INSTALLATION MANUAL

Ref : BALTIC_Installation-IOM-0412-E

TABLE OF CONTENTS

INSTALLATION MANUAL

Safety codes & regulations

TRANSPORT & HANDLING

Mandatory handling devices

LIFTING THE UNITS

Machine dimensions and weights

Minimum clearance around the unit installation

Fork lifting the unit

Removing the forklift protection located under the machine

Lifting the unit with a crane

Lifting the roof curbs

DELIVERY CHECKS

Rating plate

Storage

Maintenance key

Condensate drains

Preliminary checks

Installation requirements

Connections

INSTALLATION ON A ROOF MOUNTING FRAME

Roof opening dimensions

Sealing checks

Leveling adjustable roofcurbs

Positioning the rooftop on adjustable roofcurbs

NON ADJUSTABLE NON ASSEMBLED ROOFCURB INSTALLATION

Frame parts packing

Installation

Assembly

Securing the frame

Sealing checks

CURBING AND FLASHING

HEAT RECOVERY GENERAL DESCRIPTION

PLATE HEAT RECOVERY CONFIGURATIONS

PLATE HEAT RECOVERY INSTALLATION

THERMODYNAMIC HEAT RECOVERY CONFIGURATIONS

THERMODYNAMIC HEAT RECOVERY - SERVICE MANUAL

THERMODYNAMIC HEAT RECOVERY - CONTROL MANUAL

• 2 •

BAC 024 SNM 3M 23,4 - -

BAC 030 SNM 3M 29,2 - -

BAC 038 SNM 3M 37,1 - -

BAC 042 SNM 3M 39,4 - -

BAC 045 DNM 3M 43,9 - -

BAC 052 DNM 3M 49,8 - -

BAC 057 DNM 3M 55,2 - -

BAC 065 DNM 3M 62,6 - -

BAC 075 DNM 3M 74,1 - -

BAC 085 DNM 3M 80,7 - -

BAH 024 SNM 3M 23,4 20,7 -

BAH 030 SNM 3M 29,2 26,2 -

BAH 038 SNM 3M 37,1 34,8 -

BAH 042 SNM 3M 39,4 38,0 -

BAH 045 DNM 3M 43,9 40,8 -

BAH 052 DNM 3M 49,8 46,2 -

BAH 057 DNM 3M 55,2 54,4 -

BAH 065 DNM 3M 62,6 62,2 -

BAH 075 DNM 3M 74,1 73,5 -

BAH 085 DNM 3M 80,7 80,1 -

BAG 024 SSM 3M 23,3 - 20

BAG 030 SSM 3M 28,9 - 20

BAG 038 SSM 3M 36,8 - 20

BAG 042 SSM 3M 39,1 - 20

BAG 045 DSM 3M 43,7 - 33

BAG 052 DSM 3M 49,5 - 33

BAG 057 DSM 3M 54,7 - 33

BAG 065 DSM 3M 61,9 - 33

BAG 075 DSM 3M 73,4 - 60

BAG 085 DSM 3M 79,8 - 60

BAG 024 SHM 3M 23,3 - 46

BAG 030 SHM 3M 28,9 - 46

BAG 038 SHM 3M 36,8 - 46

BAG 042 SHM 3M 39,1 - 46

BAG 045 DHM 3M 43,7 - 60

BAG 052 DHM 3M 49,5 - 60

BAG 057 DHM 3M 54,7 - 60

BAG 065 DHM 3M 61,9 - 60

BAG 075 DHM 3M 73,4 - 120

BAG 085 DHM 3M 79,8 - 120

BAM 024 SSM 3M 23,3 20,8 20

BAM 030 SSM 3M 28,9 26,5 20

BAM 038 SSM 3M 36,8 35,1 20

BAM 042 SSM 3M 39,1 38,4 20

BAM 045 DSM 3M 43,7 41,0 33

BAM 052 DSM 3M 49,5 46,6 33

BAM 057 DSM 3M 54,7 54,9 33

BAM 065 DSM 3M 61,9 62,8 33

BAM 075 DSM 3M 73,4 74,2 60

BAM 085 DSM 3M 79,8 81,0 60

BAM 024 SHM 3M 23,3 20,8 46

BAM 030 SHM 3M 28,9 26,5 46

BAM 038 SHM 3M 36,8 35,1 46

BAM 042 SHM 3M 39,1 38,4 46

BAM 045 DHM 3M 43,7 41,0 60

BAM 052 DHM 3M 49,5 46,6 60

BAM 057 DHM 3M 54,7 54,9 60

BAM 065 DHM 3M 61,9 62,8 60

BAM 075 DHM 3M 73,4 74,2 120

BAM 085 DHM 3M 79,8 81,0 120

BALTIC-IOM-0412-E / Installation manual

INSTALLATION MANUAL

The present manual applies to the following rooftop versions

Item Net cooling capacity

(kW - Eurovent conditions)

