Lenovo TB3-X70F Comment utiliser

English/Français/España

Lenovo TAB3 10 Business

Safety, Warranty & Quick Start Guide

Lenovo TB3-X70F

Lenovo TB3-X70L

English ............................................................................................. 1

Français.......................................................................................... 12

España........................................................................................... 23

Contents

Read this guide carefully before using your Lenovo TAB3 10 Business.

All information labeled with * in this guide only refers to the WLAN + LTE model

(Lenovo TB3-X70L).

Reading ﬁrst - regulatory information

Device models equipped with wireless communications comply with the radio

frequency and safety standards of any country or region in which it has been

approved for wireless use. In addition, if your product contains a telecom modem,

it complies with the requirements for connection to the telephone network in your

country.

Be sure to read the Regulatory Notice for your country or region before using the

wireless devices contained in your device. To obtain a PDF version of the Regulatory

Notice, refer to the “Downloading publications” section below.

Getting support

To get support on network service and billing, contact your wireless network operator.

To learn how to use your tablet and view its technical speciﬁcations, go to

http://support.lenovo.com.

Downloading publications

Electronic versions of your publications are available from http://support.lenovo.com.

To download the publications for your tablet, go to http://support.lenovo.com and

follow the instructions on the screen.

Accessing your User Guide

Your User Guide contains detailed information about your tablet. To access your User

Guide, go to http://support.lenovo.com and follow the instructions on the screen.

Legal notices

Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other

countries, or both.

Other company, product, or service names may be trademarks or service marks of

others.

Manufactured under license from Dolby Laboratories. Dolby, Dolby Atmos, and the

double-D symbol are trademarks of Dolby Laboratories.

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant

a General Services Administration “GSA” contract, use, reproduction, or disclosure is

subject to restrictions set forth in Contract No. GS-35F-05925.

English

The WLAN model (Lenovo TB3-X70F) does not have a Micro-SIM card slot.

6Speakers

5On/Off button

4Volume button

9*Micro-SIM card slot

8microSD card slot

7Rear camera

10 Microphone

3Micro USB connectorFront camera

1Earphone jack

Lenovo TAB3 10 Business overview

Model Version

Lenovo TB3-X70F

Lenovo TB3-X70L

WLAN

WLAN + LTE

Only Micro-SIM card works with your tablet.

Do not insert or remove the Micro-SIM card while your tablet is on. Doing so can

permanently damage your Micro-SIM card or tablet.

You can use cellular services with the WLAN + LTE model (Lenovo TB3-X70L) by inserting

the Micro-SIM card provided by your carrier.

Install the Micro-SIM and microSD cards as shown.

Preparing your tablet

Step 1. Open the card slot cover.

Step 3. Replace the card slot cover.

Step 2. Insert the Micro-SIM and microSD cards as shown.

Micro

SIM

microSD

Turning on/off

Connect your tablet to a power outlet using the cable and USB power adapter provided.

Low battery Fully charged Charging

Turn on: Press and hold the On/Off button until the

Lenovo logo appears.

Turn off: Press and hold the On/Off button for a few

seconds, then tap Power off.

Restart: Press and hold the On/Off button for about

10 seconds.

You might need to charge the battery before using your tablet.

Charge the battery as shown.

Starting to use your tablet

Taking screenshots

Press and hold the On/Off button and the Volume down button at the same time.

Important safety and handling information

Plastic bag notice

DANGER: Plastic bags can be dangerous. Keep plastic bags away from babies and

children to avoid danger of suffocation.

Built-in rechargeable battery notice

DANGER: Do not attempt to replace the internal rechargeable lithium ion battery. Risk of

explosion if the battery is replaced with an incorrect type. Contact Lenovo Support for

factory replacement.

Polyvinyl Chloride (PVC) cable and cord notice

WARNING: Handling the cord on this product or cords associated with accessories sold

with this product will expose you to lead, a chemical known to the State of California to

cause cancer, and birth defects or other reproductive harm. Wash hands after handling.

Water resistance

Advanced nano-coating technology creates a water repellent barrier to help protect

against moderate exposure to water such as accidental spills, splashes or light rain.

Not designed to be submersed in water, or exposed to pressurized water, or other

liquids; not waterproof.

Prevent hearing damage

Your device has a headphone connector. Always use the headphone connector for

headphones (also called a headset) or earphones.

CAUTION: Excessive sound pressure from earphones and headphones can cause

hearing loss. Adjustment of the equalizer to maximum increases the earphone and

headphone output voltage and the sound pressure level. Therefore, to protect your

hearing, adjust the equalizer to an appropriate level.

