Laser MID-735 Guide de l'utilisateur

QUICK OPERATION GUIDE MID-735

TABLE OF CONTENTS

APPEARANCE AND BUTTONS 4

ACCESSORIES 5

TURNING ON AND OFF 5

BATTERY CHARGING 5

RUN TIME 5

5 POINT TOUCH-SCREEN 5

SLEEP MODE _________ 5

LOCK / UNLOCK 6

HOME SCREEN ICONS 6

VIEW ALL APPS__ 7

APP ICONS 7

WIDGETS 8

NOTIFICATION MENU BAR 8

SHORTCUT MENU BAR 8

SETTINGS - WI-FI 9

SETTINGS 10

CONNECTING TO A PC / MAC VIA USB 10

eSTREET DIRECTORY 11

NAVIGATOR____________________________ 16

EBOOK DRM (ALDIKO) 17

WHY CREATE A GOOGLE ACCOUNT 18

GOOGLE PLAY APP 18

SPECIFICATIONS 18

FAQ 19

WARRANTY INFORMATION________________ 20

QUICK OPERATION GUIDE MID-735

IMPORTANT SAFETY INSTRUCTIONS AND PRECAUTIONS

Read all instructions carefully before use.

Retain this manual for future reference.

Use this product only in the manner described.

Only use a water-dampened soft-cloth to clean the surface of this product.

The following will damage this product: water or moisture ingress, exposure to

prolonged extreme heat or cold; excessive humidity, dust or sandy.

It is recommended to thoroughly charge the device for the first time. Subsequent

charges can be as needed. During charging, or extended use, the product may become

warm.

There are no userserviceable parts in this product.

Un-authorizedattempts to dismantle or repair this product will void product warranty

and may result in dangerous electric shock.

Remove data cable by pulling it from the plug, not from the cord.

QUICK OPERATION GUIDE MID-735

APPEARANCE AND BUTTONS:

Number

Description

1 Reset Button

2 Increase / Decrease Volume

3 Micro SD card slot. (Supports cards up to 32GB)

4 Micro USB interface (Data Transfer, Charging, USB Storage flash drive).

5 Stereo Earphone Socket (3.5mm Jack)

6 On / OFF button (*Press and hold to turn ON and OFF)

7 Built in Speaker

8 Front mounted camera

QUICK OPERATION GUIDE MID-735

ACCESSORIES

1 x 7” MID-735, 1 x DC Power Adaptor with USB socket, 1 x Micro USB/DATA cable, 1 x User

Guide

TURNING ON AND OFF

To turn ON, PRESS and HOLD the POWER button until the screen turns ON.

To turn OFF, PRESS and HOLD the POWER button until the power screen appears. Then select

Power Off.

Note:At any time you can press the POWER BUTTON to enter Snooze mode or to wake from Snooze

mode.

BATTERY CHARGING

You can charge your MID-735 using the suppliedDC Power Adaptor and USB/DATA cable.

You will be alerted when the battery charge falls below 15%. If the battery is completely

depleted the MID-735 will automatically turn off.

Note:Ifthe battery has been completely exhausted, it may take a few minutes to switch the MID-735

on once charging has begun. The MID-735 can be used during charging however this may increase

the time needed to fully charge the battery.

RUN TIME

Run time of portable devices such as this MID-735 can be extended by reducing the screen

brightness, turning off the Location function, turning off WiFi and turning off Apps that are

not required. Manually turning the screen off using the power button when not in use will

also prolong run time.

5 POINT TOUCH-SCREEN

The MID-735 has 5 different touch screen behaviours.

1-TAP Tap once to select or start a function, option or application

2- TAP and HOLD Tap and hold to select or start a function

3-DRAG and DROP Tap then drag an item and drop it to a location

4-DOUBLE TAP Double Tap an item twice to select or start a function

5-SLIDE/SWIPE Tap then slide an item up, down, left or right

SLEEP MODE

During prolonged inactive use where no buttons have been pressed, the screen will turn off

automatically to conserve power. Press the POWER button to wake the MID-735.

Note: This can be adjusted in Display option under Settings.

QUICK OPERATION GUIDE MID-735

LOCK / UNLOCK

When the MID-735 is in sleep mode, press the POWER button to show the unlock screen.

TAP and HOLD the LOCKED padlock icon, drag it to the UN-LOCKED padlock icon, then release.

Note:Some of the following images may be different from the actual product supplied.

HOME SCREEN ICONS

Number

Icon Function

Open web browser / Voice command

2 “Swipe Down” Notification Menu Bar

3 “Swipe Down” Shortcut Menu Bar

View all apps

Increase Volume

Open a list of recently used applications

Home screen

8 Back button

Decrease Volume

QUICK OPERATION GUIDE MID-735

VIEW ALL APPS

Press to view all the installed apps on your tablet

APPS ICONS

Note:Some of the following images may be different

from the actual product supplied.

Icon

Function

Browser: Internet browser

Calendar: Create and manage daily, weekly and monthly events, set alarm

clocks. Note: A Google account is required

Camera: Take and view pictures and video

Clock: Access alarm clock settings and time display

Downloads: Manage downloaded content

E-mail: e-mail access

Fil

e Manager: Access all pictures, video, music, sound clips and other files saved

on the device and SD card

Music: Music player

Web Browser: Open Chrome web browser

Settings: View settings menu

Sound Recorder: Recordsound using the microphone

Videos: Video player

QUICK OPERATION GUIDE MID-735

WIDGETS

Users can add or remove Widget program icons (shortcuts) from the desktop as well as move

them to different desktop screens.

To add a Widget, press and hold the desired widget, drag and drop it to the desired position

on the desktop.

To delete an icon, press and hold the icon until the “X” icon appears at the top LEFT of the

screen. Drag the icon to the“X” and then release to delete.

NOTIFICATION MENU BAR

Swipe down over the Notification Menu Bar (top left of the screen) to bring up any

notifications you may have.

SHORTCUT MENU BAR

Swipe down over the Short cut Menu Bar to view

items such as:

Battery charge, Settings, WiFi, Bluetooth (not

supported with model MID-735), Location, Audio

Profiles, Brightness, Rotation Locked, ScreenShot,

CastScreen.

PRESS AND

HOLD THE

MAIN

SCREEN

QUICK OPERATION GUIDE MID-735

SETTINGS

Wi-Fi

Note:a WiFi connection is required if connecting to the internet (for email, Play Store or web

browsing)

When WiFi is turned on it will automatically scan for all available WiFi networks

Tap the desired NETWORK name. If this NETWORK connects successfully, “Connected”

will appear. If the NETWORK is encrypted, enter the password then tap “Connect”.

Your MID-735 will indicate when the NETWORK connection is ready for use when the

WiFi icon appears on the top right notification bar.

QUICK OPERATION GUIDE MID-735

CONNECTING TO A PC / MAC VIA USB

Connect the USB cable to your MID-735 and PC/MAC, making sure you are using the correct

MICRO USB cable supplied.
