Part Number 900-455

Revision B January 2007

EDS Device Servers

Command Reference

EDS4100

EDS8PR

EDS16PR

EDS32PR

EDS Device Servers Command Reference 2

transmitted or reproduced in any form or by any means without the written permission of

Lantronix. Printed in the United States of America.

Ethernet is a trademark of XEROX Corporation. UNIX is a registered trademark of The

Open Group. Windows 95, Windows 98, Windows 2000, and Windows NT are

trademarks of Microsoft Corp. Netscape is a trademark of Netscape Communications

Corporation.

Contacts

Lantronix Corporate Headquarters

15353 Barranca Parkway

Irvine, CA 92618, USA

Phone: 949-453-3990

Fax: 949-453-3995

Technical Support

Online: www.lantronix.com/support

Sales Offices

For a current list of our domestic and international sales offices, go to the Lantronix web

site at www.lantronix.com/about/contact .

EDS Device Servers Command Reference 3

Contents

1: Introduction 4

2: Configuration Using Telnet or Serial Port 5

Using Telnet________________________________________________________ 5

Using a Serial Port___________________________________________________ 5

Navigating the Command Line Interface __________________________________ 6

Guidelines _____________________________________________________________ 6

CLI Levels _____________________________________________________________ 7

3: Summary of CLI Commands 8

Root Menu _________________________________________________________ 9

Enable Menu ______________________________________________________ 10

Chem Level Commands _____________________________________________ 14

Configure Menu ____________________________________________________ 16

Interface 1 Level Menu ______________________________________________ 24

Device Menu ______________________________________________________ 26

Filesystem Menu ___________________________________________________ 28

Line Menu ________________________________________________________ 31

SSH Menu ________________________________________________________ 33

SSL Menu ________________________________________________________ 36

Tunnel Menu ______________________________________________________ 37

4: Configuration Using XML 44

XML Configuration Record Schema_____________________________________ 44

Quick Syntax Tour for XCRs __________________________________________ 45

Records, Groups, Items, and Values____________________________________ 46

Importing and Exporting an XML Configuration File ________________________ 47

Best Practices _____________________________________________________ 48

Testing the XML Configuration File _________________________________________ 48

Importing and Exporting Partial Configurations ________________________________ 48

Including Passwords in the XML File________________________________________ 49

Special XCR Groups ____________________________________________________ 50

XML Groups_______________________________________________________ 51

XSR Groups and Items ______________________________________________ 61

Index 68

EDS Device Servers Command Reference 4

1: Introduction

EDS device servers (EDS4100, EDS8PR, EDS16PR, and EDS32PR) contain all the

components necessary to deliver full network connectivity to virtually any kind of serial

device, a reliable TCP/IP protocol stack, and a variety of remote management

capabilities. They boast an innovative design and run on Lantronix’s leading-edge

Evolution OS™, which supports three convenient configuration methods (Web, command

line, and XML). The EDS User Guide describes how to configure the EDS using a web

interface.

Command-Line Interface (CLI): Making the edge-to-enterprise vision a reality, the EDS

with the Evolution OS™ uses industry-standard tools for configuration, communication,

and control. For example, the Evolution OS™ uses a Cisco®-like command line interface

(CLI) whose syntax is very similar to that used by data center equipment such as routers

and hubs

This Command Reference provides information about navigating the CLI interface and

lists the CLI commands for configuring, monitoring, and controlling the EDS.

XML-based Architecture and Device Control: XML is a fundamental building block for

the future growth of M2M network. The EDS supports XML-based configuration and

setup records that makes device configuration transparent to users and administrators.

The XML is easily editable with a standard text or XML editor.

This command reference provides a brief overview of the XML interface, shows typical

XML commands, and provides best practices for using XML commands.

EDS Device Servers Command Reference 5

2: Configuration Using Telnet or Serial Port

As an alternative to using Web Manager, you can configure the EDS using a series of

commands. You can access this command-line interface (CLI) with a Telnet session or

through a serial port connection to the EDS.

