Lathem 7000E Manuel utilisateur
Lathem Time Corporation
ENGLISH
1
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his or her own expense.
Caution: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS A LIMITS FOR RADIO NOISE EMISSIONS
FROM DIGITAL APPARATUS AS SET OUT IN THE RADIO INTERFERENCE REGULATIONS OF THE
CANADIAN DEPARTMENT OF COMMUNICATIONS.
LE PRÉSENT APPAREIL NUMÉRIQUE N'ÉMET PAS DE BRUITS RADIOÉLECTRIQUES DÉPASSANT LES
LIMITES APPLICABLES AUX APPAREILS NUMÉRIQUES DE CLASSE A PRESCRITES DANS LE
RÈGLEMENT SUR LE BROUILLAGE RADIOÉLECTRIQUE ÉDICTÉ PAR LE MINISTÈRE DES
COMMUNICATIONS DU CANADA.
The details of this User's Manual are subject to change even without previous notification.
This User's Manual has been prepared with the utmost care to cover all aspects of the time
clock's use.
Be sure to use your time clock after you have fully understood the hardware and software
specifications and limits.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted,
in any form or by any means, mechanical, photocopying, recording or otherwise.
1.
2.
3.
4.
Lathem Time Corporation
www. lathem. com
(800) 241-4990
(404) 691-1065
This User's Manual and its contents are copyrighted by LATHEM
TIME CORP. with all rights reserved.
WARNING
2
TABLE OF CONTENTS
PRECAUTIONS
FEATURES
BEFORE USING TIME RECORDER
Accessories
Features
Installing Ribbon Cassette
Mounting Unit on Wall
Environmental Conditions
DAILY OPERATIONS
Functions for the buttons
Required / Optional / Disabled
Card reassign
All cards reset
Card reset
WHAT YOU CAN DO WITH THE 7000E
SETTING
Preparation for setting
Setting the Display Hours
Setting the Time
Setting the Date
Setting the Mode
Payroll Mode
Job Cost Mode
Setting the Print Format
Setting the Rounding
Setting the Auto Break Deduction
Setting the Max In
Setting the Button Function
Setting the Daylight Saving Time
Deleting the daylight saving time settings
Setting the Print Language
Resetting
PRINT EXAMPLE
INSTALLING Ni-Cd BATTERY (Optional)
TROUBLESHOOTING
SPECIFICATIONS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
1
3
4
4
4
5
7
7
8
9
9
10
11
12
14
16
16
17
18
19
20
20
23
24
26
27
28
29
30
33
34
35
36
37
38
39
3
1. PRECAUTIONS
This operation manual is prepared for safe and proper use of the unit.
Please follow all the instructions to avoid possible danger to yourself or
others and damage to the unit.
Signs
Various warnings and cautions are provided throughout this manual along with signs.
Remember each sign and its explanation listed below for your safety and proper
operation of the unit.
Caution
Warning
Improper handling may cause electric
shock DANGER.
DO NOT disassemble the unit.
"Don't" sign.
"Must-Do" sign.
Be sure to remove the line cord plug
from the outlet.
Do not disassemble the unit. There is a high voltage present inside, possibly leading to an
electric shock.
Do not use any voltage of the power source other than designated.
Do not share a single outlet with another plug. These may lead to fire or shock hazards.
Do not damage, break, or modify the power cord. Do not put a heavy object on, pull, or
forcefully bend the cord, either. These may damage the cord, possibly resulting in a fire or
electric shock.
If any anomaly occurs, for example, heat or smoke is generated or an odor is emitted, unplug
the unit immediately and contact your dealer for servicing. There is a danger that further use
may cause a fire or electric shock.
Do not modify the unit. Modifications may cause a fire and/or electric shock.
Warning
Improper handling may cause bodily accidents including
death and serious injury.
Improper handling may harm the human body or material.
4
1
If foreign matter should get in the unit (including a piece of metal, water, or liquid), disconnect
the plug from the outlet immediately and contact your dealer for servicing. There is a danger
that further use may cause a fire or electric shock.
Do not place the unit on an uneven or tilted surface. This may result in injuries due to the unit
dropping or falling off.
Do not put a water-filled container or a metal object on top of the unit. If water is spilled or the
metallic object slips inside, a fire or shock hazard may occur.
Do not place the unit near kitchen counter or humidifier. Oil, smoke, or steam generating from
them may cause fire or shock hazards.
Do not yank the power cord to disconnect from the outlet. Hold the plug with your hand to do
so, or the cord may be damaged, possibly leading to a fire or electric shock.
