Lenovo A319 Manuel utilisateur
English/Bahasa Indonesia
Quick Start Guide v1.0
Lenovo A319
English
Learning more
Getting support
Read this guide carefully before using your smartphone.
To learn more information about your
Lenovo smartphone and obtain the latest
smartphone manuals, go to:
http://support.lenovo.com/.
For support on network service and billing,
contact your wireless network operator.
For instructions on how to use your
device, go to:
http://support.lenovo.com/.
Legal notices Lenovo and the Lenovo logo are
trademarks of Lenovo in the United States,
other countries, or both.
Other company, product, or service names
may be trademarks or service marks of
others.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
Type: CMOS
Pixels: 5.0 megapixels (back) + 2.0 megapixels (front)
Processor: MTK MT6572
,
Dual Core
,
1.3GHz
Size: 4.0 inches Screen: 2-touch
Resolution: 800 × 480 pixels LCD type: TN
Model: Lenovo A319 System: Android
Bluetooth 4.0; WLAN 802.11 b/g/n; WCDMA, GSM; GPS
Battery: 1500 mAh
Height: 123.5 mm (4.862 inches) Width: 63.8 mm (2.512 inches)
Depth: 10.2 mm (0.406 inch) Weight: 129 g (0.284 lb)
Model and system
① Depending on the measuring method, the dimensions and weight
might vary slightly.
Display
Battery
Processor
①Dimensions and weight
Camera
Wireless Communication
Technical specifications
Microphone
Flashlight
Micro USB
connector
Speaker
On/Off button
Volume buttons
Receiver
1
4
7
10
2
5
8
3
6
9
Front-facing
camera
Rear-facing
camera
Headset
connector
6
5
7
8
9
10
2
3
4
1
First glance
You must insert the SIM card provided by your carrier to use cellular
services. Set up your smartphone as shown.
Step 1. Open the back cover.
Step 2. Insert the SIM cards and
the memory card.
Tip: Insert the (U)SIM card into
SIM1 slot and SIM card
into SIM2 slot.
Step 3. Install the battery.
a. Align the battery
connectors on the battery
with the pins in the
battery compartment.
b. Push the battery down
into place.
Step 4. Install the back cover.
Always turn off your smartphone first before you insert or remove a
SIM card. Insert or remove a SIM card with your smartphone on may
damage your SIM card or smartphone permanently.
SIM1
SIM2
SIM1
SIM2
Preparing your smartphone
Turning on or turning off your smartphone
Turn on: Press and hold the On/Off button until
the Lenovo logo appears.
Turn off: Press and hold the On/Off button for a
few seconds, then tap Power off．
Your smartphone has a rechargeable battery. For more information
about battery safety, see the “Rechargeable battery notice” in the
Important Product Information Guide shipped with your smartphone.
Low battery power Fully charged Charging
Charge the battery as shown.
Method 1.
Method 2.
Connect your smartphone to a power outlet using the
cable and USB power adapter that come with your
smartphone.
Connect your smartphone to a computer using the cable
that comes with your smartphone.
2
1
Charging the battery
Pelajari lebih lanjut Untuk mengetahui informasi
selengkapnya tentang ponsel cerdas
Lenovo dan mendapatkan panduan
ponsel cerdas terbaru, kunjungi:
http://support.lenovo.com/.
Untuk dukungan penagihan dan
layanan jaringan, hubungi operator
jaringan nirkabel Anda. Untuk petunjuk
cara menggunakan perangkat Anda,
kunjungi: http://support.lenovo.com/.
Lenovo dan logo Lenovo adalah merek
dagang dari Lenovo di Indonesia, negara
lain, atau keduanya.
Perusahaan, produk, atau nama layanan
lainnya mungkin merek dagang atau
merek layanan dari pihak lain.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
Bahasa Indonesia
Baca panduan ini dengan saksama sebelum menggunakan
ponsel cerdas.
Mendapatkan
dukungan
Pemberitahuan
hukum
Jenis: CMOS
Piksel: 5,0 megapiksel (belakang) + 2,0 megapiksel (depan)
Prosesor: MTK MT6572, Dual Core, 1,3 GHz
Ukuran: 4,0 inci Layar: 2-sentuh
Resolusi: 800 × 480 piksel Tipe LCD: TN
Model: Lenovo A319 Sistem: Android
Bluetooth 4.0; WLAN 802.11 b/g/n; WCDMA, GSM; GPS
Baterai: 1500 mAh
Tinggi: 123,5 mm (4,862 inci) Lebar: 63,8 mm (2,512 inci)
Tebal: 10,2 mm (0,406 inci) Bobot: 129 g (0,284 lb)
Model dan sistem
Tergantung pada metode pengukuran, ukuran dan berat mungkin
sedikit berbeda.
Display
Baterai
Prosesor
Ukuran dan berat
Kamera
Komunikasi Nirkabel
Spesifikasi teknis
Tampilan sekilas
Speaker
Konektor
headset
Tombol
Nyala/Mati
Konektor USB
Mikro
Tombol
Volume
Kamera depan
1
4
7
10
2
5
8
3
6
9
Kamera belakang
Unit penerima
Senter
Mikrofon
6
5
7
8
9
10
2
3
4
1
Langkah 1. Buka penutup belakang.
Langkah 2. Masukkan kartu SIM
dan kartu memori.
Saran: Masukkan kartu (U)SIM
ke slot SIM1 dan kartu
SIM ke slot SIM2.
Langkah 3. Pasang baterai.
a. Sejajarkan konektor
baterai pada baterai
dengan pin di ruang
baterai.
b. Tekan baterai masuk ke
tempatnya.
Langkah 4. Pasang penutup
belakang.
Untuk menggunakan layanan seluler, pasang kartu SIM yang
disediakan oleh operator seluler Anda. Siapkan ponsel cerdas Anda
seperti yang ditunjukkan.
Selalu matikan ponsel cerdas Anda lebih dulu sebelum Anda
memasukkan atau melepaskan kartu SIM. Memasukkan atau
melepaskan kartu SIM dengan ponsel cerdas masih menyala dapat
merusak kartu SIM atau ponsel cerdas Anda secara permanen.
Menyiapkan ponsel cerdas
SIM1
SIM2
SIM1
SIM2
