Leonard LK0813 Manuel utilisateur
LK0813
User Manual
Benutzerinformation
Refrigerator
Kühlschrank
CONTENTS
Safety information 2
Safety instructions 4
Installation 6
Control panel 8
Daily use 8
Hints and tips 9
Care and cleaning 10
Troubleshooting 10
Noises 14
Technical data 14
Information for test institutes 14
Subject to change without notice.
VISIT OUR WEBSITE TO:
Get usage advice, brochures, trouble shooter, service and repair
information:
www.leonard-hausgeraete.de/support
SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result of
incorrect installation or usage. Always keep the instructions
in a safe and accessible location for future reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
•Children aged from 3 to 8 years are allowed to load and
unload the appliance provided that they have been
properly instructed.
•This appliance may be used by persons with very
extensive and complex disabilities provided that they have
been properly instructed.
•Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
•Do not let children play with the appliance.
2 Leonard
•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
•Keep all packaging away from children and dispose of it
appropriately.
General Safety
•This appliance is intended to be used in household and
similar applications such as:
–Farm houses; staff kitchen areas in shops, offices and
other working environments;
–By clients in hotels, motels, bed and breakfast and other
residential type environments.
•To avoid contamination of food respect the following
instructions:
–do not open the door for long periods;
–clean regularly surfaces that can come in contact with
food and accessible drainage systems;
–store raw meat and fish in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
•WARNING: Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
•WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
•WARNING: Do not damage the refrigerant circuit.
•WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
•Do not use water spray and steam to clean the appliance.
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
•When the appliance is empty for long period, switch it off,
defrost, clean, dry and leave the door open to prevent
mould from developing within the appliance.
Leonard 3
•Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
SAFETY INSTRUCTIONS
Installation
WARNING! Only a qualified
person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not use the appliance before
installing it in the built-in structure due
to safety manner.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Make sure the air can circulate around
the appliance.
• At first installation or after reversing the
door wait at least 4 hours before
connecting the appliance to the power
supply. This is to allow the oil to flow
back in the compressor.
• Before carrying out any operations on
the appliance (e.g. reversing the door),
remove the plug from the power socket.
• Do not install the appliance close to
radiators or cookers, ovens or hobs.
• Do not expose the appliance to the
rain.
• Do not install the appliance where there
is direct sunlight.
• Do not install this appliance in areas
that are too humid or too cold.
• When you move the appliance, lift it by
the front edge to avoid scratching the
floor.
Electrical connection
WARNING! Risk of fire and
electric shock.
WARNING! When positioning
the appliance, ensure the
supply cord is not trapped or
damaged.
WARNING! Do not use multi-
plug adapters and extension
cables.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Contact the
Authorised Service Centre or an
electrician to change the electrical
components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
Use
WARNING! Risk of injury,
burns, electric shock or fire.
4 Leonard
The appliance contains flammable
gas, isobutane (R600a), a natural gas with
a high level of environmental compatibility.
Be careful not to cause damage to the
refrigerant circuit containing isobutane.
• Do not change the specification of this
appliance.
• Do not put electrical appliances (e.g.
ice cream makers) in the appliance
unless they are stated applicable by the
manufacturer.
• If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not store flammable gas and liquid
in the appliance.
• Do not put flammable products or items
that are wet with flammable products
in, near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
Internal lighting
WARNING! Risk of electric
shock.
• The type of lamp used for this
appliance is for household appliances
only. Do not use it for house lighting.
Care and cleaning
WARNING! Risk of injury or
damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons
in the cooling unit. Only a qualified
person must do the maintenance and
the recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the appliance.
Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be
available for 7 years after the model
has been discontinued: thermostats,
temperature sensors, printed circuit
boards, light sources, door handles,
door hinges, trays and baskets. Please
note that some of these spare parts are
only available to professional repairers,
and that not all spare parts are relevant
for all models.
• Door gaskets will be available for 10
years after the model has been
discontinued.
Disposal
WARNING! Risk of injury or
suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozone-
friendly.
• The insulation foam contains
flammable gas. Contact your municipal
authority for information on how to
discard the appliance correctly.
• Do not cause damage to the part of the
cooling unit that is near the heat
exchanger.