Remove the line cord plug from the outlet before transferring the unit, or it may damage the
cord, possibly leading to a fire or electric shock.
Make sure to insert the power plug as far as it will go. Improper insertion of the plug may
develop fire or shock hazards.
Do not insert or drop any other time card than specified into the slot. Such misuse may cause a
fire or electric shock.
If the unit should be dropped or the case be broken, unplug the unit and contact your dealer for
servicing. Further use may lead to a fire or shock hazard.
Be careful not to contact the print head, as you may get hurt or burned.
Do not install the unit in a humid or dusty environment. It may cause a fire or electric shock.
Do not plug or unplug the unit with a wet hand. You may get an electric shock.
Daily Care
For cleaning, turn the power off and wipe the case clean of dust and dirt with a dry
cloth, etc.
Caution
5
2
2. FEATURES
This time recorder will provide automatic alignment and basic
calculation of total hours. This time recorder will utilize time
cards pre-encoded with a bar code and numbered 1 through
100. The time recorder is designed for small businesses as a fast
and efficient way to track time for Payroll and Job Costing.
You can usually obtain technical support and order
accessories from the store where you bought the clock.
To contact Lathem, go on-line to www.lathem.com or
call 800-241-4990 (404-691-1065 outside USA ).
Automatic top-feed time recorder aligns registrations on time
card.
Prints IN (Start) and OUT (Stop) dates and times.
The recorder can operate in one of 2 modes;
Payroll Mode / Job Cost Mode
The recorder prints total elapsed time between registrations and
also prints a running total of accumulated time per time card on
each line.
In order to properly identify missed punches, the recorder has a
"Max In" value that is used to pair punches for calculations.
The number of cards that can be automatically registered is a
maximum of 50 cards.
The functions for the buttons on the front of the recorder can be
set. There are 3 options;
Required / Optional / Disabled
Automatic Daylight Savings adjustment
The languages English·Spanish·French can be selected to print
"Month" and "the days of the week".
The clock can be either wall or table mountded.
6
3
MUST USE THE E7 SERIES CARD FROM LATHEM TO INSURE PROPER OPERATION.
An optional battery is sold separately (Part No. VIS 6020) to provide 100% operation of card
print mechanism during power failures.
Features
<Front view> <Back view>
3.
BEFORE USING TIME RECORDER
Accessories
Wall mount hardware
Ribbon cassette
Part No. VIS6008
Keys
Daylight saving time indication
< Display >
Key hole
Cover
Display
Control button
Card slot
Wall-mounting
hole
Day of the week indication
Current date
IN OUT
Current time
SUMOTUWETHFRSA
7
4
Installing Ribbon Cassette
1Hold the left and right sides of the cover
and lift up.
2Turn the knob of the new ribbon cassette
in the same direction as the arrow to
tighten the ribbon.
3Place the ribbon cassette inside the
time recorder as shown in the figure.
Push the ribbon cassette until it snaps
into the clasps on both sides. If it is
difficult to insert the ribbon cassette,
try it while turning the knob.
Knob
Clasp
Clasp
(located on both sides)
Knob
Make sure the power is on before installing.
8
5
Take the following precautions when inserting a new ribbon cassette.
Install the ribbon cassette so that the ribbon is between the print head and the
ribbon mask (see the figure on the left). Printing will not come out properly if the
ribbon is placed behind the ribbon mask (see the figure on the right).
4Precautions to take when replacing the ribbon
65 Replace the cover by fitting the plugs
at both sides of the cover into the
holes located on the unit of the body,
and while pulling the cover toward
yourself, push down.
Turn the knob of the ribbon cassette in
the direction of the arrow to tighten
the ribbon.
Knob
Print head
Ribbon mask
Ribbon
Print head
Ribbon mask
Ribbon
9
6
Mounting Unit on Wall
The unit can be mounted on a wall using the supplied mounting fittings. To mount the unit
on a wall, take the following steps:
The supplied screws are intended
for use on a thick wooden wall
or wooden column. Do not use
them on any other materials.
There is a danger that the unit
may come off if used on other
materials.
Install wall mount screws (supplied)
into a wall 3.94 inches (10 cm) apart.
Be sure to keep about 0.12 inch ( 3
mm) of the screw head out of the wall.
Environmental Conditions
Avoid placing the unit in environments that are:
•humid or dusty
•exposed to direct sunshine
•subject to frequent or continuous vibrations
•outside the temperature range between 23˚F (-5˚C) and 113˚F (45˚C)
•affected by chemicals or ozone
3.94" (10cm)
0.12"
(3mm)
Mount the wall mount fittings
as shown on the right.
1
2
10
7
