
6
7
4
5
1
2
8485 Gateway(C, R)
Installation Guide
L1 2
KSD42H
34
Select Air
Conditioner Type
Select Advanced
Control Type Select Network
Type
L1 2 3 4
L1 2
KSD42H
34
L1 2
KSD42H
34
DIP Switch Configuration
3 ON+ALL OFF: Using LGAP CAC Products + Central Controller
3, 4 ON+ALL OFF: LGAP CAC Products + Central Controller (ALL
type)-Using LGAP
For CAC products using LGAP
gThis means Central controller type
(Central controller using LGAP is under development. Next generation controller would
use LGAP.)
• PHNFP14A0
CAUTION:
Wrong products configuration can lead to malfunction.
The wrong setting of air-conditioner switch could cause malfunctioning.
Switch setting must be done carefully.
Installation Manual 9
Installation Guide
L1 2 3 4
L1 2
KSD42H
34
Select Air
Conditioner Type
Select Advanced
Control Type Select Network
Type
L1 2
KSD42H
34
L1 2
KSD42H
34
3 ON+ALL OFF: LGAP RAC/SRAC/PAC Products + Central Controller
(ALL type)-Without LGAP
3, 4 ON+ALL OFF: LGAP RAC/SRAC/PAC Products + Central
Controller (ALL type)-Using LGAP
For RAC/SRAC/PAC products using LGAP
• PSNFP14A0
CAUTION:
Wrong products configuration can lead to malfunctioning
