MODEL CD-79

OPERATING INSTRUCTIONS

PLEASE READ CAREFULLY BEFORE USE

PLAYS ALL MUSIC COMPACT DISCS

BASS BOOST SYSTEM

6 DIGIT LCD VISUAL DISPLAY

TRACK REPEAT & DISC REPEAT

10 SECOND ESP (ELECTRONIC SHOCK PROTECTION) PLUSTM SYSTEM

DELUXE STEREO HEADPHONES INCLUDED

CAR POWER CORD AND CASSETTE ADAPTOR INCLUDED

AC ADAPTOR INCLUDED

USES 2 SIZE AA BATTERIES (NOT INCLUDED)

AUX OUT JACK - CONNECTS TO YOUR STEREO SYSTEM

CD79(12D-10E2)011240 NL v.1 E

10 SECOND ESP PLUS

ELECTRONIC SHOCK PROTECTION

PROGRAMMABLE COMPACT DISC PLAYER

WITH CAR ADAPTOR KIT

INTRODUCTION

Your new Lenoxx Sound model CD-79 portable compact disc player, uses the latest

technology to give you crisp clean sound from all your compact discs.

Please read these operating instructions completely to take advantage of all the features

of this set.

ACCESSORIES INCLUDED

AC ADAPTOR STEREO HEADPHONES

CAR CASSETTE ADAPTOR CAR CIGARETTE LIGHTER

ADAPTOR

NOTE: Adaptor may look slightly different

from above illustration.

LOCATION OF CONTROLS

3567

1. CD DOOR OPEN BUTTON (slide to open)

2. CD DOOR

3. BACKWARD SKIP/SEARCH BUTTON ( )

4. PROGRAM BUTTON

5. FORWARD SKIP/SEARCH BUTTON ( )

6. ESP+ (electronic shock protection) BUTTON

7. STOP AND POWER OFF BUTTON

8. REPEAT/RANDOM BUTTON

9. LCD DISPLAY

10. PLAY/PAUSE BUTTON

11. AC ADAPTOR JACK

12. AUX OUT JACK (for home stereo connection)

13. VOLUME CONTROL

14. PHONES JACK (headphones jack)

15. BATTERY DOOR

16. BASS BOOST SWITCH

POWER SOURCES

1.Using with Batteries

TIPS ON BATTERY USE

Reversing polarities will damage the batteries and possibly your set. Be sure to

follow polarity ( + and - ) as indicated.

Do not mix different types together (Alkaline, Carbon-Zinc, Nickel-Cadmium etc.),

or old batteries with new ones.

When not in use for an extended period of time, or while internal batteries will not

be used, remove them to prevent possible acid leakage or corrosion resulting in

damage to your player.

When the batteries have become discharged, they must be disposed of in a safe

manner that complies with all applicable laws.

Installation of batteries should only be done by an adult (for safety).

WHEN FLASHES IN THE DISPLAY

If the alkaline batteries are weak and discharged, this symbol   flashes in the

display, then the power automatically turns off. If this occurs, replace the alkaline

batteries (also if display does not show anything, the batteries are dead).

ALKALINE BATTERY LIFE

Bear in mind that battery life expectancy is based upon volume and bass listening

levels.

Maximum battery power consumption happens at maximum settings. Typical life

for 2 size AA alkaline batteries is above 8 hours of continuous use.

Insert two size AA alkaline batteries

according to the + and - markings in

the battery compartment.

NOTE: You may use rechargeable batteries on this set. However, because

rechargeable batteries generally have lower voltage (1.2 volts instead of

1.5 volts). Your playing time will be much less than normal fresh alkaline

batteries.

2.Using AC Power

Your player may be powered from any household 120V AC outlet, using the AC

adaptor included. Insert the adaptors small connector plug into the DC 4.5V Jack

marked on player (on the right side of the set), and plug the adaptor into

an AC outlet.

NOTE: If the AC Adaptor is connected, and regular batteries are installed, the

player automatically switches to the AC Adaptor power and the batteries

are not used.

CAUTION:

To prevent electric shock, do not use this AC Adaptor with an extension cord or

outlet, unless it can be fully inserted without exposing any part of the blades. Do

not use any other AC adaptor to power this set or you may damage your set.

3.Using Cigarette Lighter Adaptor

Use the cigarette lighter adaptor to supply power to

your player and conserve battery life when using the

CD player in a car (no batteries are needed).

Plug the adaptor into the car cigarette lighter. Insert

firmly, and the cigarette lighter indicator will light up.

Plug the other end into the DC 4.5V Jack on the right

of the set.

If there is no power, your fuse may have blown. To

change fuse on cigarette lighter adaptor, unscrew

the tip. Replace only with same 1A 250V fuse.

CAUTION:

Use this set only with the supplied cigarette lighter adaptor. Use with other cigarette

lighter adaptors could damage the set.

When the inside of the cigarette lighter socket is dirty with ashes, the plug section may

become hot due to poor contact. Be sure to clean your car cigarette lighter socket

before use.

