Lenovo 90U9003QMH Manuel utilisateur

IdeaCentre 3

User Guide

Read this first

Before using this documentation and the product it supports, ensure that you read and understand the

following:

• Safety and Warranty Guide

• Generic Safety and Compliance Notices

• Setup Guide

First Edition (November 2021)

LIMI ED AND RES RIC ED RIGH S NO ICE: If data or software is delivered pursuant to a General Services

Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-

35F-05925.

Contents

bout this documentation . . . . . . . . iii

Chapter 1. Meet your computer. . . . . 1

Front . . . . . . . . . . . . . . . . . . . . 1

Rear . . . . . . . . . . . . . . . . . . . . 3

Features and specifications . . . . . . . . . . . 4

USB specifications . . . . . . . . . . . . . . 4

Operating environment . . . . . . . . . . . . . 6

Chapter 2. Get started with your

computer . . . . . . . . . . . . . . . . . 7

Work with Windows . . . . . . . . . . . . . . 7

Windows help information . . . . . . . . . . 7

Connect an external display . . . . . . . . . . . 8

Chapter 3. Explore your computer . . . 9

Lock the computer . . . . . . . . . . . . . . 9

Lenovo Vantage. . . . . . . . . . . . . . . 10

Set the power plan . . . . . . . . . . . . . 11

ransfer data . . . . . . . . . . . . . . . . 11

Connect to a Bluetooth-enabled device (for

selected models) . . . . . . . . . . . . 11

Use the optical drive (for selected models) . . 12

Use a media card (for selected models) . . . . 12

Purchase accessories . . . . . . . . . . . . 12

Chapter 4. CRU replacement . . . . . 13

CRU list . . . . . . . . . . . . . . . . . . 13

Remove or replace a CRU . . . . . . . . . . . 14

Power cord. . . . . . . . . . . . . . . 14

Computer cover . . . . . . . . . . . . . 14

Front bezel . . . . . . . . . . . . . . . 15

Card reader . . . . . . . . . . . . . . 16

Optical drive . . . . . . . . . . . . . . 17

Optical drive bracket . . . . . . . . . . . 18

Storage drive . . . . . . . . . . . . . . 19

M.2 solid-state drive . . . . . . . . . . . 21

Memory module . . . . . . . . . . . . . 23

Heat sink . . . . . . . . . . . . . . . 24

Coin-cell battery. . . . . . . . . . . . . 25

PCI Express card . . . . . . . . . . . . 26

Power supply assembly . . . . . . . . . . 27

Chapter 5. Help and support . . . . . 29

Frequently asked questions . . . . . . . . . . 29

Self-help resources . . . . . . . . . . . . . 29

Call Lenovo . . . . . . . . . . . . . . . . 31

Before you contact Lenovo . . . . . . . . 31

Lenovo Customer Support Center . . . . . . 31

Purchase additional services. . . . . . . . . . 32

ppendix . Notices and

trademarks . . . . . . . . . . . . . . . 33

ii IdeaCentre 3 User Guide

bout this documentation

• his guide applies to the Lenovo product models listed below. Illustrations in this guide may look slightly

different from your product model.

Model name Machine type (MT)

IdeaCentre 3 07IAB7 90SM

• For further compliance information, refer to the Generic Safety and Compliance Notices at https://

pcsupport.lenovo.com/docs/generic_notices.

• Depending on the model, some optional accessories, features, and software programs might not be

available on your computer.

• Depending on the version of the operating systems and programs, some user interface instructions might

not be applicable to your computer.

• Documentation content is subject to change without notice. Lenovo makes constant improvements to the

documentation of your computer, including this User Guide. o get the latest documentation, go to https://

pcsupport.lenovo.com.

• Microsoft® makes periodic feature changes to the Windows® operating system through Windows Update.

As a result, some information in this documentation might become outdated. Refer to Microsoft resources

for the latest information.

iv IdeaCentre 3 User Guide

Chapter 1. Meet your computer

Front

1. Power button 2. Card reader slot*

3. Microphone connector 4. Headset connector

5. USB-C® (3.2 Gen 1) connector 6. USB 3.2 connectors Gen 1(2)

7. Optical drive eject button* 8. Optical drive activity indicator*

9. Optical drive*

* for selected models

Power indicator

Show the system status of your computer.

• Blinking for three times: he computer is initially connected to power.

• On: he computer is on.

• Off: he computer is off or in hibernation mode.

• Blinking rapidly: he computer is entering sleep or hibernation mode.

• Blinking slowly: he computer is in sleep mode.

Related topics

• “USB specifications” on page 4.

• “Connect an external display” on page 8.

Chapter 1.Meet your computer 3

Features and specifications

For detailed specifications of your computer, go to https://psref.lenovo.com.

Hardware o view the hardware information of your computer, type device manager in the

Windows search box and then press Enter.

Power supply • 180-watt automatic voltage-sensing power supply

• 260-watt automatic voltage-sensing power supply

daptability for power supply

• Mainland China: 220 V ± 22 V, 50 Hz ± 1 Hz

• Adaptive voltage positioning: 90 V to 264 V, 50/60 Hz

• With voltage selection switch: 90 V to 264 V, 50 Hz ± 1 Hz

Microprocessor o view the microprocessor information of your computer, type system

information in the Windows search box and then press Enter.

Memory Double data rate 4 (DDR4) unbuffered dual in-line memory module (UDIMM)

Storage device

• Hard disk drive

• Solid-state drive

o view the storage drive capacity of your computer, type disk management in the

Windows search box and then press Enter.

Note: he storage drive capacity indicated by the system is less than the nominal

capacity.

Expansion

• Card reader slot*

• 2 DDR4 UDIMM slots

• 2 M.2 PCIe slots (1 for Wi-Fi; 1 for solid-state drive)

• 3.5–inch hard disk drive bay

• PCIe Gen 4 x16 slot

Network features

• Bluetooth

• Ethernet LAN

• Wireless LAN

* for selected models

USB specifications

Note: Depending on the model, some USB connectors might not be available on your computer.

4IdeaCentre 3 User Guide
