Assembly Guide
1-1 Installing for Mini PCI-e Card
1. Remove the screws from the left & right sides of the chassis and remove the top cover. (Fig.1)
1
3. Install the mini PCIe card into the slot at a
45 degree angle.(Fig. 3)
Fig. 3
Fig. 1 Fig. 1
2. Remove the mini PCIe fixing screw from
motherboard.(Fig.2)
Fig. 2
4. Press down to screw back the fixing screw.(Fig. 4)
Fig. 4
2
1. Place the HDD kit on the HDD and screw them
with screws. (Fig.5)
1-2 Installing for SATA HDD Version
Fig.5 Fig.6
2. Connect the SATA Data Cable with HDD. (Fig.6)
4. Connect the SATA Power Cable with motherboard. (Fig.8)
Fig.8
3. Connect the SATA Power Cable with HDD. (Fig.7)
Fig.7
3
5. Connect the SATA DATA Cable with motherboard. (Fig.9)
Fig.9
6. Place the HDD kit inside the system and tighten
the screws manually. (Fig.10)
Fig.10 Fig.11
7. Apply HDD thermal adhesive to HDD & make sure
don’t stick on HDD track . (Fig.11)
8. Put the cover back & tighten the cover with 2 sides screws. (Fig.12)
Fig.12 Fig.12
4
!!
1-3 TERA Exploded Drawing
2
8
7
1
6
3
4
5
11
TOP COVER 12
BOTTOM COVER
23
POWER BOTTON
1
4FRONT COVER
No Name Q'ty
5
6
7
8HDD BRACKET
1
1
1
1
TOP COVER BRACKET
FRONT FRAME
IO PANEL