This command reference describes how to use the CLI and provides a detailed list of all

the CLI commands supported.

Using Telnet

To configure the EDS using a Telnet session over the network, establish a Telnet

connection.

Note: As an alternative, establish a Telnet connection by clicking the Telnet

Configuration tab in DeviceInstaller. See the EDS User Guide for more

information.

1. From the Windows Start menu, click Run. The Run dialog box appears.

2. In the Run dialog box, type the following command, where x.x.x.x is the IP address:

telnet x.x.x.x

A prompt displays.

Note: Depending on the level of security you have configured, the User Name

and Password may be required. If you named the unit, the name displays as the

prompt. If you assigned a host name to the unit, a host name prompt displays.

Using a Serial Port

To configure the EDS locally using a serial port, connect a terminal or a PC running a

terminal-emulation program to an EDS serial port. Configure the terminal (or emulation)

for 9600 baud, 8-bit, no parity, 1 stop bit, and no flow control.

1. Cycle the unit’s power (power off and back on). After power-up, the self-test begins.

Note: The EDS8/16/32PR products have a dedicated console port that

automatically provides a CLI. If you are using the the console port, skip

step 2.

2. Press and hold down the exclamation point (!) key. (Some keyboard require you to

press the Shift key when typing an exclamation point.) Then, when an exclamation

point appears on the terminal or PC screen, immediately type xyz to display a CLI

prompt.

2: Configuration Using Telnet or Serial Port

EDS Device Servers Command Reference 6

Navigating the Command Line Interface

Guidelines

Commands at the root level (top level) of the CLI do not affect current configuration

settings. Commands within the Enable menu (and its sub-menus) modify the EDS’s

configuration.

Items within < > (e.g. <string>) are required parameters.

To view acceptable commands: Type enter “?”.

To move to a sub-level and traverse the tree of commands: Enter each sub-

command only in its parent command prompt. For example, to access the Tunnel1 level

within the Enable level (which is below the root level), enter:

>enable

(enable)#tunnel 1

To exit and return to the menu one level higher: Type exit.

The following key combinations are allowed when configuring the EDS from the CLI:

Ctrl + a: place cursor at the beginning of line

Ctrl + b: backspace one character

Ctrl + d: delete one character

Ctrl + e: place cursor at the end of the line

Ctrl + f: move cursor forward one character

Ctrl + k: delete everything to the end of the line

Ctrl + l: redraw the command line

Ctrl + n: display the next line in the history

Ctrl + p: display the previous line in the history

Ctrl + u: delete entire line and place cursor at start of prompt

Ctrl + w: delete one word back in line

Esc + b: move cursor back one word

Esc + f: move cursor forward one word

Notes:

You need only type enough characters to uniquely identify each part of a command.

The EDS CLI also supports tab completion.

2: Configuration Using Telnet or Serial Port

EDS Device Servers Command Reference 7

To view the current configuration at any level: Type show. The configuration for that

menu level displays.

To view the list of commands available at the current menu level: At the command

prompt, type ?. The list of current commands displays.

To return to the next level up in the menu hierarchy: At the command prompt, type

exit. The prompt for the parent menu displays.

To view the available commands and their explanation: At the command prompt,

type *. The list of commands for that menu level and their description displays.

CLI Levels

The following diagram shows the CLI command levels.

root

enable

chem. <n>

config

if 1

device filesystem line <n>

line <n>

tunnel <n>

ssh ssl

tunnel <n>

line <n>

tunnel <n>

EDS Device Servers Command Reference 8

3: Summary of CLI Commands

The following sections describe the CLI commands. The commands are organized as

follows:

Root menu: page 9

Enable menu: page 10

Chem menu: page 14

Configure menu: page 16

Interface 1 Level Menu: page 24

Device menu: page 26

Filesystem menu: page 28

Line menu: page 31

SSH menu: page 33

SSL menu: page 36

Tunnel menu: page 37

3: Summary of CLI Commands

EDS Device Servers Command Reference 9

Root Menu

The following parameters are top-level root commands. These commands do not alter

the configuration of the EDS. You can issue these commands from any level.

