LEOCH LFeLi-48 Series Manuel utilisateur

LEOCH International Technology Limited

Integrated Lithium-ion Battery Pack for Telecom

User Manual

Version：V1.0

Released Date：2018-08-10

Document Number：LB-LFeLi-48100TB-UM-EN-V1.0-201808

Without the company's written permission, no unit or individual may unlawfully copy in part or in whole

the content of this document, and shall not disseminate it in any form.

Trademark Statement

and LEOCH other trademarks are the trademarks of LEOCH international technology co.

All other trademarks or registered trademarks mentioned in this document, by the respective owners.

Attention

On purchasing the products, services or features, such as international commercial contracts, you

accept and are bound by the terms described in this document, in part or in whole, the product, services

or features are strictly for your own purchase or use. Unless otherwise agreed in the contract, LEOCH

does not make any express or implied representations or warranties within the content of this document.

For product version upgrades or other reasons, this document will not be updated on a regular basis.

Unless otherwise agreed, this document serves only as a guide, all the statements in this document,

information and recommendations do not constitute any express or implied warranty.

LEOCH International Technology Limited

Add: 5th Floor, Xinbaohui Bldg., Nanhai Blvd, Nanshan, Shenzhen, China. 518052

Phone: +86-755-86036060/26067200

Fax: +86-755-26951222 / 26067217

E-mail:servic[email protected]m

Website: www.leoch.com

Integrated Lithium-ion Battery Pack For Telecom

User Manual

FOREWORD

Overview

This manual describes the installation, history recording and parameter settings etc.

Please keep the manual in safety for more information.

Readers

This document provides technical details regarding the tools and infrastructure used

by the following users:

Sales engineer

Technical support engineer

Installation engineer

Application engineer

Maintenance engineer

Symbol convention

The following symbols may appear in this article, and they are represented as follows:

Symbol

Indication

Used as warning in an emergency, if not avoided, it will result in

death or serious personal injury.

Used as a warning of a middle or low potential hazards, if not

avoided, it may cause minor or normal injury.

Integrated Lithium-ion Battery Pack For Telecom

User Manual

FOREWORD

iii

Used as a warning of potential dangers, if ignore this information,

it may result in equipment broken, data lost, equipment

performance decrease and other unpredictable result.

represents the supplement information of main text to emphasize

or replenish.

Change History

Changes between document issues are cumulative. The latest document issue

contains all the changes made in previous issues.

Version：V1.0 (2018-08-10)

This version is the first official release.

Integrated Lithium-ion Battery Pack For Telecom

User Manual

DIRECTORY

FOREWORD .................................................................................................................................... ii

DIRECTORY .................................................................................................................................... iv

1OVERVIEW .................................................................................................................................... 6

1.1 Product specification ..............................................................................................................................................6

1.2 Product profiles........................................................................................................................................................6

1.3 Product structure.....................................................................................................................................................7

2ILLUSTRATION.............................................................................................................................8

2.1 Panel description .....................................................................................................................................................8

2.2 Menu operation instructions..............................................................................................................................13

2.3 The working principle...........................................................................................................................................14

2.4 The product features ............................................................................................................................................15

3INSTALLATION GUIDE ............................................................................................................ 17

3.1 Installation precaution notes..............................................................................................................................17

3.2 Installation preparation........................................................................................................................................19

3.2.1 Unpacking and inspection................................................................................................................................19

3.2.2 Installation tools .................................................................................................................................................20

3.3 Installation and wiring..........................................................................................................................................21

3.3.1 Standard cabinet installation...........................................................................................................................21

4MAINTENANCE.........................................................................................................................27

4.1 Electrical maintenance..........................................................................................................................................27

4.2Battery maintenance.............................................................................................................................................28

4.3 Treatment for malfunctions ................................................................................................................................28

Integrated Lithium-ion Battery Pack For Telecom

User Manual

DIRECTORY

5SPECIFICATIONS ....................................................................................................................... 33

5.1 Technical specifications........................................................................................................................................33

5.2 The main performance index of the battery ..................................................................................................34

6ENVIRONMENT PROTECTION ............................................................................................. 36

6.1 Environmental Label .............................................................................................................................................36

6.2 Recycle......................................................................................................................................................................36

7APPENDIX ................................................................................................................................... 37

7.1 Connection cable...................................................................................................................................................37

Integrated Lithium-ion Battery Pack For Telecom

User Manual

1 OVERVIEW

1.1 Product specification

The model of integrated lithium Ion battery (hereafter referred to as lithium battery or

PACK) for Telecom is shown in figure 1-1.

Figure1-1 The explanation of the product specification

①Trademark of Leoch: LEOCH

②The main ingredient of Lithium Ion battery is Lithium iron phosphate

③The pressure is 48V

④The capacity is 100Ah

⑤High-performance Series

⑥With a LCD display

1.2 Product profiles

The lithium battery group is developed by Leoch international technology Co. Ltd.

Belonging to one of the series of 48V communication for back-up lithium battery

products, the system adopts the international advanced lithium iron phosphate

battery application technology and BMS control technology. Due to it’s a long lifecycle,

small size, light weight, stable performance, safety and environmental protection, as

well as a strong ability to adapt, it can be used in harsh outdoor environments.

Integrated Lithium-ion Battery Pack For Telecom

User Manual

1 OVERVIEW

The system integrates advanced battery manage system (BMS), including charge

and discharge management, thermal management, communication management,

balance management, data management, and realize remote centralized monitoring,

remote management and maintenance of the battery. It has outstanding advantages

in specific occasions, as a backup power supply is widely used in the remote access

network equipment, exchange, mobile communication equipment, transmission

equipment, satellite and microwave communication equipment and communication.

1.3 Product structure

The appearance of the lithium battery pack is shown in figure 1-2, for interface

description; please refer to the 2.2 panel description".

Figure1-2 Product picture

Integrated Lithium-ion Battery Pack For Telecom

User Manual

2 ILLUSTRATION

2.1 Panel description

The lithium battery panel as the Figure2-1 shows below.

Figure2-1 Module panel description

For detailed descriptions of each location, see the following figure2-2.

Integrated Lithium-ion Battery Pack For Telecom

User Manual

2 ILLUSTRATION

Figure2-2 Panel Effect Chart

1 Handle

2 SOC (capacity light)

3 ALM（alarm）

4 RUN

5 ADD

6 RS232

7 RS485

8 RESET

9 Dry Contact

10 Main panel

11 Mounting holes

12 Output-

13 MCB

14 Output﹢

15 LCD display

Handle

Made of galvanized steel and make it for transportation.

SOC

The meaning of SOC indication light shown in table 2-1

Table2-1 The relationship between the capacity of the battery and the light

●

Capacity

75%-100%

○

50%-75%

○

25%-50%

○

0%-25%

¤indicates ON，○indicates OFF。
