IES-0841
4 x 802.3af PoE + 3 FE + 1 MM SC Web Smart Switch -10 to 60C, DIN-rail
User Manual
v1.00-1206
2
Preface
This manual describes how to install and use the IndustrialWeb-Smart PoE Ethernet Switch.This
switch introduced here is designed to deliver full scalability with web-based management
functions. Capable of operating at temperature extremes of -10°C to +60°C, this is the switch of
choice for harsh environments constrained by space.
Port 1 to port 4 on this switch supports IEEE802.3af Power over Ethernet (PoE) Power Sourcing
Equipment (PSE) and can detect an IEEE802.3af compliant Powered Device (PD). Using external
48VDC power inputs throughTerminal Block or Power Jack, data and power can be transmitted to
a Powered Device (PD) over the same twisted-pair Ethernet cable through port 1 to port 4 on the
switch.
To get the most out of this manual, you should have an understanding of Ethernet networking
concepts.
In this manual, you will find:
Features
Illustrative LED functions
Installation instructions
Management Configuration
Specifications
3
Table of Contents
OVERVIEW...........................................................................................................................4
INDUSTRIALWEB-SMART POEETHERNET SWITCH.............................................................................................4
FEATURES...............................................................................................................................................................5
PACKAGE CONTENTS.............................................................................................................................................5
FRONT PANEL DISPLAY..........................................................................................................................................6
POWERINPUT ........................................................................................................................................................7
DINRAIN MOUNT.................................................................................................................................................8
10/100BASE-TXCONNECTOR............................................................................................................................9
WEB MANAGEMENT .........................................................................................................10
DEFAULT SETTING...............................................................................................................................................10
LOGGING ONTOTHE SWITCH .............................................................................................................................11
BROWSER INTERFACE..........................................................................................................................................12
PoE.............................................................................................................................................................13
PortBasedVLAN.....................................................................................................................................14
Priority.......................................................................................................................................................15
DiffServCodePoint...............................................................................................................................16
SystemSetup...........................................................................................................................................17
FirmwareUpgrade.................................................................................................................................18
SPECIFICATIONS ...............................................................................................................19
4
Overview
IndustrialWeb-Smart PoE Ethernet Switch
LevelOne IES-0841 Industry Ethernet Switch provides 4 PoE ports of 10/100Base-TX plus 3 ports of
10/100Base-TX Ethernet plus 1 port 100FX Multimode SC fiber to enable high speed network at
mission-critical environment.This device is designed to be mounted on an industry standard DIN-
rail, plus the clearly visible status LEDs provide simple monitoring of port link activity.
Cost Effective
This device operates under -10 to 60 Celsius (-14 to 140 Fahrenheit) temperature that offers
optimal suitability for industrial applications at low cost while maintaining all components built to
withstand harsh environment applications without compromise reliability and stability.
Web Management
Web-based GUI management features implementation of Port-basedVLAN, IEEE802.1p QoS,
Prioritised DSCP, set up Admin Password with ease. Plus, the Power over Ethernet ports can be On /
Off and limits the power budget remotely
Power over Ethernet
This switch is Power Sourcing Equipment (PSE), and it is fully complied with IEEE 802.3af PoE
standard at maximum 15.4W power budget per port. It helps to save infrastructure wiring costs
dramatically by eliminating electric wiring and less UPS needed.
Safety
This device has been tested under UL508 standard for Industrial Control Equipment to endurance
safety measurement to ensure field hardened, especially for the harsh environment.
5
Features
Complies with EN61000-6-2 & EN61000-6-3 EMC Generic standard immunity for Industrial
environment.
Manageable viaWeb browser interface.
Supports IEEE802.3af Power over Ethernet (PoE) Power Sourcing Equipment (PSE).
Supports IEEE802.3/802.3u/802.3x. Auto-negotiation: 10/100Mbps-full/half-duplex; Auto
MDI/MDIX.
100Base-FX: Multi mode SC or ST type; Single mode SC or ST type;WDM Single mode SC type.
Supports 1024 MAC addresses. Provides 1M bits memory buffer.
Store-and-forward mechanism.
Full wire-speed forwarding rate.
Alarms for power and port link failure by relay output.
Power Supply: Redundant 48VDCTerminal Block power inputs and 48VDC DC JACK with 100-
240VAC external power supply.
Operating voltage and Max. current consumption: 1.5A @ 48VDC. Power consumption: 72W
Max.
-10℃to 60℃(14℉to 140℉) operating temperature range.Tested for functional operation @ -
20℃to 70℃(-4℉to 158℉).
Reset button on front panel.
Front panel port status LEDs.
Industrial aluminum case.
Supports DIN-Rail, Panel, or Rack Mounting installation.
Package Contents
When you unpack the product package, you shall find the items listed below. Please inspect the
contents, and report any apparent damage or missing items immediately to your authorized
reseller.
IES-0841 IndustrialWeb-Smart PoE Ethernet Switch
Quick Installation Guide
CD User Manual
6
Front Panel Display
LED
Status
Description
PW 1,2,3
Steady
Power On
Off
Power Off
10/100Base-TX or 100Base-FX/BX
LNK/ACT
Steady
Network connection is established
Flashing
Transmitting or Receiving data
PoE
Steady
Power Device (PD) is connected
Off
Power Device (PD) is disconnected
7
Power Input
Terminal Block
PW1
+
48VDC
Power Ground
PW2
+
48VDC
Power Ground
Earth Ground
Relay Output
0.1A @ 24VDC
1. The relay contact opens if Power1 orPower2 falls
2. The relay contact opens if the Port Link is broken
(When Link Down Detection is enabled)
DC Jack
PW3
DC Jack
48VDC
Special Note:
The relay output is normal open position when there is no power to the switch. Please do not
connect any power source to this terminal to prevent shorting your power supply.
8
DIN rain Mount
Fix the DIN rail attachment plate to the back panel of the switch.
Installation: Place the switch on the DIN rail from above using the slot. Push the front of the
switch toward the mounting surface until it audibly snaps into place.
Removal: Pull out the lower edge and then remove the switch from the DIN rail.
9
10/100Base-TX Connector
The following lists the pin-out of 10/100Base-TX ports.
Pin
PoE Port (1 to 4)
Standard Port (5)
1
OutputTransmit Data +
Input Receive Data +
2
OutputTransmit Data -
Input Receive Data -
3
Input Receive Data +
OutputTransmit Data +
4
Positive (VCC+)
NC
5
Positive (VCC+)
NC
6
Input Receive Data -
OutputTransmit Data -
7
Negative (VCC-)
NC
8
Negative (VCC-)
NC
10
Web Management
The switch provides a browser interface that lets you configure and manage the switch remotely.
applications directly in your web browser by entering the IP address of the switch.You can then
use your web browser to list and manage switch configuration parameters from one central
Web-Based Browser Management
The switch provides a web-based browser interface for configuring and managing the switch.This
interface allows you to access the switch using a preferred web browser.
This chapter describes how to configure the switch using its web-based browser interface.
Default Setting
IP address: 192.168.1.10
User Name: admin
Password: [Blank]
