Leuze electronic BPS 8 Manuel utilisateur

BPS 8

Bar Code Positioning System

en 03-2018/01 50105556

We reserve the right

to make technical changes

Original operating instructions

Leuze electronic BPS 8

Leuze electronic GmbH + Co. KG

In der Braike 1

D-73277 Owen / Germany

Phone: +49 7021 573-0

Fax: +49 7021 573-199

http://www.leuze.com

[email protected]m

Leuze electronic BPS 8 1

Table of contents

1 About this document ......................................................................................................... 4

1.1 Used symbols and signal words .......................................................................................... 4

2 Safety .................................................................................................................................. 6

2.1 Intended use ........................................................................................................................ 6

2.2 Foreseeable misuse............................................................................................................. 7

2.3 Competent persons.............................................................................................................. 7

2.4 Exemption of liability ............................................................................................................ 8

2.5 Laser safety notices ............................................................................................................. 8

3 Technical data of BPS 8 .................................................................................................. 11

3.1 General specifications BPS 8 ............................................................................................ 11

3.2 Dimensioned drawings....................................................................................................... 13

3.3 Reading field curves .......................................................................................................... 15

4 MA 8… / MA 2xxi connection units................................................................................. 16

4.1 MA 8.1 connection unit ...................................................................................................... 17

4.2 MA 8-01 / MA 8-02 connection unit.................................................................................... 18

4.3 MA 2xxi connection unit ..................................................................................................... 20

5 Bar code tape ................................................................................................................... 21

5.1 General information ........................................................................................................... 21

5.2 Control bar codes............................................................................................................... 23

5.3 Marker bar codes ............................................................................................................... 27

5.4 Technical data of the BCB8 bar code tape ........................................................................ 29

5.5 Dimensioned drawing for position, control and marker bar codes ..................................... 30

6 Mounting and installation ............................................................................................... 31

6.1 Mounting the bar code tape ............................................................................................... 31

6.1.1 Installation and application remarks ............................................................................................ 31

6.1.2 Cutting bar code tapes................................................................................................................. 33

6.1.3 Mounting the BCB........................................................................................................................ 36

6.1.4 BCB repair with repair kit ............................................................................................................. 39

6.2 Mounting the BPS 8 ........................................................................................................... 41

6.2.1 BT 8-01 mounting device............................................................................................................. 43

6.2.2 BT 8-0 mounting device............................................................................................................... 44

6.3 Device arrangement...........................................................................................................45

Leuze electronic BPS 8 2

Table of contents

7 Electrical connection ....................................................................................................... 48

7.1 Safety notices for the electrical connection........................................................................ 48

7.2 Electrical connection BPS 8............................................................................................... 49

7.2.1 BPS 8 - PWR IN - Voltage supply, RS 232, Switching input/output ............................................ 49

7.3 Electrical connection via connection unit MA 8.1 ............................................................... 51

7.3.1 Electrical connection MA 8.1 ....................................................................................................... 51

7.3.2 PWR IN HOST/RS 232 connector – voltage supply and RS 232 ................................................ 52

7.3.3 SW IN/OUT socket – switching input and switching output......................................................... 53

7.3.4 BCL socket – connecting the BPS 8 to the MA 8.1 ..................................................................... 55

7.4 Electrical connection via connection unit MA 8-01 / MA 8-02 ............................................ 56

7.4.1 PWR IN HOST/RS485 connector – voltage supply/RS 485 ........................................................ 56

7.4.2 SW IN/OUT socket – switching input and switching output......................................................... 57

7.4.3 BCL/BPS socket – connecting the BPS 8 to the MA 8-01/MA 8-02 ............................................ 59

7.4.4 Termination of the RS 485 interface............................................................................................ 60

8 Configuration / device parameters ................................................................................. 61

8.1 RS 232/RS 485 interface ................................................................................................... 61

8.1.1 General information ..................................................................................................................... 61

8.2 BPS Configuration Tool software....................................................................................... 62

8.2.1 Installation of the BPS Configuration Tool software .................................................................... 62

8.2.2 Brief manual for the BPS Configuration Tool............................................................................... 63

8.2.3 Setting the parameters ................................................................................................................ 67

8.3 Service operating mode ..................................................................................................... 68

8.3.1 Activate service interface............................................................................................................. 68

8.3.2 Connecting the service interface ................................................................................................. 68

8.3.3 Overview of commands and parameters..................................................................................... 69

8.4 Overview of the parameter structure.................................................................................. 70

8.5 Detailed description of the tabs.......................................................................................... 71

8.5.1 Control ......................................................................................................................................... 72

8.5.2 Position detection ........................................................................................................................ 73

8.5.3 Communication............................................................................................................................ 78

8.5.4 Switching input............................................................................................................................. 80

8.5.5 Switching output .......................................................................................................................... 82

Leuze electronic BPS 8 3

Table of contents

9 Protocols for position value output ............................................................................... 84

9.1 Binary protocol 1 – BPS 8 SM 10x-01 / BPS 8 SM 10x-05 ................................................ 84

9.1.1 Data format .................................................................................................................................. 84