Heating capacity

(kW - Eurovent conditions)

HeatPump

Heating capacity

(KW) GAS

COOLING ONLY

HEAT PUMP

GAS ONLY - STD HEAT

GAS ONLY - HIGH HEAT

DUAL FUEL - STD

DUAL FUEL - HIGH

• 3 •BALTIC-IOM-0412-E / Installation manual

INSTALLATION MANUAL

Safety codes & regulations

THE UNIT MUST BE INSTALLED IN ACCORDANCE WITH LOCAL SAFETY CODES AND REGULATIONS AND CAN ONLY BE

USED IN WELL VENTILLATED AREA.

PLEASE READ CAREFULLY THE MANUFACTURER’S INSTRUCTIONS BEFORE STARTING THIS UNIT.

INSPECTIONS AND REQUALIFICATION ACCORDING PRESSURE EQUIPMENT DIRECTIVE MUST FOLLOW THE LOCAL

REGULATIONS WHERE THE UNIT IS INSTALLED.

Important note for unit ﬁtted with gas burner:

The following note must be followed carefully

THIS MANUAL IS ONLY VALID FOR UNITS DISPLAYING THE FOLLOWING CODES:

GB IR GR DA NO FI IS

In case these symbols are not displayed on the unit, please refer to the technical documentation which will eventually detail any

modiﬁcations required to the installation of the unit in a particular country.

• If machine is including gas burner, minimum clearance around the unit must be at least 8 m to allow a proper gas ﬂue dilution. If

not possible, the fresh air intake must be ducted at least 8 m away from the gas burner exhaust.

• The gas burner air intake and exhaust chimney must not be modiﬁed or ducted.

• Before commissioning this type of unit, it’s mandatory to ensure that the gas distribution system is compatible with the adjustments

and settings of the unit.

• Gas module can only be used for outdoor installations.

• Any work on gas module must be carried out by qualiﬁed engineer.

All units are compliant with the PED directive 97-23/CE

All the technical and technological information contained in this manual, including any drawing and technical descriptions provided

by us, remain the property of LENNOX and must not be utilised (except in operation of this product),reproduced, issued to or made

available to third parties without the prior written agreement of LENNOX. The technical information and speciﬁcations contained in

this manual are for reference only. The manufacturer reserves the right to modify these without warning and without obligation to

modify equipment already sold.

All work on the unit must be carried out by a qualiﬁed and authorised employee.

Non-compliance with the following instructions may result in injury or serious accidents.

Work on the unit:

• The unit shall be isolated from the electrical supply by disconnection and locking using the main isolating switch.

• Workers shall wear the appropriate personal protective equipment (helmet, gloves, glasses, etc.).

Work on the electrical system:

• Work on electric components shall be performed with the power off (see below) by employees having valid electrical qualiﬁcation

and authorisation.

Work on the refrigerating circuit(s):

• Monitoring of the pressures, draining and ﬁlling of the system under pressure shall be carried out using connections provided for

this purpose and suitable equipment.

• To prevent the risk of explosion due to spraying of coolant and oil, the relevant circuit shall be drained and at zero pressure before

any disassembly or unbrazing of the refrigerating parts takes place.

• There is a residual risk of pressure build-up by degassing the oil or by heating the exchangers after the circuit has been drained.

Zero pressure shall be maintained by venting the drain connection to the atmosphere on the low pressure side.

• 4 • BALTIC-IOM-0412-E / Installation manual

INSTALLATION MANUAL

• The brazing shall be carried out by a qualiﬁed brazier. The brazing shall comply with standard NF EN1044 (minimum 30% silver).

EMC DIRECTIVE COMPLIANCE

WARNING:

This equipment is an “A class“ according CEM Directive. In an industrial environment, this device can create radio electrical noise. In

this case, the owner can be asked to take appropriated actions.

This applies to all machine installed with nominal amps below <75A:

• The short-circuit rate Rsce=33 is deﬁned in the EN61000-3-12 standard relative to the harmonics readings on the supply network.