Excessive use of headphones or earphones for a long period of time at high volume can

be dangerous if the output of the headphone or earphone connectors does not comply

with speciﬁcations of EN 50332-2.

The headphone output connector of your device complies with EN 50332-2 Sub

clause 7. This speciﬁcation limits the device's maximum wide band true RMS output

voltage to 150 mV. To help protect against hearing loss, ensure that the headphones or

earphones you use also comply with EN 50332-2 (Clause 7 limits) for a wide band

characteristic voltage of 75 mV. Using headphones that do not comply with EN 50332-2

can be dangerous due to excessive sound pressure levels.

Warning statement: To prevent possible hearing damage, do not listen at high volume

levels for a long period of time.

European Union compliance statement

Radio and Telecommunications Terminal Equipment Directive

0560

Lenovo declares that this product is in compliance with:

● The essential requirements and other relevant provisions of the Radio and

Telecommunications Terminal Equipment Directive, 1999/5/EC

● All other relevant EU directives

The Declaration of Conformity information is located in the Regulatory Notice. To obtain

a PDF version of the Regulatory Notice, go to http://support.lenovo.com.

Service and support information

The following information describes the technical support that is available for your

product, during the warranty period or throughout the life of your product. Refer to the

Lenovo Limited Warranty (LLW) for a full explanation of Lenovo warranty terms. See

“Lenovo Limited Warranty notice” later in this document for details on accessing the full

warranty.

If your device came with headphones or earphones in the package, as a set, the

combination of the headphones or earphones and the device already complies with the

speciﬁcations of EN 50332-1. If different headphones or earphones are used, ensure that

they comply with EN 50332-1 (Clause 6.5 Limitation Values). Using headphones that do

not comply with EN 50332-1 can be dangerous due to excessive sound pressure levels.

Sound pressure warning statement

For the device that is tested in accordance with EN 60950-1:

2006+A11:2009+A1:2010+A12:2011+A2:2013, it is mandatory to perform audio tests for

EN 50332.

This device has been tested to comply with the Sound Pressure Level requirement laid

down in the applicable EN 50332-1 and/or EN 50332-2 standards. Permanent hearing

loss may occur if earphones or headphones are used at high volume for prolonged

periods of time.

Online technical support

Online technical support is available during the lifetime of a product at:

http://www.lenovo.com/support

Telephone technical support

You can get help and information from the Customer Support Center by telephone.

Before contacting a Lenovo technical support representative, please have the following

information available: model and serial number, the exact wording of any error message,

and a description of the problem.

Your technical support representative might want to walk you through the problem while

you are at your device during the call.

Worldwide Lenovo support telephone list

Important: Telephone numbers are subject to change without notice. The most

up-to-date telephone list for the Customer Support Center is always available at:

http://www.lenovo.com/support/phone

If the telephone number for your country or region is not listed, contact your Lenovo

reseller or Lenovo marketing representative.

Warranty information

Lenovo Limited Warranty notice

This product is covered by the terms of the LLW, version L505-0010-02 08/2011. You

can read the LLW at http://www.lenovo.com/warranty/llw_02. You can read the LLW in

a number of languages from this Web site. If you cannot view the LLW from the Web site,

contact your local Lenovo ofﬁce or reseller to obtain a printed version of the LLW.

Warranty period and type of warranty service

Country or region Warranty period

1,3

1,4

France, Germany, Italy, Austria,

United Kingdom, Israel, Australia,

New Zealand

Parts and Labor - 1 year

Battery Pack - 1 year

Type of warranty

service

Parts and Labor - 1 year

Battery Pack - 1 year

Guatemala, Costa Rica, Venezuela, Peru,

Uruguay, Ecuador, Colombia, Chile,

Argentina, Indonesia, Vietnam, India,

Malaysia, Thailand, Philippines, Singapore,

Hong Kong, El Salvador

* Excludes some components. 90-day limited warranty for power adapters, keyboards,

plastics and hinges.

Types of warranty service

1. Customer Replaceable Unit (“CRU”) Service

2. On-site Service

3. Courier or Depot Service

4. Customer Carry-In Service

5. Mail-in Service

6. Customer Two-Way Mail-in Service

7. Product Exchange Service

For a full explanation of the types of warranty service, refer to the full warranty. See

“Lenovo Limited Warranty notice” for details on accessing the full warranty.