9.1.2 Request telegram to the BPS 8 SM 10x-01 / BPS 8 SM 10x-05 ................................................. 84

9.1.3 BPS 8 SM 10x-01 / BPS 8 SM 10x-05 response telegram.......................................................... 86

9.2 Binary protocol 2 – BPS 8 SM 10x-02 ............................................................................... 91

9.2.1 Data format .................................................................................................................................. 91

9.2.2 Request telegram to the BPS 8 SM 10x-02.................................................................................91

9.2.3 BPS 8 SM 10x-02 response telegram ......................................................................................... 93

9.3 Binary protocol 3 – BPS 8 SM 10x-03 ............................................................................... 98

9.3.1 Data format .................................................................................................................................. 98

9.3.2 Request telegram to the BPS 8 SM 10x-03.................................................................................98

9.3.3 BPS 8 SM 10x-03 response telegram ....................................................................................... 100

9.4 Binary protocol 4 – BPS 8 SM 10x-04 ............................................................................. 102

9.4.1 Data format ................................................................................................................................ 102

9.4.2 Request telegram to the BPS 8 SM 10x-04............................................................................... 102

9.4.3 BPS 8 SM 10x-04 response telegram ....................................................................................... 105

9.4.4 Binary protocol 4 request sequences ........................................................................................ 107

9.5 Binary protocol 6 – BPS 8 SM 10x-10 ............................................................................. 109

9.5.1 Data format ................................................................................................................................ 109

9.5.2 Request telegram to the BPS 8 SM 10x-10............................................................................... 109

9.5.3 BPS 8 SM 10x-10 response telegram ....................................................................................... 111

10 Diagnostics and troubleshooting ................................................................................. 113

10.1 Operating indicators of the LEDs ..................................................................................... 113

10.2 General causes of errors ................................................................................................. 113

10.3 Error on the interface ....................................................................................................... 114

11 Maintenance ................................................................................................................... 115

11.1 Cleaning........................................................................................................................... 115

11.2 Repairs, servicing ............................................................................................................ 115

11.3 Disassembling, packing, disposing .................................................................................. 115

12 Type overview and accessories ................................................................................... 116

12.1 Type overview: BPS 8...................................................................................................... 116

12.2 Type overview: Bar code tape ......................................................................................... 116

12.3 Accessories – Modular connection unit ........................................................................... 117

12.4 Accessories – Fieldbus gateway...................................................................................... 117

12.5 Accessories – Cables ...................................................................................................... 117

12.6 Accessories – Mounting device ....................................................................................... 118

12.7 Accessories - Configuration software .............................................................................. 118

13 Appendix......................................................................................................................... 119

13.1 EC Declaration of Conformity .......................................................................................... 119

About this document

Leuze electronic BPS 8 4

TNT 35/7-24V

1 About this document

1.1 Used symbols and signal words

Table 1.1: Warning symbols and signal words

Table 1.2: Other symbols

Symbol indicating dangers to persons

Symbol indicating dangers from harmful laser radiation

NOTE Signal word for property damage

Indicates dangers that may result in property damage if the measures

for danger avoidance are not followed.

Symbol for tips

Text passages with this symbol provide you with further information.

Symbol for action steps

Text passages with this symbol instruct you to perform actions.

BCB Bar code tape (general)

BCB8 Bar code tape (BCB type with 30 mm grid)

BPS Bar code Positioning System

BT Mounting device

CDRH Center for Devices and Radiological Health

CFR Code of Federal Regulations

DGUV Deutsche Gesetzliche Unfallversicherung (statutory German accident

insurance association)

EMC Electromagnetic compatibility

EN European standard

FE Functional earth

IEC International Electrotechnical Commission

About this document

Leuze electronic BPS 8 5

TNT 35/7-24V

Table 1.3: Terms and abbreviations

IO or I/O Input/Output

IP International Protection

LED Light Emitting Diode

MA Modular connection unit

MVS Type of control bar code

NEC National Electric Code

PE Protective Earth

PWR Power – Supply voltage

UL Underwriters Laboratories

UV Ultraviolet light

Safety

Leuze electronic BPS 8 6

TNT 35/7-24V

2Safety

The bar code positioning systems of the BPS 8 series and the MA 8… modular connection

unit have been developed, produced and tested subject to the applicable safety standards.

They correspond to the state of the art.

2.1 Intended use

The bar code positioning system of the BPS 8 series is an optical measuring system which

uses visible red laser light to determine the position of the BPS relative to a permanently

mounted bar code tape.

The optional connector and interface unit MA 8… is intended for the easy connection of bar

code positioning systems of type BPS 8.

Areas of application

The BPS 8 bar code positioning systems are designed for the following areas of application:

• Crane bridges and trolleys

• High-bay storage devices

• Side-tracking skates

• Telpher lines

•Elevators

NOTE

Declaration of Conformity

A copy of all declarations of conformity available for the product can be found in the

appendix of this handbook (see chapter 13.1 "EC Declaration of Conformity" on

Page 119).

CAUTION

Observe intended use!