The appliances compliant with the harmonic current limits equivalent to Rsce=33 can be connected in whatever connection point

of the main supply system.

• The maximal allowable impedance of the main supply system Zmax=0.051W is deﬁned by EN 61000-3-11 standard relative to

the voltage variation, ﬂuctuation and ﬂicker readings. The connection to the supply is a conditional connection submitted to the

preliminary agreement of the power supply local provider.

Replacing components:

• In order to maintain CE marking compliance, replacement of components shall be carried out using spare parts, or using parts

approved by LENNOX.

• Only the coolant shown on the manufacturer’s nameplate shall be used, to the exclusion of all other products (mix of coolants,

hydrocarbons, etc.).

CAUTION:

In the event of ﬁre, refrigerating circuits can cause an explosion and spray coolant gas and oil.

Transport – Handling- Access:

• Never lift the unit without forklift protections

• An approach ramp must be installed if the unit’s installation requirements tell that it's necessary to reach the main switch, the electrical

cabinet, the compressor and the ventilation compartment. This recommendation is valid for all type of installations.

• It is strictly forbidden to walk or store equipment or material on top of the rooftop unit

Rooftop installation in heavy wind locations

• The roofcurbs (vertical & horizontal) and rooftops installations are designed to withstand winds up to 80 km/h. Above this limit, it’s

recommended to take appropriate actions to secure the installation.

• Ensure the fresh air inlet does not face prevailing wind direction.

Elbow or section changes in ductworks next to the rooftop

• Whatever the supply conﬁguration is, respect a minimal duct’s length of 2 m before any elbow or any duct’s section change.

• Directional vanes must be ﬁtted inside any elbow ﬁtted in return or supply ductwork closer than 5 meter to the machine connection

ﬂanges.

Filters:

• Do the ﬁlters ﬁre classiﬁcation’s choice according to local regulations.

Fan compartment:

• Stop the power before accessing the fan compartment.

Gas:

• Any work on gas module must be carried out by qualiﬁed personnel

• A unit with gas module must be installed in accordance with local safety codes and regulations and can only be used for outdoor

installation.

The technical information and speciﬁcations contained in this manual are for reference only. The manufacturer reserves the right to

modify these without warning and without obligation to modify equipment already sold.