Leonard 5
INSTALLATION
WARNING! Refer to Safety
chapters.
WARNING! Refer to
installation instruction
document to install your
appliance.
WARNING! Fix the appliance
in accordance with installation
instruction document to avoid a
risk of instability of the
appliance.
Dimensions
B
A
H1
W1
D1
W2
D2
W3
D3
90°
Overall dimensions
1)
H1 mm 873
W1 mm 548
D1 mm 549
1) the height, width and depth of the appliance without
the handle and feet
Space required in use
1)
H2 (A+B) mm 916
W2 mm 548
D2 mm 551
A mm 880
6 Leonard
Space required in use
1)
B mm 36
1) the height, width and depth of the appliance includ‐
ing the handle, plus the space necessary for free circu‐
lation of the cooling air
Overall space required in use
1)
H3 (A+B) mm 916
W3 mm 548
D3 mm 1071
1) the height, width and depth of the appliance includ‐
ing the handle, plus the space necessary for free circu‐
lation of the cooling air, plus the space necessary to
allow door opening to the minimum angle permitting
removal of all internal equipment
Location
To ensure appliance's best functionality,
you should not install the appliance in the
nearby of the heat source (oven, stoves,
radiators, cookers or hobs) or in a place
with direct sunlight. Make sure that air can
circulate freely around the back of the
cabinet.
Positioning
This appliance should be installed in a dry,
well ventilated indoor position.
This appliance is intended to be used at
ambient temperature ranging from 10°C to
43°C.
If you have any doubts
regarding where to install the
appliance, please turn to the
vendor, to our customer service
or to the nearest Authorised
Service Centre.
It must be possible to
disconnect the appliance from
the mains power supply. The
plug must therefore be easily
accessible after installation.
Electrical connection
• Before plugging in, ensure that the
voltage and frequency shown on the
rating plate correspond to your
domestic power supply.
• The appliance must be earthed. The
power supply cable plug is provided
with a contact for this purpose. If the
domestic power supply socket is not
earthed, connect the appliance to a
separate earth in compliance with
current regulations, consulting a
qualified electrician.
• The manufacturer declines all
responsibility if the above safety
precautions are not observed.
• This appliance complies with the E.E.C.
Directives.
Ventilation requirements
The airflow behind the appliance must be
sufficient.
5 cm min.
200 cm2
min.
200 cm2
CAUTION! Refer to the
installation instructions for the
installation.
Door reversibility
Please refer to the separate document
with instructions on installation and door
reversal.
CAUTION! At every stage of
reversing the door protect the
floor from scratching with a
durable material.
Leonard 7
CONTROL PANEL
Switching on
1. Insert the plug into the wall socket.
2. Turn the temperature regulator
clockwise to a medium setting.
Switching off
To turn off the appliance, turn the
temperature regulator to the "O" position.
Temperature regulation
The temperature is regulated
automatically. However, you can set a
temperature inside the appliance yourself.
Choose the setting keeping in mind that
the temperature inside the appliance
depends on:
• room temperature,
• frequency of opening the door,
• quantity of food stored,
• appliance location.
A medium setting is generally the most
suitable one.
To operate the appliance:
1. Turn the temperature regulator
clockwise to obtain a lower
temperature inside the appliance.
2. Turn the temperature regulator
counterclockwise to obtain a higher
temperature inside the appliance.
DAILY USE
Positioning the door shelves
To permit storage of food packages of
various sizes, the door shelves can be
placed at different heights.
1. Gradually pull the shelf up until it
comes free.
2. Reposition as required.
Movable shelves
The walls of the refrigerator are equipped
with a series of runners so that the
shelves can be positioned as desired.
8 Leonard
Do not move the glass shelf
above the vegetable drawer to
ensure correct air circulation.
Vegetable drawer
There is a special drawer in the bottom
part of the appliance suitable for storage
of fruits and vegetables.
HINTS AND TIPS
Hints for energy saving
• Most efficient use of energy is ensured
in the configuration with the drawers in
the bottom part of the appliance and
shelves evenly distributed. Position of
the door bins does not affect energy
consumption.
• Do not open the door frequently or
leave it open longer than necessary.
