Levoit Dual 100-RBW Manuel utilisateur
Ultrasonic Top-Fill Cool Mist
2-in-1 Humidifier & Diuser
Model: Dual 100-RBW
Questions or Concerns?
USER MANUAL
EN DE FRES IT NL
2
Package Contents
Specifications
Safety Information
Getting to Know Your
2-in-1 Humidifier & Diuser
Getting Started
Using Your 2-in-1 Humidifier & Diuser
Care & Maintenance
Troubleshooting
Warranty Information
Customer Support
3
3
4
5
6
8
9
12
14
14
EN
DE
FR
ES
IT
NL
Table of Contents
Inhaltsverzeichnis
Table des matières
Índice
Indice
Lieferumfang
Technische Daten
Sicherheitshinweise
Ihr 2-in-1-Luftbefeuchter
und Zerstäuber
Erste Schritte
Benutzung Ihres 2-in-1-Luftbefeuchters
und Zerstäubers
Pflege und Wartung
Problemlösung
Garantie
Kundendienst
Contenu de l’emballage
Caractéristiques techniques
Consignes de sécurité
Prise en main de votre
Humidificateur et diuseur 2-en-1
Prise en main
Utilisation de votre humidificateur
diuseur 2-en-1
Entretien et maintenance
Dépannage
Informations relatives à la garantie
Service client
Contenido de la caja
Especificaciones
Información de seguridad
Componentes del humidificador y
difusor 2 en 1
Primeros pasos
Cómo utilizar el humidificador y difusor
2en1
Cuidado y mantenimiento
Solución de problemas
Información sobre la garantía
Atención al Cliente
Contenuto della confezione
Specifiche
Informazioni di sicurezza
Componenti dell’umidificatore e
diusore 2 in 1
Preparazione
Utilizzo dell’umidificatore e diusore
2 in 1
Cura e manutenzione
Risoluzione dei problemi
Informazioni sulla garanzia
Assistenza Clienti
15
15
16
17
18
19
21
24
26
26
39
39
40
41
42
43
45
48
50
50
27
27
28
29
30
32
34
36
38
38
51
51
52
53
54
56
58
60
62
62
Inhoudsopgave
Inhoud verpakking
Specificaties
Veiligheidsinformatie
Kennismaking met uw
2-in-1 Luchtbevochtiger en
Verspreider
Aan de slag
Gebruik van uw 2-in-1
Luchtbevochtiger en Verspreider
Verzorging en onderhoud
Probleemoplossing
Garantie-informatie
Klantenservice
63
63
64
65
66
68
70
72
74
74
3
EN
We hope you enjoy your new 2-in-1 Humidifier & Diuser!
Find @LevoitUK on social media for wellness + style inspiration. We make every space mindful
and chic.
1 x 2-in-1 Humidifier & Diuser
1 x User Manual
1 x Quick Start Guide
1 x Antibacterial Cartridge
Power Supply AC 100–240V, 50/60Hz
Rated Power 24W
Water Tank Capacity 1.8 L / 0.48 gal
Run Time 8–20 hours
Note: The humidifier will be able to run for a longer or shorter time
depending on the environmental temperature and humidity.
Noise Level ≤ 28dB
Eective Range 10–24 m² / 107–260 ft²
Dimensions 17.6 x 17.6 x 27.1 cm / 7 x 7 x 10.6 in
Thank you for purchasing the
ULTRASONIC TOPFILL COOL MIST 2IN1
HUMIDIFIER & DIFFUSER BY LEVOIT.
Share the Levoit Love
Package Contents
Specifications
English
User Manual
Ultrasonic Top-Fill Cool Mist 2-in-1 Humidifier & Diffuser
Model: Dual 100-RBW
4
EN
SAFETY INFORMATION
• Only use the humidifier as described in
this manual.
• Place the humidifier and cord so that it
will not be knocked over. Do not place
near large pieces of furniture or in high-
trac areas.
