Lenovo S90-A Manuel utilisateur
Quick Start Guide
Lenovo S90-A
English/Українська/Русский/Română/ქართული
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the
United States, other countries, or both.
Other company, product, or service names may be trademarks or
service marks of others.
Getting support
For support on network service and billing, contact your wireless
network operator. For instructions on how to use Lenovo
smartphone, go to: http://support.lenovo.com/.
Downloading publications
To obtain the latest smartphone manuals, go to:
http://support.lenovo.com/
Accessing your User Guide
Your User Guide contains detailed information about your
smartphone. To access your User Guide, use one of the following
methods:
Go to: http://support.lenovo.com and follow the instructions
on the screen.
Turn on your smartphone, and then open the User Guide app.
Read this guide carefully before using your smartphone.
English
First glance....................................................................... 1
Installing the Micro SIM card.............................................2
Charging the battery......................................................... 3
Technical specifications .................................................... 4
Important regulatory, safety, and handling information....... 5
Service, support, and warranty information....................... 8
Recycling and environmental information ..........................9
Specific Absorption Rate information ...............................10
Contents
1
First glance
Front-facing camera
3
Fill Light
1Receiver
2
On/Off button
6
Light/Proximity sensor
4Volume buttons
5
Home button
9
Touch screen
7Back button
8
Flashlight
12
Menu button
10 Rear-facing camera
11
Speaker
15
Headset connector
13 Micro-SIM-card tray
14
16 17 Micro USB connector
Microphone
8
10 1713 16
9
2
3
4
1
5
6
7
11 12 13 14
15
2
Installing the Micro SIM card
SIM2
SIM1
SIM2
SIM1
SIM2
A Micro SIM card provided by your carrier is required in order to use
cellular services. Install the Micro SIM card as shown.
Step 1.
Step 2.
Step 3.
Insert the SIM eject tool that comes with your smartphone
into the hole in the Micro-SIM-card tray.
Pull out the Micro-SIM-card tray and position the Micro SIM
card into the tray in correct orientation.
Carefully insert the tray with the installed Micro SIM card
back into the slot.
Only Micro SIM cards work with your smartphone.
Always turn off your smartphone first before you insert or remove a
Micro SIM card. Insert or remove a Micro SIM card with your
smartphone on may damage your Micro SIM card or smartphone
permanently.
3
Charging the battery
Low battery power Fully charged Charging
Your smartphone has a built-in rechargeable battery. For more
information about battery safety, see the “Built-in rechargeable
battery notice” section. The battery in this product cannot be easily
replaced by users themselves.
Charge the battery as shown.
Turning on or turning off your smartphone
Turn on: Press and hold the On/Off button until
the Lenovo logo appears.
Turn of f: Press and hold the On/Off button for a
few seconds, then tap Power off.
Restart: Press and hold the On/Off button for
about 10 seconds.
Method 1.
Method 2.
Connect your smartphone to a power outlet using the
cable and USB power adapter that come with your
smartphone.
Connect your smartphone to a computer using the cable
that comes with your smartphone.
2
1
4
① Depending on the measuring method, the dimensions and weight
might vary slightly.
② In some countries, LTE is not supported. To know if your
smartphone works with LTE networks in your country, contact
your carrier.
Type: CMOS
Pixels: 13 megapixels (back) + 8 megapixels (front)
Processor: Qualcomm 8916
,
quad-core
,
1.2 GHz
Size: 5.0 inches
Resolution: 1280 × 720 pixels
Model: Lenovo S90-A
Bluetooth 4.0; WLAN 802.11 b/g/n;
②FDD-LTE/WCDMA/GSM; GPS
Battery: 2300 mAh
Height: 146 mm (5.75 inches)
Depth: 6.9 mm (0.27 inch)
Model and system
Display
Battery
Processor
①Dimensions and weight
Camera
Wireless communication
Technical specifications
System: Android
Width: 71.7 mm (2.82 inches)
Weight: 129 g (0.28 lb)
Screen: multi-touch
LCD type: S-AMOLED
5
Important regulatory, safety, and handling
information
This section contains important regulatory, safety, and handling
information for Lenovo smartphones. Additional safety and handling
information is provided in the User Guide. See the “Accessing your
User Guide” section for details.