1,5

Panama 2,4

Taiwan, South Korea 3,4

Brazil 2,5

1,3

1,5

Turkey 3,4

4Saudi Arabia

Serbia 1,4

Type of warranty

service

Russia, Ukraine, Egypt, Lebanon, Morocco,

South Africa, Tunisia, Mauritius, Mozambique,

United Arab Emirates, Jordan, Kenya, Nigeria,

Uganda, Ghana, Oman,Tanzania, Namibia

Parts and Labor - 1 year

Battery Pack - 1 year

Parts and Labor - 1 year

Battery Pack - 1 year

United States of America, Canada, Mexico,

Japan

Spain, Switzerland, Portugal, Netherlands,

Belgium, Sweden, Denmark, Norway, Finland,

Estonia, Latvia, Lithuania, Iceland

Czech Republic, Hungary, Romania, Bulgaria,

Greece, Croatia, Slovenia, Slovakia, Cyprus,

Poland

Parts and Labor - 1 year

Battery Pack - 1 year

Parts and Labor - 1 year

Battery Pack - 1 year

Parts and Labor - 1 year

Battery Pack - 1 year

Parts and Labor - 2 years

Battery Pack - 1 year

Parts and Labor - 2 years

Battery Pack - 1 year

Parts and Labor - 2 years

Battery Pack - 2 years

Parts and Labor - 2 years

Battery Pack - 2 years

Parts and Labor - 2 years

Battery Pack - 1 year

Country or region Warranty period

Autres manuels pour TB3-X70F

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Lenovo Comprimé

Lenovo

Lenovo TB-7306V Manuel d'exploitation et d'entretien

Lenovo

Lenovo TAB 7 Essential Comment utiliser

Lenovo

Lenovo IdeaPad A1-07 Manuel utilisateur

Lenovo

Lenovo IdeaPad A1-07 Guide de référence

Lenovo

Lenovo YOGA Tablet 2-851F Comment utiliser

Lenovo

Lenovo YOGA BOOK YB1-X90F Manuel utilisateur

Lenovo

Lenovo Tab P11 2nd Gen Comment utiliser

Lenovo

Lenovo 10w Manuel utilisateur

Lenovo

Lenovo TAB4 8 Comment utiliser

Lenovo

Lenovo Tab P11 5G Manuel utilisateur

Lenovo

Lenovo TAB3 7 Andy Manuel du propriétaire

Lenovo

Lenovo IdeaTab S6000 Manuel du propriétaire

Lenovo

Lenovo Lenovo S5000 Manuel utilisateur

Lenovo

Lenovo ThinkPad Hard Disk Drive Guide de référence rapide

Lenovo

Lenovo PB-6505Y Comment utiliser

Lenovo

Lenovo Smart Tab M10 Manuel utilisateur

Lenovo

Lenovo MIIX 3-1030 Manuel utilisateur

Lenovo

Lenovo YT3-850L Comment utiliser

Lenovo

Lenovo TAB A8-50 Manuel utilisateur

Lenovo

Lenovo mototab TB-X704A Manuel utilisateur

Lenovo

Lenovo Yoga 2 Pro Manuel du propriétaire

Lenovo

Lenovo Tab Extreme Manuel utilisateur

Lenovo

Lenovo TAB 2 A7-10F Comment utiliser

Lenovo

Lenovo Smart Tab M10 Comment utiliser

Manuels Comprimé populaires d'autres marques

Laser

Laser MID-1060 Guide de l'utilisateur

MUNBYN

MUNBYN IRT09J Guide de démarrage rapide

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Manuel utilisateur

Dell

Dell Latitude ST Manuel du propriétaire

Venturer

Venturer WT9L11 Manuel utilisateur

EDUGEAR

EDUGEAR UnoBook Manuel utilisateur

Philips

Philips PI3210G/58 Manuel utilisateur

ADLINK Technology

ADLINK Technology IMT-BT Manuel utilisateur

TwinMOS

TwinMOS TwinTAB-T102D1 Manuel utilisateur

Archos

Archos 9.7 xenon Manuel utilisateur

Getac

Getac E100 Manuel utilisateur

HANNspree

HANNspree HANNspad SN70T3 Manuel utilisateur

Philips

Philips PI3105W2/55 Manuel utilisateur

LG LG-V935 Manuel utilisateur

Zeki

Zeki TBDB763B Manuel utilisateur

Ricoh

Ricoh eQuill Manuel utilisateur

DT Research

DT Research DT365CT Instructions de montage

MaxWest

MaxWest Nitro Phablet 9 Manuel utilisateur