After use, disconnect the cigarette lighter adaptor plugs from both the set and the

cigarette lighter socket.

The cigarette lighter adaptor may cause interference with reception to the car radio. If

this happens, disconnect the cigarette lighter adaptor from the cigarette lighter socket.

Do not leave the cigarette lighter adaptor plugged in without your cars motor running,

your cars battery may drain in some models of cars that supply power to the cigarette

lighter plug even with the cars keys removed.

Cigarette Lighter

Indicator

CONNECTING TO HOME STEREO SYSTEMS

The AUX OUT jack is made to accept a stereo mini plug (3.5mm). Simply connect the

cables mini plug to the AUX OUT jack on your player, and the other appropriate end

usually RCA JACKS to the CD/AUX INPUTS of your home stereo.

YOUR CD PLAYER

TO AUX IN JACKSTO AUX OUT JACK

YOUR STEREO

SYSTEM

OPTIONAL CABLE (3.5mm)

TO RCA JACKS

NOTE: The car cassette adaptor has the play head on one side

only. If the cassette adaptor keeps ejecting out, or the sound is weak, press

the REVERSE button on your cassette player to change direction or reverse

the adaptor.

Remove two large

screws with a dime

or screwdriver

Fig. 1 Fig. 2

Move cord to desired

position (three cord

positions)

The car cassette adaptor allows you to use your CD player with your car stereo

cassette system or portable audio cassette system.

1. Insert the car cassette adaptor in the same direction as you would insert an audio

cassette tape, with the side marked

THIS SIDE UP

facing upwards.

Reposition the cord

The cord should extend out from the cassette player

when the cassette is inserted (direction depending

on your tape player).

1. To reposition the cord, remove the top plate by

removing 2 screws with a dime (see Fig. 1).

2. Reposition the cord so that it comes out from

other positions (see Fig. 2).

3. Replace the cover and the screws.

TO AUX OUT JACK

CASSETTE ADAPTOR

2. If the car cassette adaptor cord is on the wrong side

of the tape, reposition the cord by following the

instructions below.

3. Insert the car cassette adaptor stereo plug into the

AUX OUT jack on the right of the CD player.

4. Turn on the cassette player. Press PLAY button on

the cassette player.

5. Press PLAY on the CD player.

6. Adjust the volume on your cassette player.

7. When done, leave the cassette player on and first

eject the adaptor, then turn off cassette player.

CD PLAYING

4Adjust the Volume.

1Load the Disc.

2Connect the Headphones.

3Press the PLAY/PAUSE button.

1234

Push

here

Disc

Label side up Slide right to open

To PHONES jack

Stereo headphones

PLAY/PAUSE

button

VOLUME CONTROL

TRACK NUMBER

CURRENTLY

PLAYING

ELAPSED PLAYING

TIME OF THE

CURRENT TRACK

TOTAL TRACKS TOTAL PLAYING

TIME ON THE CD

Other Operations

Operation Press Display window shows

To pause play

To release pause

and resume play

TRACK NUMBER

CURRENTLY PLAYING

PLAYING TIME

FLASHES

TRACK NUMBER

CURRENTLY PLAYING

PLAYING TIME

ADVANCES

To stop

To skip to the next track(s)

To skip to the previous track(s)

once (or repeatedly)

To go ahead at high speed

(search) Keep depressed and release when the

desired music section of the disc is found.

To go back at high speed

(search) Keep depressed and release when the

desired music section of the disc is found.

BASS BOOST switch

This switch enhances the low frequency (bass)

sounds at low listening levels. Switch this ON or

OFF to suit your taste.

TOTAL TRACKS TOTAL PLAYING TIME

PLAY/PAUSE

button

PLAY/PAUSE

button

STOP button

To turn off the power STOP button once and wait 30 seconds, or press

STOP button twice

BASS BOOST switch

Single Track Repeat

Plays one song over and over till you press STOP.

During play, select the song you want to repeat with

either of the SEARCH buttons ( or ), then press

the REPEAT/RANDOM button once, the symbol

REPEAT

appears in the display.

The song currently playing will repeat over and over,

until you press STOP.

All Tracks Repeat

Repeats all songs in order, till you press STOP.

During play, press the REPEAT/RANDOM button twice,

the symbol

REPEAT ALL

will show in the display.

All songs will keep playing in sequence 1, 2, 3, etc. and

when finished, will start all over again until you press the

STOP button.

REPEAT, INTRO AND RANDOM PLAY

You may have repeat, intro or random play using the REPEAT/RANDOM button.

Press the REPEAT/RANDOM button several times, and the display will show the

followings in turn:

REPEAT 1 --> REPEAT ALL --> INTRO --> SHUFF (RANDOM) --> NORMAL PLAY

Intro Play

This plays the first 10 seconds of songs in sequential

order.

1. During play, press the REPEAT/RANDOM button

three times, the word

INTRO

will flash in the display.

