Launch STS600 Manuel utilisateur

User sManual

English

STS600 SensorTester&Simulator

User sManual

LAUNCH STS600

E-i

TrademarkInformation

LAUNCH isaregistered trademarkofLAUNCH TECH.CO.,

LTD.(shortforLAUNCH)inChina and othercountries.All

otherLAUNCHtrademarks,servicemarks,domainnames,

logos,and companynamesreferred tointhismanualare

eithertrademarks,registered trademarks,servicemarks,

domainnames,logos,companynamesoforareotherwise

the propertyofLAUNCH oritsaffiliates.Incountrieswhere

anyoftheLAUNCHtrademarks,servicemarks,domain

names,logosand companynamesarenotregistered,

LAUNCHclaimsotherrightsassociated withunregistered

trademarks,servicemarks,domainnames,logos,and

companynames.Otherproductsorcompanynames

referred tointhismanualmaybetrademarks oftheir

respectiveowners.You maynotuseanytrademark,service

mark, domainname, logo, orcompanynameofLAUNCHor

anythirdpartywithoutpermissionfromthe ownerofthe

applicabletrademark,servicemark,domainname,logo,or

companyname.You maycontactLAUNCHbyvisiting

Launchat http://www.cnlaunch.com,orwritingtoLAUNCH,

XinyangBuilding,Bagua 4thRoad,Shenzhen,Guangdong

Province,P.R.C.,torequestwrittenpermission touse

Materialsonthismanualforpurposesorforall other

questionsrelatingtothismanual.

CopyrightInformation

reserved.Nopartofthispublicationmaybereproduced,

stored inaretrievalsystem,ortransmitted inanyformorby

anymeans, electronic,mechanical,photocopying,recording

orotherwise,withoutthepriorwritten permission of

LAUNCH.Theinformation contained hereinisdesigned

onlyforthe useofthisunit. LAUNCHisnotresponsiblefor

anyuseof thisinformation asapplied tootherunits.

LAUNCH STS600

E-ii

NeitherLAUNCHnoritsaffiliatesshallbeliabletothe

purchaserofthisunitorthirdpartiesfordamages,losses,

costs,orexpensesincurredbypurchaserorthirdpartiesas

aresultof: accident,misuse,orabuseofthisunit,or

unauthorized modifications,repairs,oralterationstothis

unit,orfailuretostrictlycomplywithLAUNCHoperatingand

maintenanceinstructions.

LAUNCH shall notbeliableforanydamagesorproblems

arisingfromthe useofanyoptionsoranyconsumable

productsotherthanthosedesignatedasOriginalLAUNCH

ProductsorProductsApproved byLAUNCH.

General Notice

Otherproductnamesused hereinareforidentification

purposesonlyand maybetrademarks oftheirrespective

owners.LAUNCH disclaimsanyand all rightsinthose

marks.

Disclaimer

lTotakefulladvantageof the unit, you shouldbefamiliar

withthe engine.

lAllinformation,illustrations, and specificationscontained

inthismanualarebased on thelatestinformation

availableatthe timeofpublication.The rightisreserved

tomakechange atanytimewithout notice.

LAUNCH STS600

E-1

TableofContents

1. CAUTION.........................................................................E-2

2. GENERAL........................................................................E-2

3. MAJORFUNCTIONS.......................................................E-3

4. STRUCTURE...................................................................E-4

5. OPERATIONINSTRUCTION............................................E-5

5.1NOTES.......................................................................E-5

5.2POWER......................................................................E-6

5.3SCREEN.....................................................................E-6

5.4KEYBOARDOPERATION...........................................E-7

5.5VOLTAGEMEASUREMENT........................................E-9

5.6RESISTANCE MEASUREMENT................................E-10

5.7FREQUENCYMEASUREMENT................................E-12

5.8FREQUENCYSIMULATION......................................E-14

5.9ΛO2SENSORSIMULATION.......................................E-17

5.10 VOLTAGESIMULATION..........................................E-19

6. FAQ...............................................................................E-21

LAUNCH STS600

E-2

1. CAUTION

1.1Pleaseread thismanualcarefullybeforeoperationin

ordertoavoiddamagingthe instrument duetoimproper

use.

1.2Afterunpacking,pleasecheckthe itemsagainstthe

enclosedpackinglist.

1.3Ifthereisanyqualityproblemwiththisunitduringone

yearwarranty(startingfromthe dateofthe invoice),

pleasecontactthe nearestdistributororLAUNCH free

servicewillbe offered ifsuchaproblemisnotresulting

fromunauthorizedservice.

