SENTRY
User Manual
Level-Sense.com
LEVEL-SENSE.COM
TABLE OF CONTENTS
About Level Sense Sentry....................................................................
Specifications..................................................................................................
Requirements..................................................................................................
In the box..............................................................................................................
Account Creation.........................................................................................
Status LEDs.......................................................................................................
Installation..........................................................................................................
Connect to Wi-Fi...........................................................................................
Claim Device.....................................................................................................
Contact Information..................................................................................
Notification Settings.................................................................................
Viewing Data.....................................................................................................
Wi-Fi Password Reset...............................................................................
Service Disclaimer.......................................................................................
Warranty...............................................................................................................
Section 1:
Section 2:
Section 3:
Section 4:
Section 5:
Section 6:
Section 7:
Section 8:
Section 9:
Section 10:
Section 11:
Section 12:
Section 13:
Section 14:
Section 15:
02
02
03
03
04
06
07
10
13
14
14
15
16
16
17
01
LEVEL SENSE SENTRY USER MANUAL
SECTION 1: ABOUT LEVEL SENSE SENTRY
Level Sense is the all-purpose basement or room protector (Indoor only). This sump pump alarm is
packed with features at an economical price.
SECTION 2: SPECIFICATIONS
Level Sense Sentry allows you to set alarms based on power failure/Loss of Wi-Fi, water leaks, and
water level. Unlimited text and email notifications come standard, as well as a 90dB siren.
02
LEVEL-SENSE.COM
LEVEL SENSE SENTRY USER MANUAL
SECTION 3: REQUIREMENTS
• 120/240 VAC (50 or 60 Hz) Power Outlet
• 2.4 Ghz Wi-Fi internet within range of Level Sense Sentry
• Wi-Fi enabled device with Web browsing
• Flat head screwdriver #3 or #4
Level Sense Sentry with Float Switch
1. Head Unit
2. Float Switch
3. Float Mounting Bracket
4. Zip Ties
5. Various Mounting Hardware
6. Power Adaptor
7. User Manual
Level Sense Sentry with Leak Sensor
1. Head Unit
2. Leak Sensor
3. Zip Ties
4. Various Mounting Hardware
5. Power Adaptor
6. User Manual
03
SECTION 4: IN THE BOX
LEVEL-SENSE.COM
LEVEL SENSE SENTRY USER MANUAL
SECTION 5: ACCOUNT CREATION
1. Level Sense Account Creation
Thank you for your Level Sense Sentry purchase. The first step in getting your Level Sense Sentry
device online is to create your Level Sense Account. This can be done with either a computer, or a
smartphone/tablet
a. Smartphone/Tablet
a. On your smartphone proceed to either the iOS app store, or the Android Play store
b. Type into the search bar “Level Sense”, and download the application
04
If you prefer video instructions over written, please scan the QR code.
This video will walk you through sections 5 and 8-11.
LEVEL-SENSE.COM
LEVEL SENSE SENTRY USER MANUAL
c. Next click on the register button and enter in your personal information into the register page,
and lastly click the create button. Congratulations, your Level Sense account has been created.
b. Computer:
05
a. Begin by opening an internet browser like Google Chrome or Safari.
b. In the address bar type in: Level-Sense.com
i.Click on the text labeled “Account”
LEVEL-SENSE.COM
LEVEL SENSE SENTRY USER MANUAL
ii. Next enter in your First name, Last name, email address, and password. Click the submit
button and your Level Sense account has successfully been created.
06
SECTION 6: STATUS LEDS
Device State
No Alarm(s) Blue
Yellow
Purple
Red
Blue Blue Blue
POWER CLOUD TEMP ALARM
The status LEDs on the level Sense Sentry provides a visual indication of the state of the device. The
below table is a system status guide. PLEASE NOTE that if the four LEDs are flashing in unison,
then this is a CLAIM CODE. If you have a claim code, reference Section 9.
Access Point (Level Sense Network is Broadcasting) Pulsing White
Wi-Fi Connection in Progress
Alarm(s) Present
Firmware Upgrade/Server Maintenance
Loss of Wi-Fi Signal
Red
LEVEL-SENSE.COM
LEVEL SENSE SENTRY USER MANUAL
07
SECTION 7: INSTALLATION
1. Head Unit Installation:
a. The head Unit can be mounted in one of three ways.
i. Magnetically: Magnets are mounted inside of the Level Sense Sentry enclosure. To mount the
unit magnetically, simply place the back of the enclosure onto a magnetic surface.
ii. Wall Mount: The template shown below can be used to mount the device
directly to a wall via the mounting screws.
LEVEL-SENSE.COM
LEVEL SENSE SENTRY USER MANUAL
08
iii. Cable Tie Mount: The two sticky pad anchors and zip ties can be used to mount the head unit.
2. Installing Float Sensor:
The float sensor mounts above the normal pump water line and detects when the water level has
reached a point above normal operating range.
The float sensor installs on the sump pump discharge pipe. Using the provided plastic float bracket
and two zip ties, securely mount the float to the discharge pipe. The sliding float portion of the
sensor should face down. Mount the float approximately six (6) inches above the sump pump
normal water line. This level can usually be found by looking at the side walls of the pit to visually
see the high-water mark roughly level with the top of the pump. The wires from the float sensor
connect to the far right two terminals on the Level Sense Sentry.
LEVEL-SENSE.COM
LEVEL SENSE SENTRY USER MANUAL
09
3. Installing Leak Sensor
The leak sensor monitors for pooling water on a flat surface. The leak sensor can be mounted near
the sump pit or other areas where water will pool in the event of a leak. Typical locations are near a
water heater or HVAC system which can leak during a malfunction. The sensor needs to be placed
flat on the floor with the metal sensing elements down. The sensor must be submerged in a
minimum pool of water of 1/8” in depth before activating. The wires do not have polarity and cannot
be wired backwards. Do not increase the length of this sensor beyond the length provided. The leak
sensor can be wired into the middle and far left terminal.
4. Completed Installation with Float Switch and or Leak Sensor
Reference the image below for a rendering of an installation utilizing both a float switch and leak
sensor. Note that the middle terminal is common.
LEVEL-SENSE.COM
LEVEL SENSE SENTRY USER MANUAL
