LEEDS WORLD 1670-82 Mode d’emploi
Desktop Digital Photo Frame Start Guide
1670-82
Before Using, Charge the Photo Frame
This digital photo frame has a built-in battery.
Plug the USB power cord into a PC and into the
frame.
The digital photo frame will begin to charge.
It takes about two hours to fully charge the
battery, which should provide
three hours of play time.
NOTE: Completely charge
the battery before use.
Do not let the frame stay
connected to a power
source for more than 12
hours or it may overheat.
To get the longest life from
the battery, it should be
completely emptied and
fully charged for the rst
three charge cycles.
Contents: Connect the Display Stand:
BACK VIEW
Controls and Connections:
2Install Disc
3Photo Frame
4USB Power Cord
1User Manual
Charge the Leed’s Photo Frame
Previous
Next
Mini-USB Jack
For transferring images
and powering the frame
Reset
Insert a straightened paper clip
if frame becomes unresponsive
Mode
Hold for three seconds to turn on
or off, click quickly to turn on/off
auto play of pictures
The Leed’s Pocket digital photo frame comes with a stand
that can be used to orient the frame in either the portrait
or landscape orientation.
The stand is kept under the
front panel in the screen. To
access it, press the tab in and
release the LCD from the front
panel.
Press where indicated to pop up the stand,
and remove it from the LCD.
Place the front panel
back in place.
In the back of the LCD,
screw the stand into
one of the slots.
©2009 LEEDSWORLD
Proprietary information contained in this document is the sole property of Leedsworld.
Any reproduction in part or as a whole without written permission of Leedsworld is prohibited.
Rear view,
stand installed.
Landscape
Portrait
Desktop Digital Photo Frame Start Guide
1670-82
Using the supplied USB
cable, connect the frame
and computer.
Requires Microsoft Windows™ (not Mac compatible).
The supplied disc contains an installer for the
software needed to transfer photos
from a computer to the photo frame.
Explore the CD Drive and double-
click on the SETUP le.
NOTE: If you have a slot-loading CD tray, you cannot use the
supplied disc; it will jam in the drive.
Upon opening the Setup le, the installer loads.
Follow the onscreen
prompts to complete the
installation.
A desktop icon is installed.
Note: The photo frame must be
connected for the software to start.
Eject the frame properly to avoid damaging
the internal memory.
Press the close button
to exit Photo Viewer.
Click “Yes” to conrm closing the program.
Eject the drive from Windows™ by clicking
the icon in the task bar:
Click “Safely Remove USB Mass Storage
Device,” unplug the USB cable, and enjoy
the digital photo frame!
Install Photo Viewer Software
Install Photo Frame Drivers
Transferring Photos from the Computer to the Frame
©2009 LEEDSWORLD
Proprietary information contained in this document is the sole property of Leedsworld.
Any reproduction in part or as a whole without written permission of Leedsworld is prohibited.
Drivers install the rst time the
frame is connected to a computer.
It may take a few moments for
this process to complete.
1
34
Eject the FrameSync to the Frame
910 11
5
2
Click the blue arrow button to
move the image to “Device” panel
for synchronization with the frame.
NOTE: It is not yet sent to the
frame, but simply staged for
synchronization.
Once all of the images
are ready in the staging
area to transfer to
the frame, click the
“Synchronize” button.
A prompt to connect
the frame to the
computer appears.
Click MODE once,
and a few seconds
later, the screen will
display “Download.”
Connect?
Download
6
Once all drivers load,
launch the program
using the shortcut
that was installed
on the computer
desktop.
8
Reset the crop area
(move with mouse)
Clear the crop area
Rotate counterclockwise
Rotate image clockwise
Add image to the album
Browse for images
in folders located on
your hard drive.
The image tools are
described below.
General Functionality:
7
Sync with frame
Image preview
and edit area
Hard Drive Browser Device Window
