Getting Started with

ThinkSmart View

Lenovo Smart Office | June 2020

ThinkSmartViewQuickSetup

1. Unbox the device and plug in AC adapter

2. Select the system language from the menu

3. Connect to your wireless network from the WLAN page

➢TIP: Turn the device to portrait (vertical) mode when logging

into a network to see more settings on screen

4. Pair a Bluetooth headset or select Skip

➢The Microsoft Teams screen will open

5. Tap Sign in or select Sign in from another device

6. Follow the prompts on screen to finish the process

➢Note: ThinkSmart View will register with the Company Portal /

Intune. For the first setup, Intune can take up to 10 minutes to

7. After registration, the main Teams screen will be shown

8. Go to Settings →Device Settings →Time & Date to change

your time zone and show the correct time

AC adapter

ProductOverview

ThinkSmart View is a new device for business,

tailored to meet the needs of employees in evolving

workspaces. It expands the desktop canvas,

supports a range of complementary uses, and

radically improves videoconferencing and

collaboration.

✓Tablet-sized touchscreen appliance with two-

position design for portrait and landscape

✓Standalone and complementary uses with your PC

✓Crystal clear audio and 5MP camera

✓Enterprise-ready, Easy to manage

Display

8” touch display; Anti

-glare and Anti-fingerprint coating

Microphone

Integrated microphone array built into the top of the device

Speakers

1.75” 10W Full

-size speaker, Two passive tweeters

Ports

USB Type

-C (Service and Support only)

Processor

Qualcomm® Snapdragon™ 624, Octa

-Core A53 1.8 GHz, 14 nm

Operating System

Android Open Source Project 8.1

Sensors

G, P, and L sensors

Software

Microsoft Teams for IP Phones

Buttons / Switches

Volume Rocker, Microphone Mute Switch, Camera Privacy Shutter

Signingintothedevice

Getting signed into your device:

1. Select the system language from the menu

2. Select your WLAN network from the list and login

➢TIP: Turn the device to portrait mode when logging into a

network to see more settings on screen

3. Pair to Bluetooth headset or select Skip

4. The Microsoft Teams screen will open. Tap Sign in

5. You can Enter your credentials or Sign in from another device

➢By selecting Sign in from another device a code will be

displayed on screen

➢Go to https://microsoft.com/devicelogin on another device and

enter the code

6. ThinkSmart View will register with the Company Portal / Intune

and then take you to the Microsoft Teams home screen.

Notes:

➢Intune policies can take up to 10 minutes to register on your

device. During this time, Company Portal may appear to be cycling.

➢Be sure to go to Device Settings and change your time zone.

Appearance and Mechanical

8” HD Display

Light/Proximity Sensor

5MP CameraFull Range

Speaker

Appearance and Mechanical

Camera

Privacy Shutter

Mute Switch Volume Buttons

Far field

Microphone array

Power adapter

Appearance and Mechanical

USB type-C Port Rubber

Note: Remove the rubber to reveal the port. This port

is only used by Lenovo service and support.

HomeScreen–Calendar

Calls View Calendar View Voicemail Screen

Create a meeting

One-touch Join

or Edit the meeting

Profile Options

and Settings

Search active

directory contacts

Meeting schedule

Meeting details

HomeScreen–Calls

Calls View Calendar View Voicemail Screen

Search and make a call

Setup favorites in Teams

desktop client

Profile Options

and Settings

Search active

directory contacts

Toggle between Favorites

and Recent calls

Dial Pad

(PSTN calling required)