The protection of personnel and the device cannot be guaranteed if the device is operated

in a manner not complying with its intended use.

Only operate the device in accordance with its intended use.

Leuze electronic GmbH + Co. KG is not liable for damages caused by improper use.

Read these operating instructions before commissioning the device. Knowledge of

this document is required in order to use the equipment for its intended purpose.

NOTE

Comply with conditions and regulations!

Observe the locally applicable legal regulations and the rules of the employer's liability

insurance association.

Safety

Leuze electronic BPS 8 7

TNT 35/7-24V

2.2 Foreseeable misuse

Any use other than that defined under "Intended use" or which goes beyond that use is

considered improper use.

In particular, use of the device is not permitted in the following cases:

• in rooms with explosive atmospheres

• as stand-alone safety component in accordance with the machinery directive 1

• for medical purposes

2.3 Competent persons

Connection, mounting, commissioning and adjustment of the device must only be carried

out by competent persons.

Prerequisites for competent persons:

• They have a suitable technical education.

• They are familiar with the rules and regulations for occupational safety and safety at

work.

• They are familiar with the technical description of the device.

• They have been instructed by the responsible person on the mounting and operation

of the device.

CAUTION

UL applications!

For UL applications, use is only permitted in Class 2 circuits in accordance with the NEC

(National Electric Code).

1. Use as safety-related component within the safety function is possible, if the component combination is designed

correspondingly by the machine manufacturer.

NOTE

Do not modify or otherwise interfere with the device!

Do not carry out modifications or otherwise interfere with the device.

The device must not be tampered with and must not be changed in any way.

The device must not be opened. There are no user-serviceable parts inside.

Repairs must only be performed by Leuze electronic GmbH + Co. KG.

Safety

Leuze electronic BPS 8 8

TNT 35/7-24V

Certified electricians

Electrical work must be carried out by a certified electrician.

Due to their technical training, knowledge and experience as well as their familiarity with

relevant standards and regulations, certified electricians are able to perform work on elec-

trical systems and independently detect possible dangers.

In Germany, certified electricians must fulfill the requirements of DGUV Provision 3 (e.g.

electrician foreman). In other countries, there are respective regulations that must be

observed.

2.4 Exemption of liability

Leuze electronic GmbH + Co. KG is not liable in the following cases:

• The device is not being used properly.

• Reasonably foreseeable misuse is not taken into account.

• Mounting and electrical connection are not properly performed.

• Changes (e.g., constructional) are made to the device.

2.5 Laser safety notices

ATTENTION, LASER RADIATION – LASER CLASS 2

Never look directly into the beam!

The device satisfies the requirements of IEC 60825-1:2007 (EN 60825-1:2007) safety

regulations for a product of laser class 2 as well as the U.S. 21 CFR 1040.10 regulations

with deviations corresponding to "Laser Notice No. 50" from June 24, 2007.

Never look directly into the laser beam or in the direction of reflected laser beams!

If you look into the beam path over a longer time period, there is a risk of injury to the

retina.

Do not point the laser beam of the device at persons!

Interrupt the laser beam using a non-transparent, non-reflective object if the laser

beam is accidentally directed towards a person.

When mounting and aligning the device, avoid reflections of the laser beam off reflec-

tive surfaces!

CAUTION! The use of operating or adjusting devices other than those specified here

or carrying out of differing procedures may lead to dangerous exposure to radiation.

Observe the applicable statutory and local laser protection regulations.

The device must not be tampered with and must not be changed in any way.

There are no user-serviceable parts inside the device.

Repairs must only be performed by Leuze electronic GmbH + Co. KG.

Table des matières

Autres manuels Leuze electronic Positionneur de vanne

Leuze electronic

Leuze electronic BPS 34 Manuel de la liste des pièces

Manuels Positionneur de vanne populaires d'autres marques

Parker

Parker 404XE Series Manuel utilisateur

Ytc

Ytc TMP-3000 Manuel utilisateur

PI M-605 Series Manuel utilisateur

Pepperl+Fuchs

Pepperl+Fuchs PXV100AS-F200-SSI-V19 Manuel utilisateur

RTK

RTK RE 3442 Series Manuel utilisateur

CVS Controls

CVS Controls 1200 Manuel utilisateur

Parker

Parker MX80L series Manuel utilisateur

Westlock

Westlock Quantum 2800 Manuel

Samson

Samson 3730-0 Manuel de service

Samson

Samson TROVIS 3730-3 Manuel de service

ESCO Technologies

ESCO Technologies ETS LINDGREN 2302-001 Manuel utilisateur

SMC Networks

SMC Networks IP8000 Manuel utilisateur

Samson

Samson FOUNDATION 3730-5 Manuel de service

Samson

Samson TROVIS SAFE 3731-3 Manuel de service

Flowserve

Flowserve Logix 3400MD Manuel utilisateur

halstrup-walcher

halstrup-walcher HIPERDRIVE Manuel utilisateur

ABB

ABB TZIDC Manuel de formation

Samson

Samson FOUNDATION 3730-5 Manuel de service