• Do not set too high temperature to save
energy unless it is required by the
characteristics of the food.
• If the ambient temperature is high and
the temperature control is set to low
temperature and the appliance is fully
loaded, the compressor may run
continuously, causing frost or ice
formation on the evaporator. In this
case, set the temperature control
toward higher temperature to allow
automatic defrosting and to save
energy this way.
• Ensure a good ventilation. Do not cover
the ventilation grilles or holes.
Hints for fresh food refrigeration
• The medium temperature setting
ensures good preservation of fresh
food.
Higher temperature setting inside the
appliance may lead to shorter shelf life
of food.
• Cover the food with packaging to
preserve its freshness and aroma.
• Always use closed containers for
liquids and for food, to avoid flavours or
odours in the compartment.
• To avoid the cross-contamination
between cooked and raw food, cover
the cooked food and separate it from
the raw one.
• It is recommended to defrost the food
inside the fridge.
• Do not insert hot food inside the
appliance. Make sure it has cooled
down at room temperature before
inserting it.
• To prevent food waste the new stock of
food should always be placed behind
the old one.
Hints for food refrigeration
• Meat (all types): wrap in a suitable
packaging and place it on the glass
shelf above the vegetable drawer.
Store meat for at most 1-2 days.
• Fruit and vegetables: clean thoroughly
(eliminate the soil) and place in a
special drawer (vegetable drawer).
• It is advisable not to keep the exotic
fruits like bananas, mangos, papayas
etc. in the refrigerator.
• Vegetables like tomatoes, potatoes,
onions, and garlic should not be kept in
the refrigerator.
• Butter and cheese: place in an airtight
container or wrap in an aluminium foil
or a polythene bag to exclude as much
air as possible.
• Bottles: close them with a cap and
place them on the door bottle shelf, or
(if available) on the bottle rack.
• Always refer to the expiry date of the
products to know how long to keep
them.
Leonard 9
CARE AND CLEANING
WARNING! Refer to Safety
chapters.
Cleaning the interior
Before using the appliance for the first
time, the interior and all internal
accessories should be washed with
lukewarm water and some neutral soap to
remove the typical smell of a brand-new
product, then dried thoroughly.
CAUTION! Do not use
detergents, abrasive powders,
chlorine or oil-based cleaners
as they will damage the finish.
CAUTION! The accessories
and parts of the appliance are
not suitable for washing in a
dishwasher.
Periodic cleaning
The equipment has to be cleaned
regularly:
1. Clean the inside and accessories with
lukewarm water and some neutral
soap.
2. Regularly check the door seals and
wipe them clean to ensure they are
clean and free from debris.
3. Rinse and dry thoroughly.
Defrosting of the refrigerator
Frost is automatically eliminated from the
evaporator of the refrigerator compartment
during normal use. The defrost water
drains out through a trough into a special
container at the back of the appliance,
over the motor compressor, where it
evaporates.
It is important to periodically clean the
defrost water drain hole in the middle of
the refrigerator compartment channel to
prevent the water overflowing and dripping
onto the food inside.
For this purpose use the tube cleaner
provided with the appliance.
Period of non-operation
When the appliance is not in use for long
period, take the following precautions:
1. Disconnect the appliance from
electricity supply.
2. Remove all food.
3. Clean the appliance and all
accessories.
4. Leave the door open to prevent
unpleasant smells.
TROUBLESHOOTING
WARNING! Refer to Safety
chapters.
10 Leonard
Table des matières
Langues :
Autres manuels Leonard Réfrigérateur
Leonard
Leonard LK0853 Manuel utilisateur
Leonard
Leonard LK1214 Manuel utilisateur
Leonard
Leonard LK1203 Manuel utilisateur
Leonard
Leonard LK1243 Manuel utilisateur
Leonard
Leonard LK1214 Manuel utilisateur
Leonard
Leonard LK0843 Manuel utilisateur
Leonard
Leonard LKT1441 Manuel utilisateur
Leonard
Leonard LK0803 Manuel utilisateur
Leonard
Leonard LK0843 Manuel utilisateur
Leonard
Leonard LK0843 Manuel utilisateur
