LAUNDRY JET Return Manuel utilisateur

+1.800.867.4580 [email protected] www.laundryjet.com

INSTALLATION GUIDE

Laundry Jet Return

September 2021

Version 1.0 Revision 0.1

Rev 4 Return Units for use with ISense & ISlide

Laundry Jet

2001 Challenger Avenue

Oroville, CA 95965

+1.800.867.4580 [email protected] www.laundryjet.com

INSTALLATION GUIDE

+1.800.867.4580 [email protected] www.laundryjet.com

INSTALLATION GUIDE

Document Revisions

Date

Version

Number

Document Changes

9/17/2021

1.0 Rev 0.1

Laundry Jet Installation Guide Rev 1

+1.800.867.4580 [email protected] www.laundryjet.com

INSTALLATION GUIDE

Table of Contents

1 Introduction 5

2 Piping & Airflow 6

3 Contents 7

4 Pipe Installation Overview 8-12

4 - Components & Tools 8

4.1 - Pipe Installation Standards 9

4.2 - Port Drop Installation 10

4.3 - Port 90 Installation 11

4.4 - Return Unit Pipe Drop 12

5 Return Unit Installation 13-14

5 - Components & Tools 13

5.1 - Return Unit Installation 14

6 Warranty 15

+1.800.867.4580 [email protected] www.laundryjet.com

Introduction

1Introduction

The Laundry Jet installation is comprised of four elements:

▪Laundry Jet Ports mounted in bedrooms, dressing rooms or bathrooms

▪The laundry room Wall mounted or Cabinet Mount Vacuum Unit

▪The PVC pipe and fittings that connect the ports to the laundry room through the attic

space

▪Laundry Jet Return Unit

Vacuum Laundry Pipe

Laundry Jet specifies 6" SDR35 White Solvent Weld PVC pipe and fittings. This piping is light

weight to make install quick and easy.

PVC piping is designed to have a smooth transition in between fittings and connections which

ensures that clothing, bedding and towels will travel smoothly to the laundry room.

Pipe & Fittings

6" SDR35 White Solvent Weld PVC pipe 10′ x 6”

All Fittings are 6" SDR35 White Solvent Weld

+1.800.867.4580 [email protected] www.laundryjet.com

Piping & Airflow

2Piping & Airflow

Laundry Jet Return Unit Piping and Airflow

▪The Return Unit has no power, and is used as an "interceptor".

▪It is connected into the pipe network as illustrated above.

▪The top right hand entry of the Return Unit connects via pipe to a dedicated port in the

laundry room.

▪The top left hand entry of the Return Unit connects the suction airflow of the main pipe run.

▪The red arrows in the illustration above show the airflow throughout the system.

+1.800.867.4580 [email protected] www.laundryjet.com

Contents

3Contents

Laundry Jet Return Unit Hardware Kit

Pipe Components

All Fittings are 6" SDR35 White Solvent Weld

6 Inch Wye 6 Inch 45° Elbow 6 Inch Coupler 6 Inch Cleanout

6 Inch Swept 90°

+1.800.867.4580 [email protected] www.laundryjet.com

Components & Tools

4Pipe Installation Overview

Components

Port 90 Assembly 6 Inch Wye 6 Inch Cleanout Adapter

6 Inch 45° Elbow Cable Bundle

Tools

Cordless Drill Sawzall Tape Measure

Clear 2 Part PVC Glue 1" Wood Screw Plumber's Metal Strapping Tape

+1.800.867.4580 [email protected] www.laundryjet.com

Pipe Installation Standards

4.1 Pipe Installation Overview

Pipe Installation Standards

Required Piping Installation Standards

▪All joints must use a minimum entry angle of 45 degrees with a break distance of 18 Inches

(460 MM). See Image below.

▪Pipe cuts must be straight and de burred before seating.

▪Pipe must be completely seated in fitting connections.

▪Seal all joints using standard PVC glue.

Connections must be glued around 360 degrees

to ensure maximum system performance.

▪System must be strapped with “plumbers tape”

(or equivalent) every 6 feet. Port 90 must be

strapped and secured prior to Port installation.

▪Install Cleanout ports every 50 feet on angled runs. Straight trunk lines can run up to 100

feet with cleanouts at either end.

+1.800.867.4580 [email protected] www.laundryjet.com

Port Drop Installation

4.2 Pipe Installation Overview

Port Drop Installation

▪Mount port 90 using the Port 90 Mount Bracket. See Page 11 for Port 90 Installation. Use a

standard SDR 6" Swept 90 for your Port Drop Installation. Block and strap drop line at

midway point
