Lenovo 3000 H200 5357 Manuel utilisateur

Version 1.0 2008.8

3000 H User Guide

www.lenovo.com

31035089

31035089_3000 H_UG_FM_EN.indd 1 2008.8.27 6:06:02 PM

Important safety information

Before using this manual, it is important that you read and understand all the

related safety information for this product. Refer to the Safety and Warranty Guide

that you received with this product for the latest safety information. Reading and

understanding this safety information reduces the risk of personal injury or damage

to your product.

Danger: Watch out for high risks

Attention: Pay attention to low risks

Note: Pay attention to important information

31035089_3000 H_UG_EN.indd 1 2008.8.27 6:05:07 PM

31035089_3000 H_UG_EN.indd 2 2008.8.27 6:05:07 PM

Contents

Important safety information

Chapter 1 Instructions for using computer hardware ........... 1

1.1 Front view of the chassis ..........................................................2

1.2 Rear view of the chassis ..........................................................2

1.3 Using the Remote Control .......................................................4

1.4 Connecting your computer .....................................................6

Chapter 2 Rescue System operation instruction ................. 13

2.1 Installing drivers and software shipped with computer ............. 14

2.2 OneKey Recovery ..................................................................15

2.3 File Management ...................................................................16

2.4 OneKey Antivirus ...................................................................17

Chapter 3 Instructions for using computer software .......... 21

3.1 Power2Go - Burning Discs ...................................................22

3.2 WinDVD ................................................................................23

3.3 Lenovo Healthcare Software ..................................................24

3.4 Trend Micro Internet Security .................................................27

3.5 Veriface ................................................................................28

3.6 Earth link ..............................................................................29

Chapter 4 System maintenance and recovery ..................... 31

4.1 Restoring the system .............................................................32

4.2 File Backup ............................................................................32

4.3 Cleaning up the disk ..............................................................32

4.4 Checking for, and correcting disk errors .................................33

4.5 Defragmenting the disk(s) ......................................................33

4.6 Performing daily maintenance tasks .......................................33

31035089_3000 H_UG_EN.indd 1 2008.8.27 6:05:07 PM

2Contents

Chapter 5 Troubleshooting and Conﬁrming Setup .............. 35

5.1 Troubleshooting display problems ..........................................36

5.2 Troubleshooting audio problems ............................................36

5.3 Troubleshooting software problems .......................................37

5.4 Troubleshooting problems with optical drives and hard disks ... 38

5.5 Special considerations for troubleshooting Windows .............39

31035089_3000 H_UG_EN.indd 2 2008.8.27 6:05:08 PM

Chapter

Instructions for using computer

hardware

This chapter contains the following

topics:

ÿ Computer hardware introduction

ÿ Information on computer connection

Read the content carefully.

Note: If the conﬁguration description in

this chapter is different from your actual

computer, the conﬁguration of your actual

computer should be taken as ﬁnal and

binding.

User Guide 1

31035089_3000 H_UG_EN.indd 1 2008.8.27 6:04:40 PM

2User Guide

1.1 Front view of the chassis

Power button

USB connector

Headphone connector

Microphone connector

Memory Card Reader (some models are equipped with this connector).

Note: Some models are not equipped with a CD drive.

1.2 Rear view of the chassis

(If the rear view conﬁguration in this chapter is different from your actual computer,

the rear view conﬁguration of your actual computer should be taken as ﬁnal and

binding)

31035089_3000 H_UG_EN.indd 2 2008.8.27 6:04:42 PM

User Guide

Voltage selection switch (Some models are equipped with this switch)

Power connector

PS/2 keyboard connector

PS/2 mouse connector

Serial connector

Parallel connector ( Some models are equipped with this connector )

On-board VGA connector ( Some models are equipped with this connector )

USB connectors

Ethernet connector

Microphone connector

Audio line-out connector

Audio line-in connector

PCI Express x16 graphics adapter connector (Some models are equipped

with this connector. For more information about the graphics adapter, see

the description below).

31035089_3000 H_UG_EN.indd 3 2008.8.27 6:04:44 PM

4User Guide

1.3 Using the Remote Control

The remote control (only shipped with some types of computers) works with the

remote control receiver on the chassis. Adjust the angle of the remote control

properly.

31035089_3000 H_UG_EN.indd 4 2008.8.27 6:04:45 PM

User Guide

Buttons on the remote control:

Button Description Button Description

Up Fast Forward

Down Rewind

Left Skip

Right Replay

OK Conﬁrm Starts Windows Media

Center.

Back Turns volume up/down

Details Previous/next channel

Guide (This function is

not available in Microsoft

Windows operating

systems.)

Mute

Shows live TV on the

currently selected

channel.

DVD menu

Displays the Recorded

TV page in Windows

Media Center.

Power supply (standby)

Play 0~9 Number (or Letter) buttons

Pause ## key

Stop ** key

Record CLEAR Clear

ENTER Enter

31035089_3000 H_UG_EN.indd 5 2008.8.27 6:04:48 PM