2. GENERAL

Thismanualprovidesdetailed informationaboutthe

functionsand operation of STS600.

STS600,withfunctionsofself-testand

automatic-range-selection,isatypeofintelligentinstrument,

mainlyused fortestingworkingconditionsofautosensors

bymeansofmeasuringvoltage,resistanceandfrequency.

It can alsosimulatesensorstogenerateoutputsignals

(voltage,frequencyand the sign of λO2

sensor).

LAUNCH STS600

E-3

3. MAJORFEATURES

1)BigcharacterLCD,3-digitaldisplayofmeasure,

maximumand minimumalongwithunitindication and

iconsfortestfunctions

2)Anti-dirtfilmkeyboard

3)Automaticrangeselectionforvoltageand resistance

measure

4)Measureprecision lessthan 1%FSR

5)Responsetime<1S

6)Voltage scope：0～400V

7)Resistancescope：0～4MQ

8)Frequencyscope：1～15KHz

9)Voltage simulation scope：0～12V

10)Frequencysimulation scope：1～15KHz （5V/12V

amplitude changeable）

11)Power：12VDC(autobattery)

12)Ambienttemperature：-5℃～+50℃

13)Ambienthumidity：0%RH～85%RH

14)Quiescentpowercurrent：≤70mA

15)Volume：320X166X40 mm

16)Weight：486g

LAUNCH STS600

E-4

4. STRUCTURE

Fig.1STS600

①Displaywindow;②Keyboard;③Powercable;④Measure

plug;⑤Powerplug;⑥Test cable.

The instrumentmainlyconsistsoftwoparts:the meterand

the externalcables.The externalcablesaresignalcables

LAUNCH STS600

E-5

（⑥ of Fig.1）andpowercable（③ ofFig.1）.Thesignal

cablescan beconnectedtothe meterthroughaDB9plug.

The powercableislinked tothe meterbya2-pinplug.

The instrumentfrontsurfaceisdividedintotwoparts:LCD

displaywindowonthe upperpart （① ofFig.1）and

keyboardon thelowerpart（② ofFig.1）.

5. OPERATIONINSTRUCTION

5.1NOTES

Therearetwosocketsonthe topoftheinstrumentasrefer

toFig.1.The rightone isforsignalcables theleft one is

forpowercable.You shouldfirstlyinsertthe signalcable

and powercableintotwosocketsrespectivelywhenusing.

The powercablehasone black jawfornegativepoleof

batteryandone redjawforpositivepoleofbattery.There

aretwocolors:the blackforsignalcommonground and the

redforsignalinputsuchasvoltage,resistance,and

frequency,oroutputofsimulativesignalsuchasfrequency

signal,voltagesignalandvoltagesimulativesignalof λO2

sensor.Thecommonmeasuringprocessforresistance,

voltage and frequencymeasure:pressingtheselect

functionkeyafterthesignaljawbe correctlyconnected to

measured element.

The processforvoltageand frequencysignalsimulation:

you havetofirstlypressthe selectfunctionkeyand setthe

parameter,then press theselectfunction keyagainto

ensuretheinstrumentatthe simulatingstatus,lastly

connect thesignaljawstosimulationpoints.

Note:Toavoiddamaging theinstrument,theabove

connectionsmustbedonecorrectly.

LAUNCH STS600

E-6

5.2POWER

Aftercorrectlyconnectingthepowercabletothetwopoles

ofautobattery(12V),the instrumentwillstartself-testing.

The screen will showallthecharacters(see Fig.2).You

wouldhearone ‘bee’soundconfirmingtheinstrumentin

normalcondition.Thenthe screen willdisplay “P”character

forthe sixfunctionsselectuse

5.3SCREEN

The eachpart of thescreen meansasfollows(seeFig.2):

1)Displaythe maximumvalue onlyforvoltage, resistance

and frequencytesting.

2)Displaytheminimumvalue onlyforvoltage,resistance

and frequencytesting.

3)Displaymeasureresultorinputvalue

4)Unit displayarea（displaycorrespondingunitaccording

todifferentrange）

5)Dynamicvoltagevaluedisplaybarasthe horizontal

cursorlength(onlyforvoltagemeasurement)

6)Measurementand simulationfunction iconsfromleft to

rightare:voltagemeasurementicon,resistance

measurementicon,frequencymeasurementicon,

voltage simulation icon andfrequencysimulation icon.

Note:Thefunctionisactivatedwhentheoutline

borderoftheicon islit.

LAUNCH STS600

E-7

Fig.2Fulldisplay

5.4KEYBOARDOPERATION

5.4.1keyboardlayout

See Fig.3, thereare19 keysintotal.