• 5 •BALTIC-IOM-0412-E / Installation manual

TRANSPORT & HANDLING

Mandatory handling devices

MANDATORY HANDLING DEVICES

Handling slings to guide the unit toward

the roof curb

Vacuum lifting beam to position the unit

COMPLIANT NON-COMPLIANT

• 6 •

2283+/-15 2250+/-15 1240+/-15 2683+/-20 2310 2309 1240

2783+/-15 2250+/-15 1240+/-15 2683+/-20 2810 2309 1240

3663+/-15 2250+/-15 1240+/-15 2683+/-20 3690 2309 1240

24 30 38 42 45 52 57 65 75 85

696 711 726 726 937 952 967 982 1150 1150

701 716 731 731 947 962 977 992 1165 1165

739 754 769 769 970 985 1000 1015 1225 1225

758 773 788 788 992 1007 1022 1037 1285 1285

744 759 774 774 980 995 1010 1025 1235 1235

763 778 793 793 1002 1017 1032 1047 1295 1295

-12,1 -12,1 -12,1 -12,1 -18,9 -18,9 -18,9 -18,9 -23,2 -23,2

-7 -7 -7 -7 -10,3 -10,3 -10,3 -10,3 -13,6 -13,6

-5,1 -5,1 -5,1 -5,1 -8,6 -8,6 -8,6 -8,6 -9,6 -9,6

0,9 0,9 0,9 0,9 1,8 1,8 1,8 1,8 2,5 2,5

11,2 11,2 11,2 11,2 20,8 20,8 20,8 20,8 30,3 30,3

22,8 22,8 22,8 22,8 30,9 30,9 30,9 30,9 39 39

3 3 3 3 4,5 4,5 4,5 4,5 6 6

14 14 14 14 21,5 21,5 21,5 21,5 31,2 31,2

20,8 20,8 20,8 20,8 26,7 26,7 26,7 26,7 26,7 26,7

25,4 25,4 25,4 25,4 32,5 32,5 32,5 32,5 32,5 32,5

37,4 37,4 37,4 37,4 45 45 45 45 62,3 62,3

49,6 49,6 49,6 49,6 67,5 67,5 67,5 67,5 92,9 92,9

36,2 36,2 36,2 36,2 54,9 54,9 54,9 54,9 86,4 86,4

20,9 20,9 20,9 20,9 28,4 28,4 28,4 28,4 35,9 35,9

65 65 65 65 70 70 70 70 87 87

139 139 139 139 156 156 156 156 195 195

272 272 272 272 295 295 295 295 440 440

218 218 218 218 241 241 241 241 358 358

174 174 174 174 209 209 209 209 239 239

BALTIC-IOM-0412-E / Installation manual

LIFTING THE UNITS

Machine dimensions and weights

Machine Length Width Height Width with

hood Transport

lenght Transport

Width Transport

Height

Cbox

Dbox

Ebox

Unit

Base weight (kg)

Cooling

HeatPump

Gas S

Gas H

Dual S

Dual H

Option weight (kg)

Horizontal return & supply

Horizontal return & vertical supply

Vertical return & horinzontal supply

Gravity exhaust damper

Power exhaust fan

F7 ﬁlter

F4 ﬁlter

Double skin

Electrical heater S

Electrical heater H

Electrical preheater S

Electrical preheater H

Hot water coil

Energy recovery coil

Accessorie weight (kg)

Non ajustable roofcurb

Ajustable roofcurb

Extraction curb vertical

Extraction curb horizontal

Multidirectional curb

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Lennox Climatiseur

Lennox

Lennox 4 Series Manuel utilisateur

Lennox

Lennox 2SCU13-18 Manuel utilisateur

Lennox

Lennox Elite ELXC Series Manuel utilisateur

Lennox

Lennox LI012CO-230P432 Manuel utilisateur

Lennox

Lennox e-Baltic D BOX 55 Manuel utilisateur

Lennox

Lennox EL296UH045XV36B Manuel utilisateur

Lennox

Lennox LM012CI-120V432-X Manuel utilisateur

Lennox

Lennox SGH036 Manuel utilisateur

Lennox

Lennox CU12M Series Manuel utilisateur

Lennox

Lennox LM018CI-100P432-1 Manuel utilisateur

Lennox

Lennox LI009CO-160T432 Manuel utilisateur

Lennox

Lennox VRF VE8K007C432P Manuel utilisateur

Lennox

Lennox LICH4024180P431-C Manuel utilisateur

Lennox

Lennox SWING Manuel utilisateur

Lennox

Lennox Merit 13ACD-018 Manuel utilisateur

Lennox

Lennox Humiditrol L Series Manuel utilisateur

Lennox

Lennox LI009HI-160T432 Manuel utilisateur

Lennox

Lennox WING Guide de l'utilisateur

Lennox

Lennox MCFA Manuel utilisateur

Lennox

Lennox T?CLASS TPA024S4 Manuel d'installation et d'exploitation

Lennox

Lennox 2SCU13 Series Manuel utilisateur

Lennox

Lennox GCM Series Manuel utilisateur

Lennox

Lennox LM018CI-115P432-1X Manuel utilisateur

Lennox

Lennox CBX25UH-018 Manuel

Manuels Climatiseur populaires d'autres marques

Spheros

Spheros CC 355 Manuel utilisateur

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuel utilisateur

Panasonic

Panasonic CS-E12HKEW Manuel utilisateur

nedis

nedis ACMB1WT7 Manuel utilisateur

Samsung

Samsung AR KV Series Mode d’emploi

Daikin

Daikin FCFV50A Manuel utilisateur

Fujitsu

Fujitsu Inverter ASBA30JFC Manuel utilisateur

Toshiba

Toshiba RAS-M10SMUV-E Manuel utilisateur

Daikin

Daikin FXLQ20MAVE Manuel utilisateur

Hitachi

Hitachi RAS-E24CAK Manuel utilisateur

CIAT

CIAT Magister 2 Series Mode d’emploi

Bestron

Bestron AAC6000 Manuel utilisateur

Hisense

Hisense 7K Manuel technique

Frigidaire

Frigidaire FFRE0533S1E0 Manuel utilisateur

Samsung

Samsung AS09HM3N Manuel utilisateur

Frigidaire

Frigidaire CRA073PU11 Manuel du propriétaire

Soleus Air

Soleus Air GB-PAC-08E4 Manuel utilisateur

McQuay

McQuay MCK020A Manuel utilisateur
