The 960LStereo

The newest addition to the 960L

family – a stereo version of Lexicon’s

flagship multi-channel digital effects

system. The 960LS is similiar to the

960L, without multi-channel

processing and AES/EBU digital I/O.

But, Multi-Channel Processing

software and AES/EBU digital I/O

cards are available as separate

options. The 960LS supports the

Automation option, and, when

Multi-Channel Processing is

enabled, the LOGIC7 UpMix option.

The 960LDigital

A more affordable, digital I/O

version of Lexicon’s flagship multi-

channel digital effects system.

The 960LD is identical to the 960L,

without the balanced analog I/O.

But, the A/D analog input and

D/A analog output cards are

available as separate options.

The 960L

Lexicon’s flagship multi-channel

digital effects system. The 960L

supports 8 channels of balanced

analog I/O and 8 channels of

AES/EBU digital I/O in various

configurations. It comes standard

with one DSP card and provides

support for an optional second DSP

card that doubles the available

processing power. It now comes

standard with Automation and

LOGIC7 UpMix™options.

OPTION VERSION

Reverb DSP Card

A second reverb DSP Card doubles the processing power of the 960L, 960LD, or 960LS to

support stereo configurations with up to eight machines at 44.1/48kHz or four machines at

88.2/96kHz. It also allows the 960L and 960LD to support surround configurations with up

to four machines at 44.1/48kHz or two machines at 88.2/96kHz.

960L, 960LD, 960LS

Requires Software

Version 2.0 or above

LARC2

A second LARC2 allows shared control of a single 960L mainframe. 960L, 960LD, 960LS

Requires Software

Version 2.0 or above

AES/EBU Digital I/O Card

Offers eight channels of AES/EBU digital I/O at sampling rates up to 96kHz. 960L, 960LD, 960LS

Standard on

960L and 960LD

A/D Analog Input Card

Offers up to eight channels of high-quality 24-bit A/D conversion at sampling rates up to

96kHz with XLR connectors.

960L, 960LD, 960LS

Standard on

960L and 960LS

D/A Analog Output Card

Offers eight channels of high-quality 24-bit D/A conversion at sampling rates up to 96kHz

with XLR connectors.

960L, 960LD, 960LS

Standard on

960L and 960LS

Hardware Options

The 960L

Now available in 3 Versions

A Harman International Company

Software Options

OPTION VERSION

Automation Package

Allows program loads, parameter adjustments, pan moves, and mutes to be

recorded and played back synchronized to incoming MIDI time code. Up to 100

sessions can be saved and recalled to restore the entire state of the machine,

including word clock settings, DSP card configuration, and I/O routings.

960L*, 960LD*, 960LS with

Software Version 3.0 or above

*Standard on units shipped with

Software Version 3.0 or above

960L*, 960LD*, 960LS** with

Software Version 4.0 or above

*Standard on units shipped with

Software Version 4.0 or above

**With Multi-channel option

enabled

Delays & Additional 96kHz Reverbs Package

Includes four stereo and five multi-channel delay algorithms, as well as stereo and

surround 96kHz Plate and Chamber reverb algorithms.

960L, 960LD, 960LS with

Software Version 2.5 or above

Receive at no charge when the

unit is registered online at

www.lexicon.com

LOGIC7 UpMix Algorithm Package

Derives multi-channel surround output from stereo input sources. The LOGIC7 UpMix

algorithm can generate surround mixes from stereo masters, serve as a reference for a

full multitrack-to-surround mix, produce surround pan effects from stereo input

sources, create surround ambiences from stereo input sources within a full multitrack

mix, and convert stereo reverbs into surround reverbs.

Multi-Channel Package

Enables multi-channel functions such as surround algorithms and configurations.

When these functions are enabled, the 960LS will support the complete Delays &

Additional 96kHz Reverbs Package and the LOGIC7 UpMix Algorithm Package.

Standard on

960L and 960LD

960LS with Software

Version 4.0 or above

3 Oak Park, Bedford, MA 01730-1441 USA | Tel: 781-280-0300 | Fax: 781-280-0490 | www.lexicon.com

Printed in USA

Part #072-13376 REV4

The 960L