• When not in use, turn the humidifier
o and disconnect from power by
removing the plug from the outlet.
• Do not use the humidifier in
wet environments.
• Keep the humidifier out of reach
from children.
• To avoid risk of electric shock, always
unplug the humidifier from the power
outlet before cleaning it or detaching
the water tank from the base.
• Always make sure the humidifier
is placed on a flat, level surface
before operation.
• Do not place the humidifier near
sources of heat, such as stovetops,
ovens, or radiators.
• Do not place the humidifier directly on
floors, carpets, or rugs. Only place on
water-resistant surfaces.
• Do not place foreign objects into the
humidifier’s base or water tank.
• Do not use attachments that are
not recommended by Levoit for
the humidifier.
• Do not cover the mist outlet while the
humidifier is on. Doing so may damage
the humidifier.
To reduce the risk of fire, electric shock, or other injury, follow all instructions and
safety guidelines.
General Safety
• Do not handle the power cord or plug
with wet hands. Keep the plug and
power cord away from liquids.
Plug & Cord
• Do not allow water or other liquids
inside the air vent.
• Remove the water tank from the base
before moving the humidifier.
• Do not immerse the humidifier base,
power cord, or plug in water.
• Always allow the humidifier to
completely cool before cleaning.
• Do not use detergents to clean
the humidifier. Only use distilled
white vinegar.
• If the humidifier is damaged or is not
functioning properly, stop using it and
contact Customer Support immediately
(see page 14).
• Not for commercial use. Household
use only.
READ AND SAVE
THESE INSTRUCTIONS
5
EN
GETTING TO KNOW YOUR
2IN1 HUMIDIFIER & DIFFUSER
Water tank upside down
A. Mist Tube
B. Water Outlet
C. Water Outlet Valve Assembly
D. Sleep Mode Button
E. Mist Level Indicators
F. Control Button
G. Mist Outlet
H. Transducer
I. Base
J. Top Cover
K. Water Tank
L. Sealing Ring
M
D
C
F
E
A
B
L
GK
J
R
P
HN
O
I
M. Float
N. Insulation Ring
O. Air Outlet
P. Air Inlet
Q. Power Cord
R. Base Chamber
Q
6
EN
GETTING STARTED
1. Remove all packaging. Choose a hard,
flat location for the humidifier at least
15 cm / 6 in away from any walls,
furniture, bedding, and appliances. The
surface must be water-resistant.
[Figure 1.1]
1. Remove the top cover from the water
tank. Fill the tank with room temperature
water. Do not fill with warm or hot water.
[Figure 1.4]
Figure 1.1
Figure 1.3
Figure 1.4Figure 1.2
Note: Do not place the humidifier on
towels, carpets, rugs, floors, or any
surfaces with fibres. This will block the air
inlet at the bottom of the humidifier and
cause overheating. [Figure 1.2]
2. Take the water tank o of the base and
remove all tape. [Figure 1.3]
Filling & Refilling
Note:
• We recommend using purified water.
• Avoid using tap water, because
the mineral content is too high and
will create white dust around the
humidifier.
7
EN
• Do not add water directly into
the base chamber.
• Do not add water through the
mist tube.
Note: For best results, we recommend
using pure essential oil.
Figure 1.6Figure 1.5
Filling & Refilling (cont.)
CAUTION
2. Optionally, add 10–15 drops of essential
oil into the base chamber. [Figure 1.5]
3. Place the top cover back onto the water
tank. Make sure the tank is properly
placed on the base by aligning the
indicator marks. [Figure 1.6]
4. Plug in the humidifier.
8
EN
USING YOUR 2IN1 HUMIDIFIER & DIFFUSER
Note:
• If there is no water in the tank, the
humidifier will not turn on and will
blink. Fill the water tank (see Getting
Started, page 6).
• Keep the humidifier stable while using, or
water may spill.