Read rst — regulatory information
Be sure to read the Regulatory Notice for your country or region
before using the wireless devices contained in your Lenovo Mobile
Phone. To obtain a PDF version of the Regulatory Notice, see the
“Downloading publications” section.
Plastic bag notice
DANGER: Plastic bags can be dangerous. Keep plastic bags away
from babies and children to avoid danger of suffocation.
General battery notice
Batteries supplied by Lenovo for use with your product have been
tested for compatibility and should only be replaced with approved
parts. Risk of explosion if the battery is replaced with an incorrect
type. Dispose of used batteries according to the instructions.
Rechargeable battery notice
CAUTION: Risk of explosion if the battery is replaced with an incorrect
type.
When replacing the lithium battery, use only the same or an equivalent
type that is recommended by the manufacturer. The battery contains
lithium and can explode if not properly used, handled, or disposed of.
Dispose of used batteries according to the instructions.
Do not:
Throw or immerse into water
Heat to more than 100°C (212°F)
Repair or disassemble
Built-in rechargeable battery notice
CAUTION: Do not attempt to replace the internal rechargeable lithium
ion battery. Contact Lenovo Support for factory replacement.
6
Charging
Lenovo is not responsible for the performance or safety of products
not manufactured or approved by Lenovo. Use only approved
Lenovo ac adapters and batteries. Adapter shall be installed near the
equipment and shall be easily accessible.
Prevent hearing damage
Lenovo Phone has a headphone connector. Always use the
headphone connector for headphones (also called a headset) or
earphones.
CAUTION: Excessive sound pressure from earphones and
headphones can cause hearing loss. Adjustment of the equalizer to
maximum increases the earphone and headphone output voltage and
the sound pressure level. Therefore, to protect your hearing, adjust
the equalizer to an appropriate level.
Excessive use of headphones or earphones for a long period of time
at high volume can be dangerous if the output of the headphone or
earphone connectors do not comply with specifications of EN
50332-2.
The headphone output connector of Lenovo Phone complies with EN
50332-2 Sub clause 7. This specification limits Lenovo Phone's
maximum wide band true RMS output voltage to 150 mV. To help
protect against hearing loss, ensure that the headphones or
earphones you use also comply with EN 50332-2 (Clause 7 limits) for
a wide band characteristic voltage of 75 mV. Using headphones that
do not comply with EN 50332-2 can be dangerous due to excessive
sound pressure levels.
If Lenovo Phone came with headphones or earphones in the
package, as a set, the combination of the headphones or earphones
and Lenovo Phone already complies with the specifications of EN
50332-1. If different headphones or earphones are used, ensure that
they comply with EN 50332-1 (Clause 6.5 Limitation Values). Using
headphones that do not comply with EN 50332-1 can be dangerous
due to excessive sound pressure levels.
7
Sound pressure warning statement
For the device that is tested in accordance with EN 60950-1:
2006+A11:2009:+A1:2010+A12:2011, it is mandatory to perform
audio tests for EN50332.
This device has been tested to comply with the Sound Pressure Level
requirement in the applicable EN 50332-1 and/or EN 50332-2
standards. Permanent hearing loss may occur if earphones or
headphones are used at high volume for prolonged periods of time.
Warning statement: To prevent possible hearing damage, do not listen
at high volume levels for long periods.
Operating temperature
Use Lenovo Phone only in the temperature range of -10°C (14 °F) —
40°C (104 °F) to avoid damage.
Polyvinyl Chloride (PVC) cable and cord notice
WARNING: Handling the cord on this product or cords associated
with accessories sold with this product will expose you to lead, a
chemical known to the State of California to cause cancer, and birth
defects or other reproductive harm. Wash hands after handling.
Disposing according to local laws and regulations
When Lenovo Phone reaches the end of its useful life, do not crush,
incinerate, immerse in water, or dispose of Lenovo Phone in any
manner contrary to local laws and regulations. Some internal parts
contain substances that can explode, leak, or have an adverse
environmental effect if disposed of incorrectly. See “
Recycling and
environmental information
” for additional information.
Eurasian compliance mark
