You can use the ThinkPad

770X User's Reference

for the ThinkPad 770Z computer

. This

supplement includes updated information for the

User's Reference

(part number 27L3407). Use this

information instead of the corresponding information in the

User's Reference

Single FDD support

Although the

User's Reference

states that several FDDs can be supported by the ThinkPad

computer, your computer can support only one FDD at a time. The FDD in the bay always takes

precedence over the external FDD. For example, in suspend mode, if you install an FDD in the bay

and attach an FDD externally, the computer recognizes the FDD in the bay after resuming.

This information also applies when you are using the docking station.

Software Selections CD

Although your

User's Reference

describes the ThinkPad Customization Center CD, and the

Setup

Guide

describes a ThinkPad Customization Center icon, your computer has a Software Selections

CD rather than the ThinkPad Customization Center CD, and there is no ThinkPad Customization

Center icon on the desktop. The Software Selections CD includes the preloaded software and

ThinkPad device drivers for Windows 98, Windows 95, and Windows NT. You can customize your

computer with this CD. To use the Software Selections CD, insert it into the CD-ROM or DVD

drive. The main menu appears. Follow the instructions on the screen. For more information, click

Help in the menu.

Part Number: 27L8686

ThinkPad 770Z

User's Reference and Setup Guide Supplement

 Copyright IBM Corp. 1998

Updated Diskette Factory

Because of the new function in the Software Selections CD, the Diskette Factory no longer supports

all device drivers. You can see the supported software listed in the Diskette Factory main window.

New diskette name

The diskette name in the description of the Personalization Editor in the

User's Reference

has

changed from

Utility Diskette for DOS

Personalization Data Update Diskette

The Recovery CD

The Recovery CD is a startable CD-ROM and is not shipped with a boot diskette. The description

about using the Recovery CD with the boot diskette in the

User's Reference

no longer applies.

Asset ID icon

The “Config” menu of Easy-Setup includes an Asset ID icon ( ), for a new radio-frequency ID

option that is supported in specified models. More details are provided in the option's user's guide.

Docking your computer to a docking station

– If you use a SelectaDock I or SelectaDock II docking station, connect the power cord to a

docking station and the AC Adapter to a SelectaBase 770 port replicator.

– If you use a SelectaDock III docking station, connect the power cord to the docking station.

Notice for using the external monitor

If you use the Both LCD and CRT Display function, the external monitor must support the same

resolution as that of your ThinkPad LCD.

If you are using an external monitor that does not support the maximum resolution of the ThinkPad

LCD (1024 X 768 for the XGA model, or 800 X 600 for the SVGA model), do not use Both LCD

and CRT Display.

Notice for using the Compact Smart Card

Some Compact Smart Cards are too thick to be inserted into the upper PC Card slot of your

computer. Insert the card into the lower slot.

Solving computer problems

Docking station problems

The following troubleshooting might apply to users who are using the docking station—SelectaDock

I, II, III, or the Port Replicator with Advanced EtherJet Feature—under the Windows 95

environment.

Note: In the following steps, src_cd is the drive letter of the DVD or CD-ROM drive and cc is the

respective country code.

The following table shows the country code that you will need in the instructions:

Country Code Country Code Country Code

Denmark DK Italy IT Spain SP

Finland FI Japan JP Sweden SW

France FR Netherlands NL United

States US

Germany GR Norway NO

Problem Action

PC Cards in the docking

station cannot be recognized

after you warm-dock your

computer to the docking

station.

PC Card modems, SCSI

cards, ATA cards, 3Com

Combo Cards, or CardBus

Cards in the docking station

don't work after the computer

resumes from the power

management mode.

1. Start Windows 95.

2. Insert the Software Selections CD into the CD-ROM drive.

3. At the DOS prompt, type:

COPY src_cd:\DATA\WIN95\cc\W95UPD\PCI.VXD C:\WINDOWS\SYSTEM

and press Enter.

You are prompted if it is okay to overwrite the file.

4. Type Y and press Enter.

The system reboots when you

insert the PC Card into the

docking station.

1. Start Windows 95.

2. Insert the Software Selections CD into the CD-ROM drive.

3. Click Start and move the cursor to Program; then click on

Windows Explorer.

4. Click the driver letter of the DVD or CD-ROM drive.

5. Double-click PCMCIA.REG under DATA\WIN95\cc\W95UPD

6. Click OK.

Audio problem

Battery pack problem

Protection notice requirement

This device is protected by U.S. patent numbers 4631603, 4577216, 4819098, 4907093, and other

intellectual property rights. The use of Macrovision's copy protection technology in the device must

be authorized by Macrovision and is intended for home and other limited pay-per-view use only,

unless otherwise authorized in writing by Macrovision. Reverse engineering or disassembly is

prohibited.

Sound synchronization restriction

For some MPEG1 or MPEG2 files, the sound might not synchronize with the movie.

Problem Action

(

Windows 95 or Windows 98

users:

) Wave or MIDI sound does

not play correctly.

Make sure that the built-in audio device is configured correctly:

1. Click Start.

2. Move the cursor to Program; then click Control Panel.

3. Double-click System.

4. Click the Device Manager tab.

5. Click the + mark by Sound, video and game controller.

6. Make sure all the following devices are enabled and configured

correctly:

Crystal PnP audio System CODEC

Crystal PnP audio System Control Registers

Crystal SoundFusion PCI Audio Accelerator

Crystal SoundFusion Virtual MPU-401

Problem Action

The battery pack cannot be

charged. The battery pack might not be able to charged when it is hot. In that

case, remove it from the computer and leave it at room temperature for

a while. After it cools down, reinstall it and recharge it. If it cannot be

charged, have it serviced.