• Do not block the mist outlet. This will
damage the humidifier. [Figure 2.1]
1. Press once. The humidifier will start
on the low mist level. [Figure 2.2]
2. Press repeatedly to cycle through
mist levels (low, medium, high) and to
turn the humidifier o. [Figure 2.2]
Mist Level
Intelligent Sleep Mode turns o all display
lights and uses a humidity sensor to
automatically adjust the mist level to
maintain a 60% relative humidity (RH) while
you sleep.
1. Press to turn on the humidifier.
Intelligent Sleep Mode
Note: The humidifier must be on to start
Sleep Mode.
2. Press to start Sleep Mode. After 5
seconds, all display lights will turn o.
3. Press a second time (or press )
to cancel Sleep Mode. The humidifier
will go back to the previously set mist
level.
Note:
• Excessive humidity can cause health
issues and mould growth. If the
relative humidity in your room is over
60%, use the low mist setting or turn
o the humidifier.
Do not block
Figure 2.1
Figure 2.2
Low
Medium
High
9
EN
• Never pour water directly into the
base chamber. Only add water to the
water tank. [Figure 2.3] The humidifier
will automatically release the correct
amount of water into the base chamber.
• Avoid moving or shaking the humidifier.
[Figure 2.4] This may cause the water
tank to release too much water into the
base chamber.
Important Tips
Note: The max water line is only for this
purpose. Do not pour water into the base.
Figure 2.3
Figure 2.5
Figure 2.4
• Before moving the humidifier, turn it o,
unplug it, and remove the water tank.
• If your humidifier doesn’t produce mist
correctly, check the max water line to
see if there is too much water in the
base chamber. [Figure 2.5] Pour out any
extra water if water is over the max line.
10
EN
CARE & MAINTENANCE
Note:
• All maintenance should be done on a
water-resistant surface, such as a kitchen
counter.
• Change the water daily to avoid bacteria
growth.
• Use a tissue or cloth to clean the mist
outlet regularly.
• If not using the humidifier for 1 week or
longer, do not leave water inside. Dry and
store instead.
Note:
• Never immerse the base in water
or liquid. Do not place the base in a
dishwasher.
• Do not use detergents to clean the
humidifier.
Cleaning
Clean your humidifier every week, and
when you’re ready to store it.
1. Unplug the humidifier. [Figure 3.1]
2. Remove and wash the top cover.
[Figure 3.2]
3. Remove the water tank from the base.
Pour out all water from the tank and
base. [Figure 3.3]
Figure 3.1
Figure 3.2
Figure 3.4
Figure 3.3
Figure 3.5
Note: Do not let water inside the air outlet
or near the control panel. [Figure 3.4]
4. Rinse the tank and base chamber with
room temperature water. [Figure 3.5]
Table des matières
Langues :
Autres manuels Levoit Humidificateur
Levoit
Levoit Classic 150-RWH Manuel utilisateur
Levoit
Levoit LV600HH Manuel utilisateur
Levoit
Levoit Core 200S Manuel utilisateur
Levoit
Levoit OasisMist LUH-O451S-WUS Manuel utilisateur
Levoit
Levoit LV600S Series Manuel utilisateur
Levoit
Levoit Classic 100 Manuel utilisateur
Levoit
Levoit LV400CH Manuel utilisateur
Levoit
Levoit Classic 160 Manuel utilisateur
Levoit
Levoit LV400CH Manuel utilisateur
Levoit
Levoit LV600B Manuel utilisateur
Levoit
Levoit LV600S Series Manuel utilisateur
Levoit
Levoit LV450CH Manuel utilisateur
Levoit
Levoit LV6S Manuel utilisateur
Levoit
Levoit Classic 100 Manuel utilisateur
Levoit
Levoit LUH-D301S-WUK Manuel utilisateur
Levoit
Levoit Classic 200 Manuel utilisateur
Levoit
Levoit LV450CH Manuel utilisateur
Levoit
Levoit LV600HH Manuel utilisateur
Levoit
Levoit Dual 100 Manuel utilisateur
Levoit
Levoit LUH-A601S-WUSB Manuel utilisateur