2. Press the PLAY button, the word

INTRO

will stop

flashing and the first 10 seconds of each song on the

CD will play in sequential order.

3. When you find a song you like, press the PLAY button,

normal play will be resumed, that song (and the

following songs) will play NORMALLY.

Random Play

This plays the songs on the disc in a random order.

1. During play, press REPEAT/RANDOM button four times

the word

SHUFF

will flash.

2. Press the PLAY button, this will play all of the songs

in random order selected by the CD player. The word

SHUFF

will stop flashing.

3. Press the SEARCH button to skip to the next

random song.

REPEAT 1

X 1

REPEAT ALL

X 2

INTRO

SHUFF

X 3

X 4

The tracks (songs) on the disc can be programmed (arranged in advance) to play in

any order you prefer (up to 20 tracks can be programmed).

Programming Example:

Program Number 1 2 3 4 5 6 7 8

Track Number (song number) 35 8 1 2 4 1 1

etc.

PROGRAM PLAY

During programming, the word

PROG

flashes in the display. To program songs to play

in your preferred order, follow steps below:

1.During play, press the PROGRAM

button.

The word

PROG

will flash in the display.

Program number

2.Press the SEARCH button ( or )

to select track number 3 (example).

PROG

and track number 03 will flash in the

display.

Track number

3.Press the PROGRAM button. Track 3 is

now programmed.

Program #2 will now show in the

display, ready for your next selection of

track.

4.Repeat steps 2 and 3 to program other

tracks till you finish (up to 20 selections).

5.After programming is finished, press

PLAY to begin programmed play.

PROG

changes to be steady on in

the display, and music begins to play in

the order you programmed.

NOTE:

- The player will stop automatically after

all programmed tracks have been

played.

- To quit programmed play, press STOP

button once. Then you may press PLAY

button to re-start normal play.

Your programming will be lost:

When the alkaline batteries are

exhausted or removed, or the AC

ADAPTOR is disconnected.

When the power is shut off or the CD

DOOR is opened.

PROG

Autres manuels Lenoxx Lecteur CD

Lenoxx

Lenoxx CD-155 Manuel utilisateur

Lenoxx

Lenoxx PR4057 Manuel utilisateur

Lenoxx

Lenoxx CD-87 Manuel utilisateur

Lenoxx

Lenoxx CD-88 Guide d'installation

Lenoxx

Lenoxx CD-91 Manuel utilisateur

Lenoxx

Lenoxx CD-57 Manuel de l'opérateur

Lenoxx

Lenoxx CD-857 Manuel utilisateur

Lenoxx

Lenoxx CD-52 Manuel de l'opérateur

Lenoxx

Lenoxx Durabrand CD-565 Manuel de l'opérateur

Lenoxx

Lenoxx Durabrand CD-62 Manuel utilisateur

Lenoxx

Lenoxx CD-87 Manuel de l'opérateur

Lenoxx

Lenoxx CD-85 Manuel utilisateur

Lenoxx

Lenoxx Durabrand CD-56 Manuel utilisateur

Lenoxx

Lenoxx CD-895 Manuel de l'opérateur

Lenoxx

Lenoxx CD-61 Manuel de l'opérateur

Lenoxx

Lenoxx CD-90 Manuel utilisateur

Lenoxx

Lenoxx CD-155 Manuel utilisateur

Lenoxx

Lenoxx CDR-1906 Manuel utilisateur

Lenoxx

Lenoxx CD-52 Manuel utilisateur

Lenoxx

Lenoxx CD-625 Manuel de l'opérateur

Lenoxx

Lenoxx Durabrand CD-62 Manuel de l'opérateur

Lenoxx

Lenoxx CD-625 Manuel utilisateur

Lenoxx

Lenoxx CD-61 Manuel utilisateur

Lenoxx

Lenoxx Durabrand CD-565 Manuel utilisateur

Manuels Lecteur CD populaires d'autres marques

RCA

RCA RP-7923 Manuel utilisateur

Pioneer

Pioneer DEH-P3550MP XM Manuel utilisateur

Philips

Philips AZ1207 Manuel utilisateur

Philips

Philips CD582 Manuel utilisateur

Philips

Philips AZ 6821 Manuel utilisateur

Lasonic

Lasonic MSU-2020 Manuel utilisateur

THOMSON

THOMSON RCD150 Manuel utilisateur

Denon

Denon DCD-1420 Manuel utilisateur

Panasonic

Panasonic SJ-MR100 Manuel utilisateur

Onkyo

Onkyo DX-7210 Manuel utilisateur

Sony

Sony MZ-R3 Manuel utilisateur

Denon

Denon DVM-4800 Manuel utilisateur

JBL

JBL MR-32 Manuel utilisateur

RCA

RCA RCD152 Manuel utilisateur

Technics

Technics SL-PS770A Manuel utilisateur

Clarion

Clarion compact disc Manuel utilisateur

Sony

Sony MZ-M10 Manuel utilisateur

Philips

Philips Expanium AZ 1538 Manuel utilisateur
