Lenovo 07ADA05 Manuel utilisateur

User Guide

IdeaCentre 3 (7L, 05)

Read this first

Before using this documentation and the product it supports, ensure that you read and understand the

fo owing:

• Safety and Warranty Guide

• Generic Safety and Compliance Notices

• Setup Guide

Second Edition (April 2023)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is de ivered pursuant to a Genera Services

Administration “GSA” contract, use, reproduction, or disc osure is subject to restrictions set forth in Contract No. GS-

35F-05925.

Contents

A out this documentation . . . . . . . . iii

Chapter 1. Meet your computer . . . . . 1

Front . . . . . . . . . . . . . . . . . . . . 1

Rear . . . . . . . . . . . . . . . . . . . . 4

Features and specifications . . . . . . . . . . . 6

Statement on USB transfer rate . . . . . . . . 6

Chapter 2. Get started with your

computer . . . . . . . . . . . . . . . . . 9

Work with Windows . . . . . . . . . . . . . . 9

Windows he p information . . . . . . . . . . 9

Connect an externa disp ay . . . . . . . . . . 10

Lenovo Vantage. . . . . . . . . . . . . . . 10

Chapter 3. Explore your computer . . 11

Manage power . . . . . . . . . . . . . . . 11

Set the power p an . . . . . . . . . . . . 11

Transfer data . . . . . . . . . . . . . . . . 11

Connect to a B uetooth-enab ed device (for

se ected mode s) . . . . . . . . . . . . 11

Use the optica drive (for se ected mode s) . . 12

Use a media card (for se ected mode s) . . . . 12

Lock the computer . . . . . . . . . . . . . 12

Purchase accessories . . . . . . . . . . . . 13

Chapter 4. CRU replacement . . . . . 15

What are CRUs . . . . . . . . . . . . . . . 15

Rep ace a CRU . . . . . . . . . . . . . . . 16

IdeaCentre 3 07ADA05 . . . . . . . . . . 16

IdeaCentre 3 07IMB05 . . . . . . . . . . 45

Chapter 5. Help and support . . . . . 81

Frequent y asked questions . . . . . . . . . . 81

Se f-he p resources . . . . . . . . . . . . . 81

Ca Lenovo . . . . . . . . . . . . . . . . 83

Before you contact Lenovo . . . . . . . . 83

Lenovo Customer Support Center . . . . . . 83

Purchase additiona services. . . . . . . . . . 84

Appendix A. Important safety

information . . . . . . . . . . . . . . . 85

Appendix B. Accessi ility and

ergonomic information . . . . . . . . 99

Appendix C. Compliance

information . . . . . . . . . . . . . . . 101

Appendix D. Notices and

trademarks . . . . . . . . . . . . . . . 113

ii User Guide

A out this documentation

• This guide app ies to the Lenovo product mode s isted be ow. I ustrations in this guide may ook s ight y

different from your product mode .

Model name Machine Type (MT) Machine Type (MT) for Energy Star

IdeaCentre 3 07ADA05 90MV, 90NT 90NT

IdeaCentre 3 07IMB05 90NB, 90NS 90NS

• For further comp iance information, refer to the Generic Safety and Compliance Notices at https://

pcsupport. enovo.com/docs/generic_notices.

• Depending on the mode , some optiona accessories, features, and software programs might not be

avai ab e on your computer.

• Depending on the version of the operating systems and programs, some user interface instructions might

not be app icab e to your computer.

• Documentation content is subject to change without notice. Lenovo makes constant improvements to the

documentation of your computer, inc uding this User Guide. To get the atest documentation, go to https://

pcsupport. enovo.com.

• Microsoft® makes periodic feature changes to the Windows® operating system through Windows Update.

As a resu t, some information in this documentation might become outdated. Refer to Microsoft resources

for the atest information.

iv User Guide

Chapter 1. Meet your computer

Front

IdeaCentre 3 07ADA05

1. Power button 2. Optica drive*

3. 7 in 1 card reader s ot* 4. Microphone connector

5. Headset connector 6. USB 2.0 connectors (2)

7. USB 3.2 connectors Gen 1 (2) 8. Optica drive activity indicator*

9. Optica drive eject/c ose button*

* for se ected mode s

IdeaCentre 3 07IMB05

1. Power button 2. Optica drive*

3. 7 in 1 card reader s ot* 4. Microphone connector

5. Headset connector 6. USB 3.2 connectors Gen 1 (4)

7. Optica drive activity indicator* 8. Optica drive eject/c ose button*

* for se ected mode s

Power indicator

Show the system status of your computer.

• Blinking for three times: The computer is initia y connected to power.

• On: The computer is on.

• Off: The computer is off or in hibernation mode.

• Blinking rapidly: The computer is entering s eep or hibernation mode.

• Blinking slowly: The computer is in s eep mode.

Headset connector (for IdeaCentre 3 07IMB05 only)

The headset connector is compatib e with:

• Headphones or earphones with a 3.5mm (0.14 inch), TRS (3-po e) p ug.

• Headsets with a 3.5mm (0.14 inch), CTIA-comp iant TRRS (4-po e) p ug.

Note: This headset connector does not support standa one externa microphones with a TRS (3-po e) p ug

or headsets with an OMTP-comp iant TRRS (4-po e) p ug.

2User Guide

Related topics

• “Use the optica drive (for se ected mode s)” on page 12.

• “Set the power p an” on page 11.

• “Statement on USB transfer rate” on page 6.

Chapter 1.Meet your computer 3

Rear

IdeaCentre 3 07ADA05

1. Pad ock oop 2. Security- ock s ot

3. Ethernet connector 4. Power adapter connector

5. USB 2.0 connectors (4) 6. HDMI™ 1.4 out connector

7. VGA-out connector 8. Audio ine-out connector

4User Guide