Root Configuration

Command Description

clrscrn Clears the screen.

enable Displays the Enable level prompt.

exit Exits from the system.

ping <host> Pings the host destination the specified number of times

(count) with a 5-second timeout.

<host> = host destination.

ping <host> <count>

<timeout> Pings the string destination a specified number of times

with a specified timeout.

<host> = host destination.

<count> = number of times the ping is to occur.

<timeout> = number of seconds that must elapse without a

response before the ping times out.

show history Displays the set of commands inputted from the moment

user was brought back up to this menu.

show eds4100

show eds8PR

show eds16PR

show eds32PR

Displays the current EDS settings.

trace route <host> Determines the path taken from a computer to a specified

destination.

<host> = host destination.

3: Summary of CLI Commands

EDS Device Servers Command Reference 10

Enable Menu

The following configurable parameters reside in the Enable configuration menu

Enable Menu Command Description

auto show interfaces Displays interface statistics.

auto show processes Continuously displays thread runtime information.

auto show xsr Displays XML Status Record counters.

chem <number> Changes to the Configure Email level.

clear interface

counters Sets the interface session counters to zero.

clear line <number> Closes a specific command mode session.

<number> = number of the serial line to be cleared.

clear query port

counters Sets the Query Port counters to zero.

clear ssh <session> Closes an active SSH session on the EDS.

<session> = session number displayed by the show

sessions command.

clear telnet <session> Closes an active Telnet session on the EDS.

<session> = session number displayed by the show

session command.

clear xsr counters Sets the XML Status Record counters to 0.

configure Displays the Configuration-level menu.

connect Displays names and numbers of all lines.

connect line <line> Starts a session on the serial line.

<line> = line number.

device Displays the device-level menu.

disable Exits current menu level and returns to main root level

menu.

exit Exits the system.

filesystem Displays the Filesystem-level menu.

kill line <line> Closes a command mode session on the line.

<line> =line number

Autres manuels pour EDS4100

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Lantronix Serveur

Lantronix

Lantronix I/O 2100 Manuel utilisateur

Lantronix

Lantronix DSTni-XPress DR Manuel utilisateur

Lantronix

Lantronix SLC8 Manuel utilisateur

Lantronix

Lantronix MSS100 Manuel utilisateur

Lantronix

Lantronix SCSxx05 Manuel utilisateur

Lantronix

Lantronix SLB Manuel utilisateur

Lantronix

Lantronix xSenso 2100 Manuel utilisateur

Lantronix

Lantronix UDS2100 Manuel utilisateur

Lantronix

Lantronix XPress DR Manuel utilisateur

Lantronix

Lantronix xPico XPW100A003-01-B Guide de configuration rapide

Lantronix

Lantronix SecureBox SDS2100 Manuel utilisateur

Lantronix

Lantronix EDS8PS Manuel utilisateur

Lantronix

Lantronix Com Port Redirector Manuel utilisateur

Lantronix

Lantronix XPress DR Manuel utilisateur

Lantronix

Lantronix EDS-MD EDS-MD4 Manuel d'installation

Lantronix

Lantronix XPort Direct Guide de configuration rapide

Lantronix

Lantronix XPress DR+ Mode d’emploi

Lantronix

Lantronix MatchPort b/g Guide de configuration rapide

Lantronix

Lantronix UDS1100 Manuel utilisateur

Lantronix

Lantronix MatchPort b/g Pro Guide de configuration rapide

Lantronix

Lantronix WiPort Manuel utilisateur

Lantronix

Lantronix Com Port Redirector Manuel utilisateur

Lantronix

Lantronix ETS16PR Manuel utilisateur

Lantronix

Lantronix XPico 900-691-R Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
